- Page 1 Manual Automatic battery charger / maintainer Current CARBA-1 Applies for Code Model 101610 CARBA-1 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Contents Technical data CAUTION Safety warnings To gain the best performance of the tool, prolong the duty life, Parts make the Warranty valid if necessary, and to avoid hazards Start Up of fatal injuries please read and Troubleshooting understand this manual before using the tool. -
Page 3: Technical Data
Technical data CARBA-1 Code 101610 Description Automatic battery charger / maintainer Output voltage 6 V c.c. 12 V c.c. Maximum input power 21 W (Maximum) Rated output voltage 7.2 V c.c. ± 0.2 V 14.4 V c.c. ± 0.2 V... -
Page 4: Safety Warnings
Safety warnings • •Read all instructions before using or • Keep the charger away from heat sources when CAUTION operating the charger. charging to prevent the heat source from damaging the • Do not disassemble the charger without training. charger and becoming a safety issue. •... -
Page 5: Parts
Parts Charger connection AC plug Cargador/mantenedor de Power LED Fault LED batería automático indicator indicator Automatic battery Charger charger / maintainer Mode 12 V output selector MODE LED indicator Ring terminals 6 V output LED indicator 12 V Alligator clip ENGLISH... -
Page 6: Start Up
Start Up MODE 1. Connect to the AC outlet (A) 2. Select the correct charging voltage according to the nominal voltage of the battery (e.g., for a 6 V battery select the 12 V 6 V charging voltage). 3. You have two options for fastening the battery terminals: by means of clamps (B) or washers (C), depending on the type of battery. - Page 7 Start Up Safety device 1. The charger will automatically go into sleep mode when 4. Connect the red clamp or washer to the positive charging is finished to prevent overcharging. battery "+" and the black clamp or washer to the 2.
-
Page 8: Troubleshooting
Troubleshooting Problem Solution 1. Check if the battery charger is plugged into a good socket. Does not react when power is on. 2. Does the plug have an AC outlet? 1. Check that the clamp is properly connected. The indicator lights up, but there is 2. -
Page 9: Notes
Notes ENGLISH... -
Page 10: Warranty Policy
. Phone number 800-018-7873. Made in China. Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
