Kohler ARCHER K-2449T Installation Instructions Manual

BEFORE YOU BEGIN BEFORE YOU BEGIN
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
Make sure the finished wall is straight and plumb, and the
floor is flat and perendicular to the finished wall.
·
Remove any moldings that may inhibit the vanity from
being flush against the finished wall.
·
It is recommended that the drawer, door(s), and shelf be
removed from the cabinet before beginning the cabinet
installation. Doing so will ease the installation process.
Refer to the sections contained in this guide for proper
removal.
·
Turn off the water supply.
·
The pluming installation must comply with Water Supply
Regulations/Bye-laws, Building Regulations or any
particular regulations and practices, specified by the local
water company or water undertakers. The installation
should be carried out by a plumber.
·
Before installation carefully inspect the new fixture for any
signs of damage.
ORDERING INFORMATION
This installation covers the following products in the
TM
ARCHER range:
TM
ARCHER Vanity Cabinet ....................................K-2449T
TM
With ARCHER Vanity ...................................K-2358-1/4/8
SAFETY: WARNINGS
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1. They are installed, commissioned, operated and
maintained in accordance with the recommendations given
in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended guidelines
are given in the MAINTENANCE
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
1044886-T01-A 1082651-T01-A
section.
( )
-1-
·
·
·
·
·
·
·
·
·
...................................................K-2449T
.........................................K-2358-1/4/8
1.
2.
158 200436
Copyright Kohler China Ltd., 2007
ARCHER
INSTALLATION INSTRUCTIONS
TM
VANITY
K-2449 T
, 2007
