SCHILD Heinrich Instruction Manual

Automatic swiss gmt eta 2893-2
Hide thumbs

Advertisement

Table of Contents

L I M I T E D E D I T I O N
I N S T R U C T I O N
M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heinrich and is the answer not in the manual?

Questions and answers

Related Manuals for SCHILD Heinrich

Summary of Contents for SCHILD Heinrich

  • Page 1 L I M I T E D E D I T I O N I N S T R U C T I O N M A N U A L...
  • Page 4 SWISS MOVEMENT GMT AUTOMATIC This Limited Edition timepiece is equipped with a Swiss Made self-winding Mechanical Automatic movement manufactured by ETA. It does not need a battery. It is powered by the motions of the user’s own wrist during the wear of the watch.
  • Page 5 A) DISPLAY Crown for Inner World Citys Turning Bezel Date Minute Hand 24 Hours Dial Ring Hour Hand Screw Down Crown Second Hand Hand Inner World Citys Turning Bezel...
  • Page 6 B) PLEASE READ THE FOLLOWING BEFORE UNSCREWING THE CROWN SCREW-DOWN CROWN Screw-down crowns are used to ensure water resistance. ALWAYS be certain that your crown is securely screwed down ( Position [0] is secured. Positions [1], [2] and [3] are not secured for water resistance ).
  • Page 7 C) USING THE SCREW- DOWN CROWN Do not pull the crown unless it is UNSCREWED first: TO UNSCREW: Turn the crown anti-clockwise until it turns freely without tension. GENTLY pull the crown out to the other desired positions for watch setting. TO SCREW: Push the crown ALL THE WAY IN (towards the watch) THEN...

  • Page 8: Winding The Mainspring

    D) WINDING THE MAINSPRING THIS WATCH IS AN AUTOMATIC WATCH EQUIPPED WITH A MANUAL WINDING MECHANISM. 1. Unscrew the crown by turning it anti-clockwise. 2. When it is in position [1], turn the crown clockwise to wind. Wind 5-10 times and it will start to move naturally after shaking slightly.
  • Page 9 NOTE: This watch MUST be worn for at least 8 (Eight) hours each day to ensure it is fully wound. An automatic watch will only wind when the watch is on your wrist and your arm moves. Winding the watch by the crown will put power on the spring but not enough to allow the watch to function fully.

  • Page 10: Time Setting

    E) TIME SETTING 1. Unscrew the crown and pull it out to position [3] (2nd click). 2. Turn the crown anti-clockwise to set the correct time. 3. Push the crown in then screw it securely. * Take a.m./p.m. into consideration when setting the hour and minute hands to the desired time.

  • Page 11: Date Setting

    F) DATE SETTING 1. Unscrew the crown and pull it out to position [2] (1st click). 2. Turn the crown anti-clockwise to set the correct date. 3. Push the crown in then screw it securely. * Do not set the date between 9:00 P .M. and 4:00 A.M.
  • Page 12 G) HOW TO SET THE SECOND TIME ZONE You may wish to set your main time to your current location and the second time read out via the GMT hand to another location for at a glance read out of two timezones at the same time. 1.
  • Page 13 H) HOW TO READ THE SECOND TIME ZONE The GMT function allows travelers to simultaneously read their local time and a second timezone. The local time is indicated by the conventional hour and minute and seconds display. The second timezone is indicated by the triangle tipped GMT hand read against markings on the 24 Hours Dial ring.
  • Page 14 Example: Local Time: Hong Kong: 5pm 24 Hours Dial Ring Second Timezone: Zurich: 11am The triangle tipped GMT hand is always indicating Zurich time during your trip in Hong Kong.
  • Page 15 USING THE WORLD CITIES TURNING BEZEL The rotating bezel or dial ring, may feature the names of major city around the world in the sequence of time difference. Using this bezel you may be able to read and keep track of time in another (2nd) timezone.
  • Page 16 Example: the present time is 10:09 p.m.(Tokyo time) 24HRS. Index The approximate time of all the major cities can be determined by using the rotating bezel.
  • Page 17 Example: Perhaps you want to know the time of Paris while in Tokyo. [The main time display is set according to the time in Tokyo.] 1. Read and change the present time [hour] into 24-hour format. [10 o’clock p.m. --> 22:00] 2.
  • Page 18 J) HOW TO USE A DUAL DEPLOYANT CLASP 1. Press the buttons on both sides of the clasp. 2. The Buckle will release and open.
  • Page 19 K) HOW TO CHANGE THE BRACELET TO STRAP Quick Release Spring Bar...
  • Page 20 Quick Release Spring Bar...

  • Page 21: Care And Maintenance

    We advise having your timepiece serviced every 3 or 4 years to ensure long use and trouble free operation. While your SCHILD timepiece has been designed and built to exacting specification, it is important to avoid the following conditions: extreme heat or...
  • Page 22 Never operate any of the function buttons or crown when timepiece is in contact with water. Avoid exposure to strong magnetic fields or sources of static electricity as these may interrupt the mechanisms inside the watch. It is also important to avoid extreme shock or impact.

  • Page 23: Water Resistance

    WATER RESISTANCE The water resistance indicated on your timepiece serves only as a guide. Actual water resistance may vary depending on a number of important factors including temperature, water salinity, and actual use under water. The water resistance of your timepiece may eventually be compromised over time with general wear and tear and the use of your watch under adverse...

  • Page 24: Service Log

    SERVICE LOG Use this area to record any after care of your timepiece. Notes: Date Location...
  • Page 25 NOTES...
  • Page 26 NOTES...
  • Page 28 Vo l .1. 0 4 EN S C H I L D 1 8 9 6 . C O M...
