Inovonics™ RF LAN Expander Module. P/N: 996008
Overview .................................................................................................................................................................1
Parts List .................................................................................................................................................................2
Specifications ..........................................................................................................................................................2
Regulatory Information ..........................................................................................................................................2
Installation ..............................................................................................................................................................2
The Inovonics™ RF Expander Module Assembly ....................................................................................................4
Module Status and Fault LEDs ................................................................................................................................5
System Programming .............................................................................................................................................5
Transmitter Registration.........................................................................................................................................6
Transmitter Compatibility Guide ............................................................................................................................7
Integriti Inovonics Functionality .............................................................................................................................8
Inception Inovonics Functionality........................................................................................................................ 10
The Inovonics™ RF Expander, designated as an "F" Type module, provides an interface for Inovonics™ security
transmitters such as detectors, universal transmitters and user pendants. Refer to:
- The "Transmitter Compatibility Guide" chapter in this manual for the list of supported transmitters.
- The 'Inovonics Security Product Guide. Australia/New Zealand' for detailed transmitter product descriptions.
The number of devices supported is determined by the Controller Input and User licensing. There are no Auxiliaries on
this Module.
Power is sourced from the LAN or a separate battery-backed external supply.
Depending on type, Transmitters are processed as Zone Inputs or User RF remotes. Some devices can be processed as
either type depending on how they are enrolled in the system.
Repeaters can be used to extend the range of the system. The Repeater device ID can be assigned to an RF Zone Input to
allow Repeater problems to be monitored.
Refer to the "Inovonics Repeater Monitoring..." chapters in this manual for details.
Up to 32 Detectors can be monitored by each Module as Zone Inputs. User pendant transmissions can be received via any
RF Expander Module in the system. Transmitters must be registered via simple procedures described on page 7, before
they can be used. Once registered, system programming is then performed to specify their operations. An RF Zone
indicates an Alarm state when the device is in alarm, and a Tamper state when the housing is opened. A 'Detailed
Review' option is available to log information including transmitter signal strength which can assist in commissioning and
troubleshooting.
COMPATIBILITY:
© 2017 - 2020. Inner Range Pty. Ltd.
Inner Range Integriti/Inception.
INSTALLATION AND APPLICATION GUIDE
Integriti Controller Firmware & Software must be V17 or later.
Inception Controller must be V1.2.1 or later.
For use in Australia, New Zealand or North America only.
Contents
Overview
1
Rev. 3.0 Jan. 2020
Advertisement
Table of Contents
Related Manuals for Inner Range Inovonics 996008
Summary of Contents for Inner Range Inovonics 996008
-
Page 1: Table Of Contents
COMPATIBILITY: Integriti Controller Firmware & Software must be V17 or later. Inception Controller must be V1.2.1 or later. For use in Australia, New Zealand or North America only. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... -
Page 2: Parts List
3. Set the Module Number using DIPswitches 1 to 7 as required. DIPswitch 8 must be Off. See table below. 4. Connect the LAN, connect the power supply (if required), test, then fit the enclosure cover. See details on pages 3 - 5. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... - Page 3 If the LAN cabling connected to the Module passes through areas where electrical interference may exist, is installed outside a building, or is a very long run, then the Inner Range LAN Surge Diverter (P/N: 995041) may be used and connected to an effective EARTH to minimise interference.
-
Page 4: The Inovonics™ Rf Expander Module Assembly
LAN Data B connection. *NOTE: Positive (+) connections from two different power supply sources must never be connected together. See “LAN & Power Supply Wiring” on page 3. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... -
Page 5: Module Status And Fault Leds
Refer to the ‘Transmitter Registration’ and ‘Inception Inovonics Functionality’ chapters in this manual for additional information. Full programming details are provided via the Info buttons in the Inception browser. NOTE: Additional programming may be required depending on the desired functionality. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... -
Page 6: Transmitter Registration
‘Manage Users’ under ‘Configuration’ > ‘Users’. Select or create a User. Expand the ‘Credentials’ option, click on ‘Add Items’ under ‘Remote Fobs’ then follow the prompts. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... -
Page 7: Transmitter Compatibility Guide
‡ Devices with a “60” or “240” suffix on the model number indicate a longer poll time in minutes. The poll time for these devices will need to be altered accordingly in the system programming. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... -
Page 8: Integriti Inovonics Functionality
Right Button Both buttons * NOTE: EN1235DF incorporates a Tamper switch and is intended to be permanently mounted and enrolled as a Zone input rather than a User Remote. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... - Page 9 Note that ‘Poll Fail’, ‘Mains Fail’, ‘Low Battery’ and ‘RF Jam’ are also monitored per Module, via the RF LAN Expander System Inputs as described above to allow reporting of these conditions. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020...
-
Page 10: Inception Inovonics Functionality
Detector Alarm EN1265 Detector Alarm Detector Alarm Detector 2 Alarm ‘Detector’ is the High temperature alarm. EN1752 ‘Detector2’ is the Low temperature alarm. EN1941 Detector Alarm Detector 2 Alarm © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020... - Page 11 Any of these conditions (where relevant) on any device associated with the Module will trigger the relevant alarm for that Module. The Review log can then be inspected for details of the specific device that triggered the alarm. © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020...
- Page 12 While every effort has been made to ensure the accuracy of this manual, the manufacturer assumes no responsibility or liability for any errors or omissions. • Due to ongoing development, this manual is subject to change without notice. www.innerrange.com Document Part No: 636008 © 2017 – 2020. Inner Range Pty. Ltd. Rev. 3.0 Jan. 2020...
