IMO JAGUAR VXM Manual

High performance ac drives 0.4 - 400kw
Hide thumbs Also See for JAGUAR VXM:
Table of Contents

Advertisement

Quick Links

Download this manual
HIGH PERFORMANCE AC DRIVES 0.4 - 400kW
Year
Guarantee

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JAGUAR VXM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IMO JAGUAR VXM

Summary of Contents for IMO JAGUAR VXM

  • Page 1 HIGH PERFORMANCE AC DRIVES 0.4 - 400kW Year Guarantee...
  • Page 2 Range and Application Please seek the full instruction manual before installation. Other Features If in doubt please call IMO on 020 8452 6444 or Specifications visit our website on www.imopc.com (Please refer to inside back Terminal Functions...
  • Page 3 3 0 0 Dynamic torque-vector control system performs high- 2 0 0 speed calculation to determine the required motor power for the load status. IMO’s key technology is 1 0 0 optimal control of voltage and current vectors for maximum output torque.
  • Page 4 JAGUAR VXM New on-line tuning system • On-line tuning to continuously check for variation of motor characteristics during running for high-precision speed control. • This tuning function also available for a second motor, which allows high-precision driving of the second motor by changeover operation between two motors.
  • Page 5 JAGUAR VXM Advanced, convenient functions • 16-step speed, 7 pattern operation with timer control, rotating motor pick-up control for conveyance machinery. • PID control, cooling fan on/off control, line/inverter changeover operation for fans and pumps. • Rotating motor pick-up control: Restarts motor without any shocks, by detecting motor speed where motor is coasting after momentary power failure occurs.
  • Page 6 RANGE AND APPLICATION Model numbers and range Jaguar VXM can be Easy to apply to customer systems. A consistent design concept in all models from 0.4kW to 315kW. Fans • Air-conditioning systems (for factory, building, office, hospital, Nominal applied 400V series...
  • Page 7 JAGUAR VXM used for most general purpose industrial and commercial applications Machine tools Conveyance machiner y Chemical machiner y/wood working machines • Grinding machines • Cranes (travelling, traversing, hoisting) • Fluid mixing machine • Sanding machines • Automated warehouse • Extruders •...
  • Page 8 JAGUAR VXM Intelligent keypad panel Extensive product line • Copy function: Easily copies function codes and data • Since the product is equipped with a dual rating to other inverters. feature, it can be used for variable torque rating control (VT) (5.5kW or larger), as well as constant •...

  • Page 9: Standard Specifications

    *5) When the input voltage is 380V/50Hz or 380 to 415V/60Hz, the top of the auxiliary transformer must be changed. *6) Refer to the EN 61800-3 (5.2.3). *7) Tested at standard load condition (85% load). *8) This value is calculated. (Refer to IMO). *9) With a nominal applied motor, this value is average torque when the motor decelerates and stops from 60Hz.

  • Page 10: Common Specifications

    • Terminal C1 (4 to 20mA DC or 20 to 4mA DC) NOTES: (*) Option *1) For application at 120Hz or above, please contact IMO. *2) Inverter may automatically reduce carrier frequency, in accordance with ambient temperature or output current for protection purposes.
  • Page 11 JAGUAR VXM Item Explanation Control Automatic deceleration Torque limiter 1 (braking) is set at “F41:0” (Same as Torque limiter 2 (braking). • In deceleration : The deceleration time is automatically extended up to 3 times the setting time for tripless operation even if braking resistor not used.
  • Page 12 JAGUAR VXM Item Explanation Protection Overload Protects the inverter by electronic thermal and detection of inverter temperature. Over voltage Detects DC link circuit overvoltage, and stops the inverter. 400V series: 800VDC. Under voltage Detects DC link circuit undervoltage, and stops the inverter.

  • Page 13: Terminal Functions

    TERMINAL FUNCTIONS JAGUAR VXM Symbol Terminal name Function Remarks Func. code Main L1/R, L2/S, Power input Connect a 3 phase power supply circuit L3/T U, V, W Inverter output Connect a 3 phase induction motor P1, P(+) For DC REACTOR...
  • Page 14 JAGUAR VXM Symbol Terminal name Function Remarks Func. code Analog Analog monitor Output voltage (0 to 10VDC) is proportional to selected function’s value as follows. Allowable maximum output current: 2mA F30 to F31 output The proportional coefficient and bias value can be preset.

  • Page 15: Basic Wiring Diagram

    BASIC WIRING DIAGRAM JAGUAR VXM Keypad panel operation The following diagram is for reference only. For detailed wiring diagrams, refer to the relevant instruction manual. Main circuit 7.5 kW or smaller 11 to 55 kW (*3) DC reactor Jumper wire (*3)
  • Page 16 (P(+)] and (DB) terminals. The end to earth at both ends of the cable. The appropriate power of the removed cables (indicated with an X) must be supply filter kit should also be fitted to the inverter input insulated. circuit. For further details contact IMO.

  • Page 17: Keypad Panel

    KEYPAD PANEL FUNCTIONS AND OPERATIONS Keypad Panel LED monitor LCD monitor In operation mode: In operation mode : Displays the setting frequency, Displays various items of output current, voltage, motor information such as operation speed, or line speed. condition and function data. In trip mode: Operation guidance, which Displays code indicating the...
  • Page 18 JAGUAR VXM Keypad Panel Operation Perform the wiring shown in the Basic wiring diagram on page 14. Turn on inverter power, and use the key to set an output frequency. Press the key, then press the key. The inverter starts running using the factory setting function data.

  • Page 19: Function Settings

    FUNCTION SETTINGS JAGUAR VXM The functions in the white boxes can be set while the inverter is running. Other functions must be set while the inverter is stopped. Fundamental Functions Function Min. Factor y setting Setting range Code Name LCD monitor...
  • Page 20 JAGUAR VXM The functions in the yellow boxes can be set while the inverter is running. Other functions must be set while the inverter is stopped. Extension Terminal Functions Function Min. Factor y setting Setting range Code Name LCD monitor...
  • Page 21 FUNCTION SETTINGS JAGUAR VXM The functions in the white boxes can be set while the inverter is running. Other functions must be set while the inverter is stopped. Extension Terminal Functions (cont’d) Function Min. Factor y setting Setting range Code Name...

  • Page 22: Motor Parameters

    EXTENSION TERMINAL FUNCTIONS Motor Parameters The functions in the white boxes can be set while the inverter is running. Other functions must be set while the inverter is stopped. Function Min. Factor y setting Setting range Code Name LCD monitor unit -22kW 30kW-...
  • Page 23 0.00 Notes: *1) Typical value of standard IMO 4P motor. *2) Percent shall be set according to FUNCTION CODE: P02 or A09, motor capacity. Torque referenced here may not be obtainable when DATA CODE: 0 is selected for FUNCTION CODE: P02 or A09.

  • Page 24: Protective Functions

    PROTECTIVE FUNCTIONS Function Description LED monitor Overcurrent • Stops running to protect inverter from an overcurrent resulting from overload. During protection • Stops running to protect inverter from an overcurrent due to a short-circuit in the acceleration (Short-circuit) output circuit. During (Earth fault) deceleration...

  • Page 25: External Dimensions

    EXTERNAL DIMENSIONS JAGUAR VXM Fig. 1 Fig. 2 VXM40 © VXM75 VXM150 © VXM400 Type VXM40 36.5 VXM75 51.5 Fig. 3 Fig. 4 VXM550 © VXM750 VXM1100 © VXM2200G...
  • Page 26 JAGUAR VXM Fig. 5 Fig. 6 Internal mounting type External cooling type KEYPAD panel (Common for all models) (30kW or larger) (30kW or larger) ø15 or ø18 ø15 or ø18 2 or 3 - øC Lifting hole Lifting hole Panel drilling...
  • Page 27 Three-phase average voltage [V] (For improving input power-factor, reducing harmonics) • Used to reduce input harmonic current (correcting power-factor) • For the resultant effects, contact IMO. Optional. May be fitted to compensate for long motor cables, or shock loads AC Reactor (ACR)
  • Page 28 (1) A DC reactor must be used for 75kW and above. (2) The above drawings, masses and dimensions are intended as a guide only. Product details may be subject to change without prior notice. If in doubt contact IMO Ltd. *Please contact IMO for details.
  • Page 29 OPTIONS JAGUAR VXM Braking Unit, Braking Resistor Continuous braking (100% Repetitive braking Continuous braking Repetitive braking Inverter Option torque conversion value) (100s or less cycle) (MAX. braking torque) (100s or less cycle) Power Max. Max. supply Constant Torque Rating (CT)
  • Page 30 JAGUAR VXM Name (type) Dimensions Braking unit Fig.C Fig.B Fig.A Mounting hole φ4.5 Dimensions (mm) Mass Voltage Type Fig. (kg) VXDBU 11-22 See Fig. A – VXDBU 30-37 – 400V VXDBU 45-55 Series VXDBU 75-90 VXDBU 110-132 VXDBU 160-220 Braking resistors Example 1 –...
  • Page 31 PBG11-7.5 VXM550 to VXM750 PBG11-22 VXM1100to VXM2200G Panel-mount adaptor Used to mount a Jaguar VXM inverter in panel holes that were Type Applicable inverter type (MAG9-I I I I used to mount a Fuji G7S inverter. MAG9-3.7 VXM40 to VXM400 MAG9-7.5...
  • Page 32 • For molded-case circuit breakers (MCCB) and earth-leakage circuit breakers (ELCB), the required frame type and series depend on the transformer capacity and other factors. When selecting breakers, refer to IMO, if uncertain. • Select the current sensitivity of ELCB, with reference to motor cable length and type, and carrier frequency.
