Samsung PS50P3HS Service Manual

Samsung PS50P3HS Service Manual

Chassis d59a(p)
Hide thumbs

Advertisement

Quick Links

Download this manual
PLASMA DIAPLAY TV
PLASMA DISPLAY TV
Chassis :
D59A(P)
Model :
PS50P3HX/XEU
1.
2.
3.
4.
C O N T E N T S
Alignment and Adjustments
Exploded View and Parts List
Electric Parts List
Schematic Diagrams

Advertisement

loading
Need help?

Need help?

Do you have a question about the PS50P3HS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung PS50P3HS

Summary of Contents for Samsung PS50P3HS

  • Page 1 PLASMA DISPLAY TV Chassis : D59A(P) Model : PS50P3HX/XEU PLASMA DIAPLAY TV C O N T E N T S Alignment and Adjustments Exploded View and Parts List Electric Parts List Schematic Diagrams...

  • Page 2: Alignment And Adjustments

    -. DVI -. PC -. PC Analog PC Dport -. RF -. RF - Auto gain (A-RGB) -. TTX -. TTX value(RGB) TTX Mode SIL169 (D-RGB) Different adjustment values will be applied to DVI, PC, RF and TTX mode. Samsung Electronics...
  • Page 3 1-1-2(C) ADJUSTMENT OF VIDEO (CVBS) & RF WHITE BALANCE 1. Adjust the timing to PAL-BDGI 780x576@50Hz with MSPG-925LTH, and load the Samsung White Balance pattern. (When adjusting with RF signals instead of MSPG-925LTH, use the Development Team’s UHF C21 Toshiba pattern.) Set the Digital NR to Picture [On] in the menu.
  • Page 4 Alignment and Adjustments 1-1-2(D) TTX MODE WHITE BALANCE ADJUSTMENT 1. Adjust the timing to PAL-BDGI 780x576@50Hz with MSPG-925LTH, and load the Samsung White Balance pattern. (When adjusting with RF signals instead of MSPG-925LTH, use the Development Team’s UHF C21 Toshiba pattern.) 2.
  • Page 5 RAST HSIZE B GAIN DE GAIN CLIP (90/90/60) SHARP OFFSET R,CR OFFSET CE UPPER CLK DLY G,Y OFFSET CE CUTOFF H_POSI B,CB OFFSET CE GAIN VIDEO PATH WTE Y THRE AUTO COLOR R CTL SYNC MODE PATT SEL Samsung Electronics...
  • Page 6 LAST MEMORY 1-1-4 Specifications of W/B Adjustment by Mode Video or RF Remark Set the [offset] for NTSC. Y(fL) SNI Contrast +14 Bright Logic R-Drive +3 G-Cutoff +1 B-Cutoff : -1(-4 Additional image Y(fL) 0.85 0.75 quality assessment12/28) Samsung Electronics...
  • Page 7 MEMO Samsung Electronics...
  • Page 8 BN94-00449A ASSY PCB MISC-ANALOG;PS42P3S/PS50P3H,D56 BN94-00451D ASSY PCB MISC-DIGITAL;PS50P3H/PS63P3H,D5 BN96-00173B ASSY COVER P-BACK;SPD-50P3H,AL5052 T1.2, BN96-00286B ASSY MISC P-BRACKET,TERMINAL;PS50P3H,D57 S.N.A 1-24 BN63-00358A COVER-BACK;50P3H,AL5052,T1.2,DGM-S810MG S.N.A 2-24 BN61-00202A BRACKET-HANDLE;42P3S,AL5052,T1.5,DGM-S81 S.N.A BN64-00137B DECORATION-BACK;SPD-50P3H,PC+ABS,5V S.N.A 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A 6001-000059 SCREW-MACHINE;TH,+,M4,L10,ZPC(BLK),SWRCH S.N.A 6006-001121 SCREW-ASS’Y MACH;WSP,PH,+,M4,L25,ZPC(BLK Samsung Electronics...

  • Page 9: Electrical Parts List

    Electrical Parts List You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr 3. Electrical Parts List 3-1 PS50P3HX/XEU Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification...
  • Page 10 ..4 FT200 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L133 3301-001593 CORE-FERRITE BEAD;AB,200OHM,2.0X1.2X1.3M ..4 FT201 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L134 3301-001593 CORE-FERRITE BEAD;AB,200OHM,2.0X1.2X1.3M ..4 FT202 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L300 2703-002327 INDUCTOR-SMD;3.9UH,55,3.2X2.5X2.2MM ..4 FT203 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L301 2703-002327 INDUCTOR-SMD;3.9UH,55,3.2X2.5X2.2MM Samsung Electronics...
  • Page 11 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 ..4 R333 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 ..4 R160 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 ..4 R335 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608 ..4 R161 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 ..4 R336 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608 ..4 R162 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 ..4 R338 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 ..4 R165 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608 ..4 R339 2007-000211 R-CHIP;1.1Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 12 0403-001052 DIODE-ZENER;RD8.2MB,8.2V,7.7-8.64V,200mW ..4 C1060 2402-000176 C-AL,SMD;10uF,20%,16V,GP,TP,4.3x4.3x5.4 ..4 ZD306 0403-001052 DIODE-ZENER;RD8.2MB,8.2V,7.7-8.64V,200mW ..4 C1061 2203-005005 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 BN94-00451D ASSY PCB MISC-DIGITAL;PS50P3H/PS63P3H,D5 ..4 C1062 2203-000384 C-CERAMIC,CHIP;0.015NF,5%,50V,C0G,TP,160 ...3 CN701 3711-003973 CONNECTOR-HEADER;BOX,11P,1R,2.5mm,STRAIG ..4 C1063 2203-000384 C-CERAMIC,CHIP;0.015NF,5%,50V,C0G,TP,160 ...3 CN702 3711-003272 CONNECTOR-HEADER;BOX,10P,2R,2.54mm,STRAI ..4 C1064 2203-000384 C-CERAMIC,CHIP;0.015NF,5%,50V,C0G,TP,160 Samsung Electronics...
  • Page 13 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C1307 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 ..4 C1165 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C1308 2402-000176 C-AL,SMD;10uF,20%,16V,GP,TP,4.3x4.3x5.4 ..4 C1166 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C1309 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,- ..4 C1167 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C1310 2203-000236 C-CERAMIC,CHIP;0.1NF,5%,50V,C0G,TP,1608 ..4 C1168 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C1313 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 Samsung Electronics...
  • Page 14 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C729 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, ..4 C609 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C730 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, ..4 C610 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C731 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, ..4 C611 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C732 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, ..4 C612 2203-000626 C-CERAMIC,CHIP;0.022NF,5%,50V,C0G,TP,160 ..4 C733 2203-001652 C-CERAMIC,CHIP;470nF,+80-20%,16V,Y5V,TP, Samsung Electronics...
  • Page 15 2203-001656 C-CERAMIC,CHIP;0.47nF,5%,50V,NP0,TP,1608 ..4 C966 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608 ..4 C828 2402-000176 C-AL,SMD;10uF,20%,16V,GP,TP,4.3x4.3x5.4 ..4 C967 2402-000176 C-AL,SMD;10uF,20%,16V,GP,TP,4.3x4.3x5.4 ..4 C829 2203-000843 C-CERAMIC,CHIP;39nF,10%,25V,X7R,TP,1608, ..4 C968 2402-000176 C-AL,SMD;10uF,20%,16V,GP,TP,4.3x4.3x5.4 ..4 C830 2203-000726 C-CERAMIC,CHIP;3.9nF,10%,50V,X7R,TP,1608 ..4 C969 2203-005005 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,1608 ..4 C831 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP, ..4 C972 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608 Samsung Electronics...
  • Page 16 INDUCTOR-SMD;3.3UH,20%,3.2X2.5X2.2MM ..4 FT526 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L1200 3301-001404 CORE-FERRITE BEAD;AB,30ohm,20x1.25x1mm,2 ..4 FT527 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L1300 2703-001334 INDUCTOR-SMD;1.5uH,10%,2x1.25x0.85mm ..4 FT528 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L1301 2703-001334 INDUCTOR-SMD;1.5uH,10%,2x1.25x0.85mm ..4 FT529 2901-001119 FILTER-EMI SMD;25V,100mA,-,-,3.2x1.6x1,T ..4 L1302 2703-001334 INDUCTOR-SMD;1.5uH,10%,2x1.25x0.85mm Samsung Electronics...
  • Page 17 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 ..4 R1229 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 ..4 R1043 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608 ..4 R1230 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 ..4 R1044 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R1231 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 ..4 R1045 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R1232 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 ..4 R1046 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R1233 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608 Samsung Electronics...
  • Page 18 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R702 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 ..4 R531 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R703 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608 ..4 R532 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R704 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608 ..4 R533 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R705 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 ..4 R534 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R706 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608 3-10 Samsung Electronics...
  • Page 19 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R987 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 ..4 R905 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R988 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 ..4 R906 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R989 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 ..4 R907 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R990 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608 ..4 R908 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608 ..4 R991 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608 Samsung Electronics 3-11...
  • Page 20 ASSY COVER FRONT;PS50P3HX/XEC,D59A S.N.A ...3 RM101 AA32-00013B MODULE REMOCON;346HF5,38KHz,940mm,MESH,H ...3 SW101 3404-000115 SWITCH-TACT;12V,50MA,160GF,6X6X7.85MM,SP ..2 A/C/CO 6006-001035 SCREW-ASS’Y MACH;WSP,PH,+,M3,L8,ZPC(YEL) S.N.A ...3 SW102 3404-000115 SWITCH-TACT;12V,50MA,160GF,6X6X7.85MM,SP ..2 A/V/B+ 6006-001035 SCREW-ASS’Y MACH;WSP,PH,+,M3,L8,ZPC(YEL) S.N.A ...3 SW103 3404-000115 SWITCH-TACT;12V,50MA,160GF,6X6X7.85MM,SP ..2 B/F/B+ 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A 3-12 Samsung Electronics...
  • Page 21 CARD-REGISTRATION;XEU,ENG,MOJO100,L150,W S.N.A ..2 S/N AA68-20051A MANUAL-S/NETWORK;ALL,W/P 100(G),B5,ENG,S S.N.A BH39-00228A CBF POWER CORD;DT15LS,S89354,H05VV-F 3G* BN39-00315A LEAD CONNECTOR;D54A/SPD-42P3S,UL1007#24, BN39-00360A CBF IF-RF CABLE;PS50P3H,1P,3C-2V,3000mm, BN68-00361A MANUAL-GUIDE;WML200/300/420/500,EN,FR,GE S.N.A BN69-00428A BOX-ACCESSORY;PDP,CB SW-1,E,YEL,KSD-21,5 S.N.A BN68-00420A MANUAL-GUIDE;PDP,ENG/KOR/FRE/ES,B5,W/MOU S.N.A BN68-00380A MANUAL USERS;PS42P3S/PS50P3H,EN,W/P100G, AA59-00268C REMOCON;,TM63,PDP,52,G6671B,TTX,E/X 3301-001110 CORE-FERRITE;ZZ,35x19.5x9.0mm,-,- Samsung Electronics 3-13...
  • Page 22 Electrical Parts List MEMO 3-14 Samsung Electronics...
  • Page 23 Italy Delete TP27 TP28 ED DATE P_A0 JUN 12th,2002 JUL 22th,2002 ZD115 ZD116 ZD117 ZD118 RLZ8.2 RLZ8.2 RLZ8.2 RLZ8.2 Model : ZD119 ZD120 ZD121 ZD122 Alexander_PAL RLZ8.2 RLZ8.2 RLZ8.2 RLZ8.2 Sheet Title : 2_A1_Tuner&Input Connector REF.NO CODE.NO SHEET.NO 2/12 Samsung Electronics...
  • Page 24 C133 R173 P_A0 May 20th,2002 JUL 22th,2002 CVBS_OUT R177 FT219 10uF C140 LFA30-2A1E473MT SCT_BL_IN SCT_CVBS_OUT Q109 CVBS_OUT2 KSC1623-G R161 Model : Alexander_PAL R162 SCT2_CVBS_OUT R182 FT222 R183 Sheet Title : LFA30-2A1E473MT SCT2_B-PB2 3_A2__Toshiba COMB REF.NO CODE.NO SHEET.NO 3/12 Samsung Electronics...
  • Page 25 ED DATE 4.7K R364 P_A0 May 20th,2002 JUL 22th,2002 R365 R368 C404 100nF R371 Q303 MUTE ZD305 Model : Alexander_PAL KSC1623-G 4.7K RLZ8.2 ZD306 R372 100uF 4.7K C405 RLZ8.2 Sheet Title : 4_A3_Audio (MSP3451G) REF.NO CODE.NO SHEET.NO 4/12 Samsung Electronics...
  • Page 26 TP999 FT527 SCT_R_C-PR TP983 TP992 LFA30-2A1E473MT FT523 TP1000 PC_SL TP984 LFA30-2A1E473MT Model : Alexander_PAL FT528 LFA30-2A1E473MT SCT_BL_IN Y_MAIN FT530 FT526 LFA30-2A1E473MT Sheet Title : LFA30-2A1E473MT PC_SR FT529 SCT2_B-PB2 5_D1_Video Decoder (VSP9437) LFA30-2A1E473MT FT531 LFA30-2A1E473MT REF.NO CODE.NO SHEET.NO 5/13 Samsung Electronics...
  • Page 27 23SDD(21) 23SDD(26) 23SDA(0:10) DQ21 DQ26 R642 23SDD(22) 23SDD(25) DQ22 DQ25 23SDD(0:31) VDDQ4 VSSQ5 23SDD(23) 23SDD(24) DQ23 DQ24 43 VDD4 VSS1 DATE P_A0 Jun 12th,2002 Jul 22th,2002 Model : Alexander_PAL Sheet Title : Video Deinterlacer(FLI2300) REF.NO CODE.NO SHEET.NO 6/13 Samsung Electronics...
  • Page 28 THER_D C773 C774 C775 C776 FT703 TP923 TP924 220uF 100nF 220uF 100nF LFA30-2A1E223MT DATE P_A0 Jun 12th,2002 Jul 22th,2002 IC707 Model : Alexander_PAL LF25CDT C777 C778 220uF 100nF Sheet Title : TTX Mixing&SCP IC(CXA2101) REF.NO CODE.NO SHEET.NO 7/13 Samsung Electronics...
  • Page 29 ASI_SUB_R(0:7) IC801 D806 NM24C02M8 TP24 ASI_SUB_CLK PMLL4148 C843 100nF ASI_SUB_H D807 ASI_SUB_SOG PMLL4148 R836 AD9883_IN_V ASI_SUB_V R837 COMP_MODE_DET AD9883_IN_H DATE P_A0 Jun 12th,2002 Jul 22th,2002 Model : Alexander_PAL Sheet Title : 8_D4_PC,DTV Analog,DVI Input REF.NO CODE.NO SHEET.NO 8/13 Samsung Electronics...
  • Page 30 R1038 S_VHS_DET R1039 R1229 ZD904 ZD905 PC_DET DVI_DET RLZ8.2 RLZ8.2 R1230 R1231 THER_D R1232 R1233 TP949 R1234 Model : Alexander_PAL ZD907 ZD906 RLZ8.2 RLZ8.2 SERVICE TP951 TP952 Sheet Title : Flash Memory Download 9_D5_Mega_TTX&MiCOM(M2) REF.NO CODE.NO SHEET.NO 9/13 Samsung Electronics...
  • Page 31 TP933 TP934 HPDR R1092 R1093 C1076 R1094 22uF C1078 C1077 100nF 100nF ZD1002 ZD1004 RLZ8.2 RLZ8.2 ZD1003 ZD1005 RLZ8.2 RLZ8.2 DATE P_A0 Jun 12th,2002 Jul 22th,2002 Model : Alexander_PAL Sheet Title : 10_D6_Scaler (ASI500) REF.NO CODE.NO HEET.NO 10/13 Samsung Electronics...
  • Page 32 SNI_DQ(58) SNI_DQ(54) DQ22 DQ25 SNI_DQ(57) VDDQ4 VSSQ5 SNI_DQ(55) DQ23 DQ24 SNI_DQ(56) VDD4 VSS1 C1175 C1176 C1177 15pF 15pF 15pF DATE P_A0 Jun 12th,2002 Jul 22th,2002 Model : Alexander_PAL Sheet Title : 11_D7_SNI,LVDS Output REF.NO CODE.NO SHEET.NO 11/13 4-10 Samsung Electronics...
  • Page 33 BOUTB3 BOUTB4 BOUTB5 50" OPTION for OSD BOUTB6 BOUTB7 R1217 DATACK DATACK_ DATE C1251 47uF SOGOUT P_A0 Jun 12th,2002 Jul 22th,2002 100nF HSOUT R1218 Model : Alexander_PAL Sheet Title : 12_D8__AD9884&Buffer For OSD REF.NO CODE.NO SHEET.NO 12/13 Samsung Electronics 4-11...
  • Page 34 R1334 R1335 FT1310 4.7K 4.7K SGM32F1E104-2A +3.3V R1336 DDC_SDA DDC_SDAT Q1300 2N7002L R1337 DDC_SCL DDC_SCLT FT1309 Q1301 SGM32F1E104-2A 2N7002L DATE P_A0 Jun 12th,2002 Jul 22th,2002 Model : Alexander_PAL Sheet Title : 13_D_ (Sil169) REF.NO CODE.NO SHEET.NO 13/13 4-12 Samsung Electronics...
  • Page 35 Schematic Diagrams 4-13 SMPS 1 Samsung Electronics 4-13...
  • Page 36 Schematic Diagrams 4-14 SMPS 2 4-14 Samsung Electronics...
  • Page 37 Schematic Diagrams 4-15 SMPS 3 Samsung Electronics 4-15...
  • Page 38 Schematic Diagrams 4-16 SMPS 4 4-16 Samsung Electronics...
