PLASMA DISPLAY TV Chassis : D68A(P)Europe 50” Model PS50P4HX/XEC SERVICE Manual PLASMA DISPLAY TV C O N T E N T S Specifications Alignment and Adjustments Exploded View and Parts List Service Item Schematic Diagrams...
Page 5
To increase and decrease the data of the selected items (ENTER) Confirm your choice(Store OR Enter) SOURCE button Change input source ♣ ♣ While in Tuner mode, the direct access buttons can be used to select and change channels. Samsung Electronics...
Page 6
The video signal uses the video port when there is no other input signal. However, signal uses the graphic port in PIP mode, which includes other input signals (PC, DVI, Component, etc.), Video adjustment should be performed with Video portand Graphic port separately. Samsung Electronics...
Page 7
- PC - PC - Video Graphic - Video Analog PC - Component(DTV) Port - Component(DTV) - Auto Color (A-RGB) value(RGB) DTV Mode SIL169 (D-RGB) Different adjustment values will be applied to DVI, PC ,DTV(Component) and Video mode. Samsung Electronics...
Page 8
05. Y/C Delay Y/C Delay Setting according to the System and Input Modes √ 06. Motion Motion Enhancing Adjustment √ 07. DNIe DNIe Registers √ 08. Logic Logic Registers of the Panel √ 09. Picture Size Picture Size Registers Samsung Electronics...
Page 9
07.Sub Contrast DNIe 08.Sub Brightness 09.R Gain 10.G Gain 11.B Gain AD9883 12.R/Cr Offset 13.G/Y Offset 14.B/Cb Offset 15.Auto color on/off Input modes require respective storing the changes after adjustment. 01~06 : Logic 07~08 : DNIe 09~15 : AD9883 Samsung Electronics...
Page 10
09. B Gamma 10. Gain-Sel 11. Cr Gain CXA2151Q 12. Cb Gain 13. Y Gain 14. FLI-Y/G Bir FLI2310 15. FLI-Cr/R Bir 16. FLI-Cb/B Bir 01 ~05 : VSP9437 07~09 : ASI510 06 , 14~16 : FLI2310 10~13 : CXA2151Q Samsung Electronics...
Page 14
13. CTI GAIN 14. DE NOISE GAIN 15. TH CORING 16. PATT SEL 17. NOISE TH2 18. H CONT 19. V CONT 20. BLACK GAIN 21. WHITE GAIN 22. WTE GAIN 23. CTE GAIN 01~23 : DNIe 2-10 Samsung Electronics...
Page 16
03. Movie 04. Custom 02.Initial Setting => 02.P-Mode Value 02. P-Mode Value Current Input Mode √ Available options for the PC/DVI Mode are High,Middle, 01. Dynamic Low and Custom. √ 02. Standard √ 03. Movie √ 04. Custom 2-12 Samsung Electronics...
Page 17
Available Settings for the PC Mode are 02.Initial Setting Current Input Mode Custom,Color Tone 1, Color Tone 2, Color Tone 3 01. Cool2 02. Cool1 Available options for the DVI Mode are 03. Normal ColorTone1, ColorTone2, ColorTone3 04. Warm1 05. Warm2 Samsung Electronics 2-13...
Page 19
- Language Group is Europe : 18 languages (English=>Bulgarian=>Croatian=>Czechoslovak=>Netherlandish=>French=>German=>Greek=>Hungarian=> Italian=>Poland=>Portuguese=>Rumanian=>Russian=>Spanish=>Swedish=>Turki=>Yugoslave) - Language Group is Asia : 7 languages (English=>Arabic=>French=>Indonesian=>Malay=>Persian=>Chinese) 06. ATM : On => Off -. ATM available region : On -. ATM non-available region : Off Samsung Electronics 2-15...
Page 20
03. Upper, low movement Pixel 02. Pixel Number 04. Shift Test 03. Shift Line 04. Shift Time 05. Number Range 06. Line Range 07. Temp Protection 08. DNIe DEMO 09. PILOT HIGH 10. PILOT LOW 11. CHECKSUM 0000 2-16 Samsung Electronics...
Page 22
CN812 CN806 CN 806 Pin No. 1, 2 Notes 1. When the SMPS-PCB is replaced, the Va, Vsc, Vs, Ve and Vset voltages must be checked and adjusted to the proper levels indicated on the panel sticker. 2-18 Samsung Electronics...
Page 26
Schematic Diagrams 5. Schematic Diagrams 5-1 SCART(Digital PCB) This Document can not be used without Samsung’s authorization. R110,R140 NTSC &PAL COMMON APPLY NTSC & PAL R110,R140 NTSC &PAL COMMON APPLY Samsung Electronics...
Page 27
Schematic Diagrams 5-2 VIDEO SW(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 28
Schematic Diagrams 5-3 VSP9437(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 29
Schematic Diagrams 5-4 PCIN 9883 2151(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 30
Schematic Diagrams 5-5 FLI2310(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 31
Schematic Diagrams 5-6 ASI510(Digital PCB) This Document can not be used without Samsung’s authorization. ASI510 Samsung Electronics...
Page 32
Schematic Diagrams 5-7 DVI SII169(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 33
Schematic Diagrams 5-8 POWER(Digital PCB) This Document can not be used without Samsung’s authorization. +5V_ST CN1204 slcon3p Samsung Electronics...
Page 34
Schematic Diagrams 5-9 JACK INPUT(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics...
Page 35
Schematic Diagrams Schematic Diagrams 5-10 SDA6001(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics 5-10...
Page 36
Schematic Diagrams 5-11 DNIe2(Digital PCB) This Document can not be used without Samsung’s authorization. 5-11 Samsung Electronics...
Page 37
Schematic Diagrams 5-12 AUDIO(Digital PCB) This Document can not be used without Samsung’s authorization. Samsung Electronics 5-12...
Page 38
Schematic Diagrams 5-13 TUNER This Document can not be used without Samsung’s authorization. +5V_R +33V +33V +5V_TUNER CN101 +9V_R BD101 HH-1H4532-121JT HH-1H4532-121JT WOOPER MONO BD102 C102 C103 10uF 100nF R101 C104 100uF SIF2 SIF1 MGND1 RF_SUB MGND2 RF_MAIN AFT2 AFT1...
Page 39
Schematic Diagrams 5-14 SIDE A/V This Document can not be used without Samsung’s authorization. BD101 CN102 BFS3557AOLS1 slcon12p R101 V2_DET V2_CVBS C101 1/8W 100pF V2_DET SK101 S-VHS2_DET BD102 BFS3557AOLS1 V2_SL V2_CVBS C102 100pF V2_SR BD103 BFS3557AOLS1 V2_SL S-VHS2_Y C103 R102...
