- Page 1 Air conditioner Installation manual AN D • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this user manual carefully and retain it for future reference.
-
Page 3: Table Of Contents
A Contents Safety precautions ..............................3 Accessories ..................................5 Selecting the installation location ..........................5 Indoor unit installation ............................10 Purging the unit ............................... 11 Charging additional refrigerant ........................... 11 Connecting the refrigerant pipe .......................... 12 Cutting/flaring the pipes ............................13 Performing leak test & insulation ........................14 Drain pipe and drain hose installation ....................... -
Page 4: A Safety Precautions
This manual explains how to install an indoor unit with a split system with two SAMSUNG units. The use of other types of units with different control systems may damage the units and invalidate the warranty. The manufacturer shall not be responsible for damages arising from the use of non compliant units. -
Page 5: Safety Precautions
Safety precautions Our units must be installed in compliance with the spaces indicated in the installation manual to ensure either accessibility from both sides or ability to perform routine maintenance and repairs. The units’ components must be accessible and that can be disassembled in conditions of complete safety either for people or things. For this reason, where it is not observed as indicated into the Installation Manual, the cost necessary to reach and repair the unit (in safety, as required by current regulations in force) with slings, trucks, scaffolding or any other means of elevation won’t be considered in-warranty and charged to end user. -
Page 6: Accessories
A Accessories The following accessories are supplied with the indoor unit. The type and quantity may differ depending on the specifications. Insulation cover Thermal insulation A Thermal insulation B Thermal insulation (use for refrigerant pipe) (use for refrigerant pipe) (use for drain hose) User's manual Installation manual Flexible hose clamp... - Page 7 A Selecting the installation location Space requirements for installation & service Construction Standard for Inspection Hole. 1) In case, the ceiling is textile, Inspection hole dose not need. 2) In case, the ceiling is plaster board, Inspection hole depends on Inside height of the ceiling. a.
- Page 8 AM006/007/009/012/015ANMD Unit : inch(mm) (Drain pump built-in) hole 7x3.937=27.56(7x100=700) 22-ø0.13(3.2) (Air outlet duct flange) (Air around) 32.17(817) Inspection hole 33.46(850) 35.43(900) (Suspension position) 33.46(850) 37.40(950) 19.69(500) 8.39(213) 4.92(125) 13.39(340) Discharge side Suction side Name Description Liquid pipe connection ø1/4"(6.35) Gas pipe connection ø1/2"(12.70) Drain pipe connection 3/4"(ODØ1.05"(26.67))
- Page 9 Selecting the installation location AM018ANMD Unit : inch(mm) AM024/027/030ANHD (Drain pump built-in) 11x3.937=43.31(11x100=1100) hole 30-ø0.13(3.2) (Air outlet duct flange) 45.94(1167) (Air around) 47.24(1200) Inspection hole 49.21(1250) (Suspension position) 47.24(1200) 51.18(1300) 19.69(500) 8.39(213) 4.92(125) 13.39(340) Discharge side Suction side Name Description Liquid pipe connection :ø1/4"(6.35), 024/027/030 : ø3/8"(9.52)
- Page 10 AM036/048ANHD Unit : inch(mm) (Drain pump built-in) 11x3.937=43.31(11x100=1100) hole 30-ø0.13(3.2) 49.92(1268) (Air outlet duct flange) (Air around) 51.18(1300) Inspection hole 53.15(1350) (Suspension position) 51.18(1300) 55.12(1400) 19.69(500) 8.39(213) 4.92(125) 13.39(340) Discharge side Suction side Name Description Liquid pipe connection ø3/8"(9.52) Gas pipe connection ø5/8"(15.88) Drain pipe connection 3/4"(ODØ1.05"(26.67))
- Page 11 A Indoor unit installation It is recommended to install the Y-joint before installing the indoor unit. Place the pattern sheet on the ceiling at the spot where you want to install the indoor unit. Note Since the diagram is made of paper, it may shrink or stretch slightly due to temperature or humidity.
-
Page 12: Purging The Unit
Purging the unit ANMD / AM ANHD On delivery, the indoor unit is loaded with inert gas. All this gas must therefore be purged before connecting the assembly piping. To purge the inert gas, proceed as follows. Unscrew the pinch pipe at the end of each refrigerant pipe. Result: All inert gas escapes from the indoor unit. -
Page 13: Connecting The Refrigerant Pipe
A C onnecting the refrigerant pipe There are two refrigerant pipes of differing diameters: Refrigerant oil A smaller one for the liquid refrigerant A larger one for the gas refrigerant The inside of copper pipe must be clean & has no dust. The connection procedure for the refrigerant pipes varies according to the exit position of the pipes from the indoor unit, as seen when facing the indoor in the “A”... -
Page 14: Cutting/Flaring The Pipes
A Cutting/flaring the pipes Make sure that you prepared the required tools. (pipe cutter, reamer, flaring tool and pipe holder) If you want to shorten the pipe, cut it using a pipe cutter ensuring that the cut edge remains at 90° with the side of the pipe. There are some examples of correctly and incorrectly cut edges below. - Page 15 A Performing leak test & insulation Leak test LEAK TEST WITH NITROGEN (before opening valves) In order to detect basic refrigerant leaks, before recreating the vacuum and recirculating the R410A, it’s responsible of installer to pressurize the whole system with nitrogen (using a pressure regulator) at a pressure above 4.1MPa(594.7 PSI) (gauge).
- Page 16 Select the insulator of the refrigerant pipe. Insulate the gas side and liquid side pipe referring to the thickness according to the pipe size. Indoor temperature of 30°C (86°F) and humidity of 85% is the standard condition. If install in a high humidity condition, use one grade thicker insulator by referring to the table below.
-
Page 17: Performing Leak Test & Insulation
Performing leak test & insulation Caution Install the insulation not to get wider and use the adhesives on the connection part of it to prevent moisture from entering. Wind the refrigerant pipe with insulation tape if it is exposed to outside sunlight. Install the refrigerant pipe respecting that the insulation does not get thinner on the bent part or hanger of pipe. - Page 18 A D rain pipe and drain hose installation Drainpipe Connection Without the drain pump Install horizontal drainpipe with a slope of 1/100 or more and fix it by hanger space of 3.28~4.92ft(1~1.5m). Install U-trap at the end of the drainpipe to prevent a nasty smell to reach the indoor unit. Do not install the drainpipe to upward position.
- Page 19 Drain pipe and drain hose installation Centralized Drainage Without the drain pump Install horizontal drainpipe with a slope of 1/100 or more and fix it by hanger space of 3.28~4.92ft(1~1.5m). Install U-trap at the end of the drainpipe to prevent a nasty smell to reach the indoor unit. Horizontal drainpipe more than 1/100 slope Ceiling...
- Page 20 Testing the drainage ANMD / AM ANHD Prepare a little water about 2 liters. (Drain pump built-in) Loosen screws and take out the side cover plate. Pour water into the indoor unit as shown in figure. Note Drainage test should be done after installation has been finished.
- Page 21 A Wiring work Power and communication cable connection Before wiring work, you must turn off all power source. Indoor unit power should be supplied through the breaker( ELCB or MCCB+ELB ) separated by the outdoor power. ELCB: Earth Leakage Circuit Breaker MCCB: Molded Case Circuit Breaker ELB: Earth Leakage Breaker The power cable should be used only copper wires.
- Page 22 Specification of electronic wire Power supply MCCB ELB or ELCB Power cable Earth cable Communication cable Max : 253V X A, 30mA 0.0039inch 0.0039inch 0.0012~0.0023inch Min : 187V 0.1 sec (2.5mm (2.5mm (0.75~1.5mm Decide the capacity of ELCB (or MCCB+ELB) by below formula. The capacity of ELCB (or MCCB+ELB) X [A] = 1.25 X 1.1 X ∑Ai X : The capacity of ELCB (or MCCB+ELB).
-
Page 23: Wiring Work
Wiring work(Cont.) Rating current Unit Model Rating current Unit Model Rating current AM ANMD 0.30A AM ANHD 0.70A 0.30A 0.80A 0.30A 1.20A 0.30A 1.20A 0.40A 1.50A 0.50A Caution Select the power cable in accordance with relevant local and national regulations. Wire size must comply with local and national code. - Page 24 Wiring diagram ° ° Read the instructions. USE COPPER SUPPLY WIRES.
- Page 25 A Setting an indoor unit address and installation option Set the indoor unit address and installation option with remote controller option. Set the each option separately since you cannot set the ADDRESS setting and indoor unit installation setting option at the same time. You need to set twice when setting indoor unit address and installation option. Setting an indoor unit address (MAIN/RMC) Check whether power is supplied or not.
- Page 26 Setting an indoor unit installation option (suitable for the condition of each installation location) Check whether power is supplied or not. - When the indoor unit is not plugged in, there should be additional power supply in the indoor unit. The panel(display) should be connected to an indoor unit to receive option.
-
Page 27: Setting An Indoor Unit Address And Installation Option
Setting an indoor unit address and installation option (Cont.) The output of hot water heater in SEG9 is generated from the hot coil part of the terminal board in duct models. * The output of hot coil terminal is AC 220 V / 230 V (The same as Indoor Unit’s input Power) L(L1)N(L2) COM1... - Page 28 Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 Use of external Setting the output of external control Explanation PAGE Hours of filter usage control / External heater On/Off signal Details Setting the External Indication Details Indication Details Indication Indication Details output of heater On/Off external signal...
- Page 29 Setting an indoor unit address and installation option (Cont.) Advanced function: Controlling cooling/heating current or power saving with motion detect. (*1) Minimizing fan operation when thermostat is off - Fan operates for 20 seconds at an interval of 5 minutes in heat mode. (*2) 1: Fan is turned on continually when the hot water heater is turned on, 3: Fan is turned off when the hot water heater is turned on with cooling only indoor unit Cooling only indoor unit: To use this option, install the Mode Select switch(MCM-C200) on the outdoor unit and fix it as cool mode.
- Page 30 05 series installation option(Detailed) Option No. : 05XXXX-1XXXXX-2XXXXX-3XXXXX Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 (When setting SEG3) Use of Auto Change (When setting SEG3) (When setting SEG3) Standard for mode PAGE MODE Explanation Over for HR only in Standard heating Standard cooling temp.
- Page 31 Setting an indoor unit address and installation option (Cont.) (*3) Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 Explanation Control variables when using hot water / external heater Details Indication Set temp. for heater On/Off Delay time for heater On At the same time as thermo on No delay 10 minutes At the same time as thermo on...
- Page 32 SEG 3, 4, 5, 6, 8, 9 additional information When the SEG 3 is set as "1" and follow Auto Change Over for HR only operation, it will operate as follows. Standard temp. for Temp. → Heating Cooling Standard temp. for Cooling Set temp.
-
Page 33: Setting Temperature Control Of Discharge Air
Setting temperature control of discharge air 1. Use of “Temperature control of discharge air” or target temperature of discharge air in cooling/heating can be set with the service mode of a wired remote controller. (Refer to the installation manual of a wired remote controller.) 2. -
Page 34: Providing Information For User
Providing information for user After finishing the installation of the air conditioner, you should explain the following to the user. Refer to appropriate pages in the user & installation manual. How to start and stop the air conditioner How to select the modes and functions How to adjust the temperature and fan speed How to adjust the airflow direction How to set the timers... -
Page 35: Adjusting Air Flow
A Adjusting air flow Automatic Air-Volume When multi indoor units are installed, Automatic Air-Volume function cannot be performed simultaneously for all indoor units. Automatic Air-Volume function must be performed for each indoor unit with the wired remote con- trol attached. With its BLDC motor, you can use smart adjust the indoor unit fan speed depending on the installation condition. - Page 36 Automatic Air - Volume Service mode Room Temperature Calibration Indoor unit status information Status Operation Voltage Discharge Temperature Disabled 220V Stop Deleted Automatic Air - Volume Stop Stop (v.4.8) Ventilator ERV option Press the OK button to complete the setting. Automatic Air - Volume Automatic Air - Volume Status...
- Page 37 A A djusting air flow(Contiued) E.S.P(External Static Pressure)setting for phase control motor With its phase control motor,you can adjust the indoor unit fan speed depending on the installation condition. If the external static pressure is high so that the duct becomes longer or if the external static pressure is low so that the duct becomes shorter,adjust the fan speed by referring the following table.
- Page 38 Note represents E.S.P(External Static Pressure)range of factory setting. You don’t have to adjust the fan speed separately if the external static pressure of the installation place is in . When it is out of , input the appropriate option code. If you input the inappropriate option code,error may occur or the air conditioner is out of order.
-
Page 39: Extending The Power Cable
A E xtending the power cable 1. Prepare the following tools. Tools Crimping pliers Connection sleeve Insulation tape Contraction tube 20xØ0.26 inch(6.5 70xØ0.31 inch(8.0 Width 0.75 inch(19 Spec MH-14 (HxOD) (LxOD) Shape 2. As shown in the figure, peel off the shields from the rubber and wire of the power cable. - Page 40 1. Wrap it with the insulation tape twice or more and position your contraction tube in the middle of the insulation tape. Three or more layers of insulation are required. Method 1 Method 2 Insulation tape Insulation tape 1.57 inch 1.38 inch (40 mm) (35 mm)
- Page 41 DB68-09470A-01...
