  • Page 1 USER MANUAL CROSS MOUNT SOLO...

  • Page 2: Spare Parts

    COMPONENTS Top cross bar: 2ea Spring washer: 16ea M6 bolt torx head: 16ea Side bracket: 4ea M6 T-nut: 16ea Torx T30IP wrench: 1ea SPARE PARTS: M6 T-nut: 4 ea Spring washer: 2 ea M6 bolt torx head: 2 ea Page 1...
  • Page 3 INSTALLING THE CROSS MOUNT SOLO 2. CROSSBAR & 1. 4 T-NUTS INSERTION SIDE BRACKET ASSEMBLY Insert x2 T-Nuts into the groove of the After mounting the side bracket to top frame where you want to install the crossbar, adjust x2 bolts and the Top Crossbar Side Bracket.
  • Page 4 DIMENSION Two indication lines have been etched on both bottom ends of the crossbar to make sure that side brackets are fully inserted when mounting. Lines should not be visible after assembly. Laser line on both ends 1.3” (32.5mm) 1.3” (32.5mm) 33.3”...
