L M 3 S 6 9 6 5 E V A L U A T I O N K I T
R E A D M E F I R S T
Stellaris® LM3S6965 Evaluation Kit
The Stellaris LM3S6965 Evaluation Kit for Ethernet provides a low-cost way to start
designing Ethernet applications with Stellaris microcontrollers. The LM3S6965 Evaluation
Board (EVB) can function as either a complete evaluation target, or as a debugger interface to
any external Stellaris device. The included USB cable is all that is needed to provide power
and communication to the host PC.
LM3S6965 Evaluation Board
Requirements
You have a PC, with a USB interface, running Microsoft® Windows 2000. XP, or Vista
You have the Stellaris LM3S6965 Evaluation Kit Documentation and Software CD
Board Set-Up
The LM3S6965 Evaluation Board is configured for immediate use. To power the EVB, use
the USB cable supplied in the kit. Connect the mini-b (smaller) end of the USB cable to the
connector labeled "USB TO JTAG/SWD" on the EVB. Connect the other end (Type A) to a
free USB port on your host PC. The USB is capable of sourcing up to 500 mA for each
attached device, which is sufficient for the evaluation board. If connecting the board through a
USB hub, it must be a powered hub.
Rev. 1.5
1
Advertisement
Related Manuals for Stellaris LM3S6965
Summary of Contents for Stellaris LM3S6965
- Page 1 Ethernet applications with Stellaris microcontrollers. The LM3S6965 Evaluation Board (EVB) can function as either a complete evaluation target, or as a debugger interface to any external Stellaris device. The included USB cable is all that is needed to provide power and communication to the host PC.
- Page 2 L M 3 S 6 9 6 5 E V A L U A T I O N K I T R E A D M E F I R S T When you plug in the EVB for the first time, Windows starts the Found New Hardware Wizard and asks if Windows can connect to Windows Update to search for software.
- Page 3 L M 3 S 6 9 6 5 E V A L U A T I O N K I T R E A D M E F I R S T Next, the Found New Hardware Wizard asks from where to install the software. Select “Install from a list or specific location (Advanced)”...
- Page 4 L M 3 S 6 9 6 5 E V A L U A T I O N K I T R E A D M E F I R S T Make sure the “Documentation and Software” CD that came with the Evaluation Kit is in your CD-ROM drive.
- Page 5 L M 3 S 6 9 6 5 E V A L U A T I O N K I T R E A D M E F I R S T A warning may pop up during the Hardware Installation like the one below; click Continue Anyway.
- Page 6 Found New Hardware Wizard window appears like the one below. Click Finish to close the dialog box. You have just installed the drivers for “Stellaris Evaluation Board A.” The USB device built into the EVB is a composite USB device. After you click Finish, Windows automatically installs a driver for the “Stellaris Evaluation Board B”...
-
Page 7: Quickstart Application
Exit either mode of screen saver by pressing the user pushbutton (SELECT). Press the button again to start the game. The LM3S6965 microcontroller contains an Ethernet controller, which is also used by the game. During the game, a user can attach the board to a LAN. If there is a DHCP server present on the LAN, the board attempts to obtain an IP address from the DHCP server. - Page 8 IP address as 169.254.19.60 and your subnet mask to 255.255.0.0, as shown below. Now you can connect your host machine directly to the LM3S6965 evaluation board with the Ethernet cable provided in the evaluation kit. The integrated PHY on the LM3S6965 has an Auto-MDX feature which allows you to use a straight-though or cross-over Ethernet cable.
- Page 9 4) Click on the + symbol to expand the Ports (COM & LPT) group. “Stellaris Virtual COM Part (COM#)” is listed as shown in the figure below. This COM# is the device you connect to using your terminal application. In this example, the COM port is COM13 Rev.
-
Page 10: Software Development Tools
StellarisWare® Driver Library User’s Manual Stellaris LM3S6965 Microcontroller Data Sheet Copyright © 2007–2010 Texas Instruments, Inc. All rights reserved. Stellaris and StellarisWare are registered trademarks of Texas Instruments. ARM and Thumb are registered trademarks, and Cortex is a trademark of ARM Limited. Other names and brands may be claimed as the property of others. -
