Delta Electronics SISH85 Specification Sheet

SMT Power Inductor
SISH85 Type
Features
RoHS compliant.
Low profile (5.2mm max. height) SMD type.
Unshielded.
Self-leads, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.

Mechanical Dimension:

B
A

Electrical Characteristics:

PART NO.
(uH)
SISH85 - R33 0.33
SISH85 - R68 0.68
SISH85 - 1R0 1.00
SISH85 - 1R5 1.50
SISH85 - 2R2 2.20
SISH85 - 2R7 2.70
SISH85 - 3R3 3.30
SISH85 - 4R7 4.70
SISH85 - 6R8 6.80
SISH85 - 100 10.00
SISH85 - 150 15.00
SISH85 - 220 22.00
SISH85 - 330 33.00
SISH85 - 470 47.00
SISH85 - 680 68.00
SISH85 - 101 100.00
SISH85 - 151 150.00
SISH85 - 221 220.00
SISH85 - 331 330.00
SISH85 - 471 470.00
SISH85 - 681 680.00
SISH85 - 102 1000.00
1. Tolerance of inductance: 20%.
2. Isat is the DC current which cause the inductance drop less than 10% of its nominal inductance without current.
3. Ir is the DC current which cause the surface temperature of the part increase less than 45
4. Operating temperature : -20
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
F
C
E
D
o
25 : 100KHz, 0.1V C
2
1
DCR
L Isat
(m )MAX (Adc)
2.0 20.0
5.0 13.0
6.0 11.0
8.0 9.0
11.0 7.8
12.0 7.0
14.0 6.4
18.0 5.4
27.0 4.6
38.0 3.8
46.0 3.0
85.0 2.6
100.0 2.0
140.0 1.6
200.0 1.4
280.0 1.2
400.0 1.0
610.0 0.8
1020.0 0.6
1270.0 0.5
2020.0 0.4
3000.0 0.3
o o
C to 105 C (including self-temperature rise)
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
3.5
3.5
14.0
7.0
3
Ir
(Adc)
102
16.0 1000.00
681
12.0
471
10.0
331
9.0
221
7.4 151
101
6.6
100.00
680
5.9
470
4.8
330
4.4
220
3.9
150
3.1 100
10.00
6R8
2.7
4R7
2.1
3R3
1.8
2R7
2R2
1.5
1R5
1.3
1R0
1.00
1.0
R68
0.8
R33
0.6
0.5
0.4
0.10
0.3
0.10
76
UNIT:mm/inch
A = 12.94 / 00.510 Max.
B = 9.4 / 0.370 Max.
C = 5.2 / 0.205 Max.
D = 7.9 0.2 / 0.303 0.008
E = 2.5 0.2 / 0.098 0.008
F = 2.5 0.2 / 0.098 0.008
1.00 10.00 100.00
CURRENT (A)
o
C.
