- Page 1 AW-D2-5800 User’s ManUal Point-to-point Industrial-grade, ultra-long-range 5.8 GHz line-of-sight wireless Ethernet systems...
-
Page 2: Line-Of-Sight
Line-of-sight :: 5.8 GHz Thank you for your purchase of the AW-D2-5800 wireless Ethernet dome. The AvaLAN wireless radio functions in place of an Ethernet cable and provides a transparent wireless point-to-point Ethernet cable replacement. If you have any questions when configuring your AvaLAN system, please send an e-mail to support@avalanwireless.com. -
Page 3: System Diagram
User’s Manual aW-D2-5800 System diagram Power adapter Ultra-long-range 2x 120 VAC to 24 VAC digital Ethernet 5.8 GHz radio link 24 VAC Power over Ethernet AW5800x mate injector (included) Ethernet RJ45 10BaseT Power adapter 120 VAC to 12 VDC 9-48 VDC... -
Page 4: Troubleshooting
User’s Manual Troubleshooting See the online installation tutorial and FAQ at www.avalanwireless.com. no Power leD Check the power connections. no radio link leD The radio is looking for its matched partner. If both units are powered up and the Power LEDs are active, they may be too far away to create the radio connection. -
Page 5: Technical Specifications
This product is warranted to the original purchaser for normal use for a period of 180 days from the date of purchase. If a defect covered under this warranty occurs, AvaLAN will repair or replace the defective part, at its option, at no cost. This warranty does not cover defects resulting from misuse or modification of the product. -
Page 6: Appendix A - 5800 Channel Table
User’s Manual Appendix A — 5800 channel table Manual frequency selection mode: This mode enables the user to restrict the operation of the AW5800x to a specific channel. This can be done by setting DIP switches 3-8 as shown in the table below. -
Page 7: Appendix B - Antenna Alignment Guide
User’s Manual aW-D2-5800 Appendix B — Antenna alignment guide Do not aim the omni-antennae directly at each other Technical support :: (650) 384.0000 PaGe 7 www.avalanwireless.com... - Page 8 ©2004 — 2008 AvaLAN Wireless Systems Incorporated. All rights reserved. AvaLAN Wireless and the AvaLAN Wireless logo are registered trademarks of AvaLAN Wireless Systems Incorporated. All other trademarks are property of their respective owners. AvaLAN Wireless makes no representations or warranties with respect to the accuracy, utility, or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any time without notice.
