Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
(Order No. MD0509368C0) for this mechanism.
Specifications
RMS output power
THD 10%, both channels driven
1 kHz
Total output power
n FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
Frequency range
Sensitivity
S/N 26 dB
Antenna terminal(s)
Amplitude Modulation (AM)
Frequency range
Sensitivity
S/N 20 dB (at 999 kHz)
Music Port input jack
Terminal
Sensitivity
Phone jack
Terminal
n CASSETTE DECK SECTION
Track system
Heads
50 W per channel (3 Ω)
100 W
FM 20 stations
AM 15 stations
87.5 to 108.0 MHz (50 kHz steps)
4.0 µV (IHF)
2.2 µV
75 Ω (unbalanced)
522 to 1629 kHz (9 kHz step)
560 µV/m
Stereo, 3.5 mm jack
100 mV, 4.7 kΩ
Stereo, 3.5 mm jack
4 track, 2 channel
SA-AK250E
SA-AK250EB
SA-AK250EG
SA-AK250EE
Colour
(S)... Silver Type
Record/playback
Erasure
Motor
Recording system
Erare system
Tape speed
Overall frequency response (+3, -6 dB) at DECK OUT
NORMAL
S/N Ratio
Wow and flutter
Fast forward and rewind time
n DISC SECTION
Disc played [8 cm or 12 cm]
(1) CD-Audio (CD-DA)
(2) CD-R/RW (CD-DA, MP3* formatted disc)
(3) MP3*
*MPEG-1 Layer 3, MPEG-2 Layer 3
Bit rate
MP3
Sampling frequency
MP3
CD-DA
© 2007 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0704052CE
CD Stereo System
Solid permalloy head
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase 100 kHz
35 Hz to 14 kHz
50 dB (A weighted)
0.18 % (WRMS)
Approx. 120 seconds with
C-60 cassette tape
32 kbps to 320 kbps
32 kHz, 44.1 kHz, 48 kHz
Unauthorized
copying
4.8 cm/s
44.1 kHz
and
