Commercial Electric 5018-WH-C Installation Manual

PACKAGE CONTENTS
(1) Low Voltage Recessed Cable Plate
For video information visit homedepot.com and search for model number 5018-WH-C
Installation
1
PREPARING THE INSTALL LOCATION
□
Use a drywall saw (not included) and the included template
to cut a hole in your install location. Then route your
cables through the opening in the wall.
3
INSTALLING THE PLATE
□
Secure the Low Voltage Recessed Cable Plate to the wall
using a Phillips head screwdriver to tighten the attached
screws with wings.
Conforms to UL Std. 1863
3026001 Certified to CSA Std. C22.2#182.4
TOOLS NEEDED
Drywall Saw
#2 Phillips head screwdriver
Pencil
*The use of power tools is not recommended
2
4
RoHS Compliant
This product is patent protected by
U.S. Patent number: 7390964
Installation Guide
Low Voltage Recessed Cable Plate
Scan Me
ROUTING THE CABLES
□
Route your low voltage cables through the opening in the back of
the Low Voltage Recessed Cable Plate and out through the front
of the Plate.
INSTALLATION COMPLETE
□
Installation is complete. You can now connect your home theater
devices and equipment.
Item #1000746324
Model #5018-WH-C
HOMEDEPOT.CA
