"1379" – User password (end user)
PASSWORDS:
"9731" – Administrator Password
"1173" – Network Admin Password
"6629" – Network User Password
To enter Programming Mode
1. Press the "SETUP" button.
2. Enter the password followed by "enter".
3. If the password is accepted, the display will show:
Technical Setup
Set Time
4. Use the following buttons to configure your transmitter.
•
"*/ Menu" key to scroll through the different menu options.
•
"#/Select" key to toggle between
•
" Enter" to edit the menu and save the new settings.
•
"Cancel" to exit the system programming menu.
Menu 1 - Set the Current Time
1. At the "Set Current Time" menu, press the "ENTER" key.
2. Set the hour, then press the "ENTER" key.
3. Set the minutes, then press the "ENTER" key.
4. Use "1 or 2" key to select AM or PM, then press the "ENTER" key.
5. After the correct time is set, press the "ENTER" key to accept. Press the "CANCEL" key to exit the system
programming menu.
Menu 2 - Set the Sleep Shutdown Time (Factory Default: OFF) –
This system has an "ALL SLEEP" function that turns off all battery pagers (TOPNUM RALPHA) at once, automatically.
You do not need to use this function if your system is completely rechargeable like GuestCall IQ pagers.
To turn Sleep Time "ON", follow the procedure below:
1. At the "Set Sleep Time" menu, press the "#/Select" key to turn the sleep shutdown to "ON".
2. Press the "ENTER" key to accept the change.
3. Press the "CANCEL" key twice to exit out of the menu.
Change Shutdown Time
1. At the sleep shutdown menu, press the "#/Select" key to turn the sleep shutdown to "ON".
2. Press the "Enter" key.
3. Set the hour then press the "ENTER" key.
4. Set the minutes and press the "ENTER" key. Use the "1 or 2" key to select AM or PM and then press the "ENTER"
key. After the correct time is set, press the "ENTER" key to save. Press the "CANCEL" key to exit the system
programming menu.
To turn Sleep Time "OFF", follow the procedure below:
1. At the "Set Sleep Time" menu, press the "#/Select" key to turn preset messages from "ON" to "OFF"
2. Press the "ENTER" key to save the programming.
3. Press the "CANCEL" key to exit the system programming menu.
Menu 3 - Range Test (Factory Default: OFF)
With this feature you can determine what distance your transmitter will cover.
To start the Range Test, follow the procedure below:
1. Remove a couple of pagers from the charging stack.
ISTATION SYSTEM PROGRAMMING
for battery operated pagers only.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HME JTECH ISTATION
Summary of Contents for HME JTECH ISTATION
- Page 1 ISTATION SYSTEM PROGRAMMING “1379” – User password (end user) PASSWORDS: “9731” – Administrator Password “1173” – Network Admin Password “6629” – Network User Password To enter Programming Mode 1. Press the “SETUP” button. 2. Enter the password followed by “enter”. 3.
- Page 2 2. At the “Range Test” menu, press the “#/Select” key to turn range test “ON”. 3. Press the “ENTER” key to start the range test. As soon as range test is activated you’ll notice the pagers flash once every 10 seconds (if you use numeric pagers they will vibrate). Walk around your property. When you reach the point where the pagers do not flash consistently, this is your maximum range.
- Page 3 4. Press the “CANCEL” key to exit the system programming menu 5. Return all the pagers to the charging base or plug the power supply. The pagers are ready to receive the page with the new alert time. Menu 7 – Custom Alpha (Factory Default: Normal Font) Description To change the Custom Alpha, follow the procedure below: 1.
- Page 4 3. Press the “ENTER” key 3 times. After sending the signal, all the pagers will light up once to tell you that they received the new code. 4. Press the “CANCEL” key to exit the system programming menu. Menu 10 – Set Default Numeric Message (Factory Default: OFF) - for Numeric Display Pagers This feature is common when an end user is using multiple stand-alone transmitters.
- Page 5 3. Press the “CANCEL” key to exit the system programming menu. Menu 15 - Set Output Format This option is use interface the HME Handheld Tablescouts to table management software. You can also use this to log data coming via the RS232 connection.
- Page 6 2. Press the “ENTER” key to save your choice. 3. Press the “CANCEL” key to exit the system programming menu. Menu 17 - Estimated Start Time / Estimated Add Time This is the time to start your wait and the incremental change in minutes every time you page and add a guest to the wait list.
- Page 7 To start the Search Pagers function, follow the procedure below: 1. At the “Search Pagers” screen press the “ENTER” key. 2. Press the “CANCEL” key when you have located the pagers. 3. Press the “CANCEL” key to exit the system programming menu. Menu 23 - Set Range ID (Factory Default: 0) ID use for out of range function.
- Page 8 2. Press the “ENTER” key to save your choice. 3. Press the “CANCEL” key to exit the system programming menu. Menu 28 - Set USB Type (Factory Default: Keyboard) Description To change the USB Type, follow the procedure below: 1. At the “Set USB Type” press the “#/Select” key to scroll between Keyboard and None 2.
- Page 9 To enter Network Programming Mode 1. Press the “SETUP” button. 2. Enter the password followed by “enter”. 3. If the password is accepted, the display will show: Admin Setup MAC Address 4. Use the following buttons to configure your transmitter. •...
- Page 10 2. Enter the twelve-digit IP, then press the “ENTER” key. 3. Press the “CANCEL” key to exit the system programming menu. Menu 13 – IP Domain (Factory Default: http://hme.com) Description To change the IP Domain (Keyboard Required), follow the procedure below: 1.
- Page 11 2. Press the “ENTER” key to save your choice. 3. Press the “CANCEL” key to exit the system programming menu. Menu 17 – Pager Powerup Message (Factory Default: HME Wireless) Description To change the Pager Powerup Message (Keyboard Required), follow the procedure below: 1.
