- Page 1 EN User Manual | Tumble Dryer TR722E95E aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................6 3. PRODUCT DESCRIPTION................8 4. TECHNICAL DATA..................9 5. -
Page 3: Children And Vulnerable People Safety
1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. - Page 4 similar accommodation where such use does not exceed (average) domestic usage levels. • Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.
- Page 5 • WARNING: Do not damage the refrigerant circuit. • WARNING: Do not touch the accessible condenser metal fins with bare hands. Risk of injury. Wear protective gloves. • If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.
-
Page 6: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation • Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power Warning: Risk of fire / Flammable supply. materials. • Always use a correctly installed shockproof socket. •... - Page 7 2.4 Care and cleaning printed circuit boards, electronic displays, thermostats and temperature sensors, software updates (including reset WARNING! software), springs, heaters and heating Risk of injury or damage to the appliance. elements, electric fuses (separately or bundled together), tension pulley, support roller, doors, door seals, door handles, Warning: Risk of fire / Flammable door lock assemblies and hinges, lint...
-
Page 8: Product Description
Access your appliance details, documentation and articles on how to use the best features (User Manual also available at aeg.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at aeg.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at aeg.com/ shop ) ENGLISH... -
Page 9: Technical Data
3.1 Electrical connection The power supply cable must be easily accessible after installing the appliance. At the end of installation you can connect the For any electrical work required to install this mains plug to the mains socket. appliance, contact our Authorised Service The rating plate and the 'Technical Data' Centre. -
Page 10: Control Panel
Weight 0,149 kg 5. CONTROL PANEL Program dial On/Off button Display Programs Start/Pause button Options 5.1 Display Symbol on the display Symbol description cycle time indication maximum load ENGLISH... -
Page 11: Programme
Symbol on the display Symbol description delay start selection (30min-20h) + Anti Crease option on buzzer off child lock on laundry dryness: iron dry, cupboard dry, extra dry Time Dry option on drain the water container indicator: clean the filter indicator: check the condenser indicator:... -
Page 12: Programmes And Options Selection
Load 1) Properties / Fabric mark 2) Programme Dries up to three bed linen sets at once. Minimises twists and tangles of large items Bedlinen XL 4,5 kg to ensure every bed linen reaches a uniform dryness without wet spots. Dries generic sportswear made with syn‐... -
Page 13: Options
Options Programmes 1) Dryness Level + Anti Crease Time Dry Duvet Easy Iron Refresh Together with the programme you can set 1 or more options. Set by default 7. OPTIONS 7.1 Dryness Level To change the default degree of target final moisture: 1. -
Page 14: Settings
time to time to prevent creases. Laundry can be removed during the anti-crease phase. TIME DRYING RECOMMENDATION 7.3 End Signal up 10 min action of cool air only (no heater). 10 - 40 additional drying to improve dryness af‐ The acoustic signal sounds at the following: ter previous drying cycle. -
Page 15: Before First Use
e.g. if the operating time is 1276 hours, To activate this option follow steps below: the display shows the text Hr for 2 1. Switch the appliance on by pressing seconds then 12 for 2 seconds followed On/Off button. by 76. This value is displayed with a 2. -
Page 16: Daily Use
Working pump and transferring condensation to the tank. 10. DAILY USE 10.1 Preparing the laundry • Remove all items from pockets. • Turn items with the internal layer made of cotton inside out. Cotton layer must be faced outwards. Loading the drum up to the maximum •... - Page 17 Fabric label Description Laundry is not suitable for tumble drying. 10.2 Loading the laundry • After 5 minutes from the end of the programme or anticrease phase. CAUTION! Ensure the laundry is not trapped When the appliance goes in low power between the appliance door and the mode, the display and icons turn off.
- Page 18 10.8 Starting a program To activate or deactivate an option touch the relevant button or a two button combination. To start the program: Corresponding symbol on the display or the led above the button lights up. Touch the Start/Pause button. The appliance starts and the LED above the 10.7 Child lock option button stops flashing and stays on.
-
Page 19: Hints And Tips
4. Close the appliance door. Possible causes of unsatisfactory drying results: If you do not turn off the appliance, the anti-crease phase starts (not active with • Inadequate default dryness level settings. Adjustment of the target final See chapter all programmes). Flashing symbol moisture signals the execution of the anti-crease... - Page 20 Cleaning the drum Every two months Cleaning the control panel and housing Every two months Cleaning the airflow slots Every two months The following paragraphs explain how you should clean each part. 12.2 Removing the foreign items Make sure that the pockets are empty and all loose elements are tied up before running the drying cycle.
- Page 21 2. Pull the plastic connection out and drain the water into a basin or equivalent receptacle. 3. Push the plastic connection back in and place the water container back into position. Throw the lint in the dustbin. 4. To continue the programme press the 4.
- Page 22 2. Open the condenser cover. 6. Close the condenser lid. 7. Turn the levers until it clicks into position. 8. Put the filter back. 12.6 Cleaning the humidity sensor CAUTION! Risk of humidity sensor damage. Do not use abrasive materials or steel wool to clean the sensor.
-
Page 23: Troubleshooting
12.7 Cleaning the drum Use a moist cloth to clean. Dry the cleaned surfaces with a soft cloth. WARNING! CAUTION! Disconnect the appliance before you Do not use furniture cleaning agents or clean it. cleaning agents which can cause corrosion. Use a standard neutral soap detergent to clean the inner surface of the drum and drum 12.9 Cleaning the airflow slots... - Page 24 Error code Possible cause Remedy The mains supply is unstable. When the appliance is showing EH0, please wait until main supply is stable than press start. If the appliance paused the cycle with‐ out any indication then press the cycle start. If the warning will occur again check the power cord / socket integrity or main supply.
- Page 25 Problem Possible cause Remedy It is not possible to The option you tried to select is not availa‐ Turn the tumble dryer off and on. Change select an option. An ble for the selected program. the program or option as required. acoustic signal is emitted.
-
Page 26: Consumption Values
14. CONSUMPTION VALUES 14.1 Introduction The user manual reports two different references for EU energy label and ecodesign regulations. • Reg. (EU) 932/2012 and Reg. (EU) 392/2012 valid up to 30 June 2025 is relate to the Energy efficiency classes from A+++ to D. •... - Page 27 Initial Energy con‐ Target final Load Spun at mois‐ Drying time Programme sumption Moisture (kg) (rpm) ture (h:mm) (kWh) 1) 2) 1000 3:39 1,64 1) 2) 1000 2:10 0,84 This is the reference programme used to assess the compliance with EU ecodesign and Energy label regula‐ tions, Reg.
-
Page 28: Environmental Concerns
15. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office. - Page 32 136205750-B-142024...
