- Page 1 VANDAL RESISTANT BACK-LIT WEATHERPROOF RFID ACCESS CONTROL KEYPAD With Access Plus App DK-2852 C&D User Manual (MK-II ) FOR ELECTRIC LOCK, INTER-LOCK AND SECURITY SYSTEM INSTALLATIONS...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ······································································································································· 4 FEATURES ················································································································································ 4 OPTIONAL DEVICES FOR SYSTEM EXPANSION ·················································································· 5 SPECIFICATIONS ···································································································································· 6 INSTALLATION ········································································································································· 7 Precautions ············································································································································ 7 CONNECTION TERMINALS ··············································································································· 8-10 OTHER FACILITIES ································································································································ 11 On-Board LED Indicators ······················································································································· 11 Pacifier Tone & The LED Signals ···········································································································... - Page 3 Operation Modes ···································································································································· 42 Close The Programming Mode ················································································································ 42 ····································································· 43-44 PROGRAMMING MAKE SIMPLE - For General Users PROGRAMMING SUMMARY CHART ································································································ 45-46 APPLICATION EXAMPLES ················································································································ 47-48 A Stand Alone Door Lock ························································································································ 47 An Inter-Lock System Using Two Keypads ·····························································································...
-
Page 4: Introduction
The keypad is ideally for door strike and alarm arm-disarm controls. It is also a programmable industrial timer (from 1 second to over 24 hours) for automatic operator system. Two versions are available for DK-2852. They are denoted with a suffix letter “C” & “D” DK-2852C (Standard Version): Output Relay 1 –... -
Page 5: Optional Devices For System Expansion
OPTIONAL DEVICES FOR SYSTEM EXPANSION The Optional Decoders Available for Split-decoded Operation DA-2800 – Full Feature Decoder with RF Remote Control DA-2801 – Full Feature Decoder The Auxiliary Reader / Keypad Available for Multi-station Operation AR-2802S or A – EM Card Reader AR-2806S or A –... -
Page 6: Specifications
SPECIFICATIONS Operating Voltage: 12V-24V AC/DC, Auto adjusting Operating Current: 62mA (quiescent) to 130mA@12VDC 30mA (quiescent) to 61mA@24VDC Storage and Operation Temperature: -20 C to +70 C Storage and Operation Humidity: 5-95% relative humidity non-condensing Working Environment & Ingress Protection: All weather, IP-66 Number of Users: Output 1 –... -
Page 7: Installation
INSTALLATION ASSEMBLY LED Indicators Digital Keyboard EM Card Reader PRECAUTIONS 1) Prevent Interference: The EM Card reader is working at the frequency of 125Khz. Installation precautions are necessary. Make sure the location for installation has no strong low frequency electro-magnetic wave. Especially in the range of 100-200Khz If there is more than one keypads with the same operation frequency installed closely in the location, make sure that they are at least 60cm (2ft) apart from each other to prevention... -
Page 8: Connection Terminals
CONNECTION TERMINALS WI-FI MODULE WI-FI SELECTOR JUMPER BACK-LIT JUMPER CONNECTION TERMINALS 1 - 2 : 12 - 24V AC/DC (Power Input Terminal) Connect to 12-24V AC or DC power supply. The (-) supply and (-) GND (terminals 2 & 12) are the common grounding points of the keypad system. -
Page 9: System Refreshing With "Refreshing Code
9 : EG IN ( Egress Input) A Normally Open (N.O.) input terminal referring to (-) ground. With the help of connecting a normally open button to activate Output 1 for door opening like using Codes/Cards. Egress button is usually put inside the house near the door. More than one egress buttons can be connected in parallel to this terminal. - Page 10 14 : O/P 1 INHIBIT N.O. (Output 1 Inhibit Control Input – Normally Open) A Normally Open (N.O.) sensing input point for controlling the Output 1, with this terminal connecting to (-) ground, the Egress Button, the group of User PINs and Cards for Output 1 are all disabled.
-
Page 11: Other Facilities
OTHER FACILITIES ON-BOARD LED INDICATORS It lights up in Green for Output 1 activation; Red for Output 1 inhibited RED / GREEN (Right) --- and flashing during inhibition paused. Amber LED flashes in Standby. It shows the system status in AMBER / RED (Centre) -- synchronization with the beep tones. -
Page 12: Preparation For Programming
PREPARATION FOR PROGRAMMING A) CRITERIA FOR CODES AND CARDS 1) Prime Codes The prime codes include the a) User Codes, b) Master Code, c) Duress Codes, d) Super User Codes, e) Common User Codes and f) Visitor Codes. All these codes MUST be unique. It is not allowed to repeat a prime code for second function. -
Page 13: C) List Of User Information
5) EM Card + Proprietary Secondary User Code – Operation Media 3 The keypad accepts programming with each card having its own proprietary user code to work. It prevents any other people can use the lost card to open the door. Card with proprietary user code approach is ideal for the area that high security is the main concern. -
Page 14: Programming And Operation
PROGRAMMING & OPERATION POWER-UP THE KEYPAD The keypad gives power-up delay of 1 minute after power has been applied. It is the time frame designed for setting the keypad to programming mode with DAP code. See the details of “DAP CODE –... -
Page 15: Direct Access To Programming Mode With The "Dap" Code - 2 8 2 8
DIRECT ACCESS TO PROGRAMMING MODE WITH “DAP” CODE -- 2 8 2 8 In case the Master Code is forgotten, apply the following procedures precisely to set keypad into programming mode with DAP code: Switch OFF all the power for 1 minute to ensure that the keypad is fully discharged. Switch ON power again. -
Page 16: The Default Values After Refreshing
THE DEFAULT VALUES AFTER REFRESHING LOCATION PARAMETERS DEFAULT FUNCTIONS & VALUES Master Code 0 0 0 0 Factory Set, Not a default value * Super User Codes Nil ----- User Program Required Common User Code 1 Nil ----- User Program Required Common User Code 2 Nil ----- User Program Required User Codes &... -
Page 17: Master Code
MASTER CODE (Location 01) LOCATION MASTER CODE VALIDATION 4 to 8 Digits (1) LOCATION Key in Location (2) MASTER CODE Master Code is the authorization code for setting the system to programming mode. It is NOT an User Code operating the output relays. The Master Code can be 4 to 8 digits. -
Page 18: Operation And Functions Of The Super User Code
OPERATION AND FUNCTIONS OF THE SUPER USER CODE 1) Operate Output 1 and 2 The operation of the Super User Code is just like a normal User Code. Simply key-in the Code with a specific output number for the desired Output. The Super User Code can also be used to reset an operating output timer instantly. -
Page 19: Super User Code
REMARK : While SUPER USER CODE is in operation to hold the door lock open, the functions that rely on the door sensor (such as a magnetic contact) and the User Codes for output 1 are all temporarily ... -
Page 20: Common User Codes For Output 1 & 2
COMMON USER CODES FOR OUTPUT 1 & 2 (Locations 03 & 04) The Common User Codes 1 and 2 are prepared for operating of the Output 1 and 2 respectively as an enhance code. The Common User Codes MUST work in the form of “Card + Common Code” to operate the outputs to increase the security of the access control system. -
Page 21: User Codes/Card For Output 1
USER CODES / CARDS FOR OUTPUT 1 & 2 (Locations 10 & 20) LOCATIONS MEDIA USER ID CARD / USER CODE VALIDATION (1) LOCATIONS (User Groups) – Group 1 – 1,000 User Codes / Cards for controlling Output 1 ... -
Page 22: Examples - Programming And Operation
EXAMPLES – PROGRAMMING AND OPERATION 1) Example 1 -- EM Card Only : i) Programming : Read Card (a) The card is programmed for operating Output 1 (b) The operation is medium EM Card only (c) Take ID number 001 in Group 1 to store the card, which is one of the IDs in 000-999 (d) Put the card close to the reader, one beep confirms the reading (e) Press # to store the “Card”, two-beep confirms a valid entry ii) Operation : (while the system is back to operation mode) - Page 23 3) Example 3 -- EM Card + Secondary User Code i) Programming : Read Card (a) The card is programmed for operating Output 1 (b) The operation medium is EM Card + Secondary User Code (c) Take the ID number 002 in Group 1 to store the Card & Code, which is one of the IDs in 000-999 (d) Put the card close to the reader.
- Page 24 5) Example 5 -- Delete An User Code & / or EM Card (for O/P 1 or 2) : i) Delete An User Code or A Lost EM Card User ID (a) Key in the User Group that the User ID belongs to. “10” for Group 1, “20” for Group 2 (b) Key in “5”...
-
Page 25: Visitor Codes (For Output 1 Only)
VISITOR CODES (FOR OUTPUT 1 ONLY) (Location 40) The Visitor Codes are temporary user codes for Output 1 (mainly for door strike in access control). They can be programmed as “One Time Codes” or “Codes with Time Limit”. The Visitor Codes will be cleared automatically after use if they are one time codes, or, when the allowed time expires. - Page 26 EXAMPLES: Example 1: Set a “One Time Visitor Code” with the number of “1 2 6 8” for the Output 1 (a) Visitor Code Programming, (b) The Visitor ID, (c) An One Time Code, (d) The Visitor Code, (e) Entry Confirmation Example 2: Set a “Visitor Code”...
-
Page 27: Duress Codes (For Outputs 1 & 2)
DURESS CODES (FOR OUTPUTS 1 & 2) (Locations 41 & 42) Duress Codes are prepared for those Important Persons in case of DURESS while he is operating the access control keypad. The duress code operates like a normal User Code for Output 1 or 2, and at the same time activates the Duress Output without any indication. -
Page 28: Operation And Function Of The Duress Code
EXAMPLES: Example 1: Set a “Duress Code” with the number of “3 3 6 9” for Output 1 (a) Duress Code for Output 1, (b) Duress Code ID, (c) The Duress Code, (e) Entry Confirmation Example 2: Set a “Duress Code” with the number of “2 3 9 8 0” for Output 2 (a) Duress Code for Output 2, (b) Duress Code ID, (c) The Duress Code, (e) Entry Confirmation ... - Page 29 Report Duress in EM Card Operation The Duress Codes are Prime User Codes in the system. In the “EM Card + Secondary User Code” or “EM Card + Common User Code” operation, they can be used to replace the “Secondary User Code”...
-
Page 30: Output Modes & Timing For Output 1 And 2
OUTPUT MODE & TIMING FOR OUTPUT 1 and 2 (Locations 51 & 52) The two relay outputs are programmable for Start/Stop or Timing modes. Apart from door access control, alarm arm-disarm control, they are also universal timers for automatic operators in industry with their 99,999 seconds (over 24 hours) programmable timer. -
Page 31: System Real-Time-Clock
SYSTEM REAL-TIME-CLOCK (Location 55) This 24 hour real-time-clock provides the daily time base for starting and stopping the function of inhibition to relay output 1 (mainly for electric door lock strike). No real-time-clock setting is required if daily start-stop inhibition at Location 56 is not enabled. -
Page 32: Start & Stop Times For Daily Inhibition Of Output 1
START & STOP TIMES FOR DAILY INHIBITION OF OUTPUT 1 (Location 56) Setting with start and stop times into the keypad, the real-time inhibition period for output 1 will recycle daily until the time settings are cleared. This function works with the real-time-clock. Set up the real-time at Location 55 is necessary. For safety reason, the Egress Button is designed always valid. - Page 33 Programming and Operation Examples: (i) Set the starting and stopping time for the real-time inhibition period a) Set Inhibition Period from 12:30 PM (today) – 1:30 PM (same day) for lunch time: b) Set Inhibition Period from 6:30 PM (today) – 8:15 AM (next day) for office close: ...
-
Page 34: Personal Safety And System Lock-Out
PERSONAL SAFETY AND SYSTEM LOCK-UP (Location 60) LOCATION LOCK-UP OPTIONS VALIDATION 1 to 2 Digits (1) LOCATION Key in Location (2) LOCK-UP OPTIONS The Options are represented by the following Numbers. They are described below: --- After 10 successive false Card/User Code trials, the keypad locks during 60 seconds. -- (Default) ... -
Page 35: User Code Entry Mode - Auto Or Manual
USER CODE ENTRY MODE – Auto or Manual (Location 70) LOCATION ENTRY MODES VALIDATION (1) LOCATION Key in Location (2) USER CODE ENTRY MODES Two modes 1 and 2 are available for User Code entry options. The EM Card is always in Auto Entry Mode and is not affected by the selection here. -
Page 36: Output Operation Announcer
OUTPUT OPERATION ANNOUNCER (Location 72) LOCATION FUNCTION MODES VALIDATION (1) LOCATION Key in Location (2) FUNCTION MODES FOR OUTPUT ANNOUNCER Output announcer gives notification beep on the operation status of the outputs. There are two notification modes available for the selection.The notification is also OFF while the Pacifier Tone OFF mode in the Location 71 is selected. -
Page 37: Door Forced Open Warning & Timing
DOOR FORCED OPEN WARNING & TIMING (Location 80) LOCATION FUNCTION MODES VALIDATION (1) LOCATION Key in Location (2) FUNCTION MODES FOR DOOR FORCED OPEN WARNING The Door Forced Open Warning function works with a Door Position Sensing switch equipped on the door (usually a magnetic contact). -
Page 38: Intelligent Egress Button - An Unique Feature Of A Contemporary Keypad
INTELLIGENT EGRESS BUTTON – AN UNIQUE FEATURE OF THE KEYPAD INTRODUCTION Most of the keypads for access control are just for controlling “Going In” from outside. It is not enough for today’s access control systems. In fact, controlling “Going Out” is also very important in some public passage areas those are not allowed to use locks or digital keypads for stopping of “Going Out”... - Page 39 High Traffic Passage: A short buffer time may be necessary for opening a door outward after pressing the egress button for those exits open to a high traffic passage. An egress button with short delay and warning beeps helps the user to pay attention to the people passing by to prevent hitting them when the door is pushed outward.
-
Page 40: Egress Delay , Warning And Alarm
EGRESS DELAY , WARNING AND ALARM (Location 90) LOCATION CONFIGURATIONS DELAY TIME VALIDATION (1) LOCATION Key in Location (2) CONFIGURATIONS OF THE EGRESS WARNING Key in the number to enable 1 of the 6 configurations described below: ... - Page 41 NOTE: 1) Momentary Contact -- The Egress Delay starts to count when the egress button is momentarily pressed. Output 1 activates automatically (door is released) when the delay time reaches. Holding Contact -- The user MUST hold the egress button in contact for the whole period of the Egress Delay time until Output 1 activates.
-
Page 42: Operation Modes
OPERATION MODES (Location 94) The keypad is programmable for keypad mode to work stand-alone for door control directly or for server mode to work with a split-decoder for high security access control. LOCATION OPERATION MODES VALIDATION (1) LOCATION ... -
Page 43: Programming Make Simple - For General Users
PROGRAMMING MAKE SIMPLE – For General Users This is a multi purpose keypad. It has many functions for user’s selection. For those general users taking the keypad for door strike only, most of the features can be kept in their Default values. Only the User Codes / Cards and a private Master Code are required to program. -
Page 44: Operation
5) Record an “EM Card + User Code” to Operate The Output 1 for Door Open READ CARD (a) 10 = Programming Location for Output 1 (b) 3 = Programming option for EM Card + User Code. (The User Code can be repeated use or proprietary) (c) 003 = One of the 1,000 User IDs for the User /Card from 000-999... -
Page 45: Programming Summary Chart
PROGRAMMING SUMMARY CHART ENTRY LIMITS & CODE FACTORY FUNCTION CODE ENTRY LOCATION DEFAULT OPTIONS Master Code 4-8 Digits MASTER CODE Super User Code 4-8 Digits SUPER USER CODE Common User Code for COMMON USER CODE 1 O/P 1 4-8 Digits Common User Code for... - Page 46 Mode = 1, FUNCTION MODE: Pacifier Tone ON-OFF 0---OFF Pacifier Tone FUNCTION MODE 1---ON FUNCTION MODE: Mode = 1 0---NO Notification 1 Second Output Announcer FUNCTION MODE 1---1 Second Long Beep Long Beep 2---2 Short Beeps FUNCTION MODE: Mode = 1, ...
-
Page 47: Application Examples
APPLICATION EXAMPLES 1) STAND ALONE DOOR LOCK ELECTRIC LOCK DK-2852 NOTE: Connect the 1N4004 as close as possible to the lock in parallel with the lock power terminals of the lock to absorb the back EMF to prevent it from damaging the keypad. The 1N4004 is not required if the electric lock is AC operated. -
Page 48: An Inter-Lock System Using Two Keypads
2) INTER-LOCK SYSTEM USING TWO KEYPADS DK-2852 DK-2852 An inter-lock system needs two door controllers. This application example uses two keypads with simple cross wire connection on their "Output 1 Inhibit" and "Inter-lock Control Output" terminals. It is necessary to link up the "(-) GND" terminals of the two keypads as common ground to achieve the inter-lock logical functions. -
Page 49: Application Expansions
The wiring is very simple. Just connect all the related devices in parallel with the Data I/O Bus. The DK-2852 is the server that manages the data among them. A Multi-station System provides higher security in access control and user convenience to operate an electric lock at different locations. -
Page 50: The Split-Decoders
The Split-decoders (Optional) DA-2800 DA-2801 Decoder with RF Remote Control Standard Decoder Connection Terminal OUTPUT 1 OUTPUT 2 OUTPUT 3 IMPORTANT NOTE The optional Auxiliary Readers, Reader-keypads and Split-decoders are DC operation. It is necessary to power the whole system with DC power supply if the Master Keypad is working with them for system expansion, even it is an AC/DC Version keypad... -
Page 51: Dual-Station Access Control Door Lock
Owner can select an auxiliary reader AR-2802 or an auxiliary reader-keypad AR-2806, AR-2807 or AR-2809 and connect it with the master keypad DK-2852 to expand the system with dual-station for user convenience. Simply connect the reader or the reader-keypad in parallel with the Data I/O Bus of the master keypad. -
Page 52: Multi-Station Access Control Door Lock
2) Multi-station Access Control Door Lock Description This is an expansion of application (1). The DK-2852 is expandable to a multi-station system for user convenience with the auxiliary readers AR-2802 and/or the auxiliary reader-keypads AR-2806, AR-2807 &r AR-2809. Total 3 auxiliary readers or reader-keypads can be connected in parallel with the Data I/O Bus and they provide the same functions like the master keypad in using cards and user codes. -
Page 53: Split-Decoded Access Control Door Lock
DA-2800 or DA-2801. The decoder is inside the house with all the input and output installations connecting to it. The DK-2852 manages the data in the system with its Data I/O Bus. The decoder operates the door lock and the appliances directly according to the commands from the keypad unit. -
Page 54: Split-Decoded Multi-Station Access Control Door Lock
Data I/O Bus. They provide the same functions like the master keypad in using cards and user codes. The DK-2852 that is the server of the system manages the data with its Data I/O Bus among the associated devices. This approach gives high security in sabotage prevention and user convenience. -
Page 55: Application Hints For The Auxiliary Terminals
APPLICATION HINTS FOR THE AUXILIARY TERMINALS (A) TAMPER N.C. The tamper switch is Normally Closed while the keypad is secured on gang box. It is open when the keypad is removed from the gang box. To prevent sabotage, connect these terminals in series with a 24 hour N.C. - Page 56 (D) DURESS OUTPUT The Duress Output switches to (-) ground when duress code is entered. You may use it to turn ON an LED lamp and/ or a small buzzer to notify a guard; or connect it to a 24 hour Normally Open protection zone of an alarm system.
- Page 57 (F) OUTPUT 2 -- Door Bell Button (DK-2852D) (OPTIONAL) The output 2 of the DK-2852D is prepared for ELECTRONIC triggering a low power door chime. DO NOT DOOR CHIME use it as a high voltage power path for a door bell.
-
Page 58: Auxiliary Information
AUXILIARY INFORMATION DRY CONTACT A dry contact means that no electricity is connected to it. It is prepared for free connections. The Relay Output contacts provided in this keypad system are dry contacts. N.C. Normally Closed, the contact is closed circuit at normal status. It is open circuit when active. N.O. - Page 59 FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 60 AEI PROTECT-ON SYSTEMS LIMITED www.apo-hk.com Ver.202108_V3...
