Technical Service
BULLETIN
June 18, 2007
Introduction
This bulletin provides information on the proper automatic transmission fluid fill and
level check procedures for 2007 model year Tundra vehicles. Use the procedures below
when checking automatic transmission fluid level.
NOTE:
Failure to properly adjust transmission fluid can cause transmission shifting issues or
damage to the automatic transmission.
Applicable
2007 model year Tundra vehicles.
Vehicles
Parts
PREVIOUS PART NUMBER
Information
00289–ATFWS
Warranty
OP CODE
Information
N/A
Toyota Supports ASE Certification
Title:
TRANSMISSION FLUID LEVEL
Models:
'07 Tundra
CURRENT PART NUMBER
Same
DESCRIPTION
Not Applicable to Warranty
PART NAME
ATF WS
As Needed
TIME
OFP
–
–
QTY
T1
T2
–
–
Page 1 of 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tundra 2007 and is the answer not in the manual?

Questions and answers

Related Manuals for Toyota Tundra 2007

Summary of Contents for Toyota Tundra 2007

  • Page 1 2007 model year Tundra vehicles. Vehicles Parts PREVIOUS PART NUMBER CURRENT PART NUMBER PART NAME Information 00289–ATFWS Same ATF WS As Needed Warranty OP CODE DESCRIPTION TIME Information Not Applicable to Warranty – – – – Page 1 of 7 Toyota Supports ASE Certification...

  • Page 2: Required Equipment

    NOTE: Additional Techstream units may be ordered by calling Approved Dealer Equipment (ADE) at 1–800–368–6787. The Toyota Diagnostic Tester and CAN Interface Module may also be used to perform the service procedures listed in this bulletin. SPECIAL SERVICE TOOLS (SSTs)
  • Page 3 TRANSMISSION FLUID LEVEL – TC009-07 June 18, 2007 Inspection 1. Confirm if vehicle is equipped with the optional towing package. Procedure Vehicles equipped with the optional towing package are also equipped with a separate transmission oil cooler and transmission fluid thermostatic valve located on the right side of the transmission adjacent to the ATF warmer (see illustration below for location).
  • Page 4 TRANSMISSION FLUID LEVEL – TC009-07 June 18, 2007 Inspection B. With the shaft of the thermostat pressed in, push a pin (diameter 1.0 to Procedure 1.8 mm [0.04 to 0.07 in.]) into the hole on the side of the thermostat’s cap. Insert (Continued) the pin until it passes through the hole on the other side of the thermostat’s cap to hold the shaft in place.
  • Page 5 TRANSMISSION FLUID LEVEL – TC009-07 June 18, 2007 Inspection E. While observing the “D” shift Procedure indicator on the combination (Continued) meter, move the shift lever back and forth between “N” and “D” at an interval of 1.5 seconds for 6 seconds or more.
  • Page 6 TRANSMISSION FLUID LEVEL – TC009-07 June 18, 2007 Inspection 5. Warm up the ATF to fluid check temperature. Procedure With the engine idling in Park, allow the transmission to reach the fluid check (Continued) temperature of 115 to 133 F (46 to 56 C). BELOW FLUID CHECK ABOVE FLUID CHECK FLUID CHECK TEMPERATURE...
  • Page 7 TRANSMISSION FLUID LEVEL – TC009-07 June 18, 2007 Inspection B. Check that the fluid comes out of the overflow tube. Procedure If fluid does NOT come out, proceed to step 7, “Refill Transmission’’ . (Continued) If fluid comes out, wait until the overflow slows to a trickle and proceed to step 8, “Complete the transmission fluid level Inspection Procedure’’.
