3 3 0 R
M330R V7, © July 2023
1/8 DIN PROCESS MONITOR and
INDICATOR USER'S MANUAL
The 330 Process Monitor is an entirely new
design. The operation of the instrument's keys
and the wiring of the rear terminals is different
than found on the 320. In addition, a 320 chassis
may not be used in a 330 case. To insure proper
use and installation, please review the manual
before using.
M330-V1
3 3 0 R
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Moore Industries 330R
Summary of Contents for Moore Industries 330R
- Page 1 3 3 0 R 3 3 0 R 1/8 DIN PROCESS MONITOR and INDICATOR USER'S MANUAL The 330 Process Monitor is an entirely new design. The operation of the instrument's keys and the wiring of the rear terminals is different than found on the 320.
-
Page 2: Table Of Contents
Alarm Operation Charts ..........19 Input Linearization ............20 Square Root .............. 21 Custom Linearization ..........21 Security ..............22 TROUBLESHOOTING/SERVICE ......23 Symptom/Cause/Solution ........... 23 Error messages ............23 Electrical Noise Solution ..........24 SPECIFICATIONS ..........24 330R User’s Manual... -
Page 3: About This Manual
Optional isolated RS 485 serial communications allows supervision and data acquisition by higher level devices. The communications protocol is compatible with all Moore Industries’ micro-based instruments, allowing a variety of instruments to be installed on the same RS 485 line. -
Page 4: Ordering
Note: If you require a waterproof seal, +0.5 CUTOUT 43.7 –0.0 apply a bead of caulk or silicone seal- +.02 (1.71 +0.7 –.00 90.5 ant behind the panel around the perim- –0.0 +.03 eter of the case. (3.56 –.00 330R User’s Manual... -
Page 5: Wiring Practices
You may also use additional process variable input filtering on systems that use these devices. If the spark gap is given a sufficient low impedance return path, these items will most likely not be necessary. 330R User’s Manual... -
Page 6: Rear Terminal Connections
Drive output is ~17 VDC when active and ~0.3 VDC when inactive. This is suitable for switching most of the SSR’s on the market. Be sure to set the option board jumper to the normally-open (NO) position when using an SSR drive output. 330R User’s Manual... -
Page 7: Communications Wiring
Failure to follow these proper wiring practices could result in transmission errors and other communications problems Thermocouple Input Wiring Note: Refer to thermocouple manufacturer's specification for (typically red) positive and negative color code. - LEAD PV1: + LEAD 330R User’s Manual... -
Page 8: Rtd Input Wiring
When using milliamp inputs, the 330 may power a transmitter using loop power. LOOP POWER or PV1 Input – EXCITATION OUTPUT – LOOP POWER or PV1 Input + EXCITATION OUTPUT + LOOP POWER #2 OUTPUT – LOOP POWER #2 OUTPUT + 330R User’s Manual... -
Page 9: Voltage/Current Input Operation
0 to 5.10 0 to 30.60 0 to 61.20 0 to 102.00 Flashes 20.40 to 20.50 5.10 to 5.125 30.60 to 30.75 61.20 to 61.50 102.00 to 102.50 “-Hi-” Above 20.50 Above 5.125 Above 30.75 Above 61.50 Above 102.50 330R User’s Manual... -
Page 10: Hardware Set Up
Accessing and Changing Jumpers Depending on the model number ordered, the 330 will come with one or two boards. the 330R000 is shipped with one board. The 330R with any additional specified options will be shipped with two boards. The alarm relay output jumper is set at the factory to normally open (N.O.). -
Page 11: Adding Or Changing Output Boards Or Output Modules
Configuration Adding or Changing Option Boards or Output Modules The basic 330R has provisions for adding up to 4 different option boards. Three of these option boards may be shipped with different output modules; these may also be added in the field. These modules are the same as those used in the 535 Series of controllers. -
Page 12: 330 Display-Modes
While displaying the menu label, press ACK & UP or ACK & Down keys to exit the menu and display the PV and alarm messages ("buSY" will be displayed until the PV is ready to be displayed). 330R User’s Manual... -
Page 13: Configuration
Curr or VoLt nn.nn, n.nnn or nnn.n only PVLo PV low input value inPt is Curr -999 to 9999 Uses dP decimal or VoLt and Lin point is not CuSt 330R User’s Manual... - Page 14 4-20, 20-4, -999 to 9999 Uses dP range value 0-20 or 20-0 decimal pt. rEHi Retransmission high rEtr is 4-20, 20-4, -999 to 9999 1000 Uses dP r range value 0-20 or 20-0 decimal pt. 330R User’s Manual...
- Page 15 UP and 18.07mV, mA or ohms value to DOWN Keys 19.20mA, PV (and short 300.0 Ohms, the 3rd leg input or 150.0 ohms to PV-ifPV is an rtd), then press the UP and DOWN keys simultaneously 330R User’s Manual...
- Page 16 1) press the UP or DOWN key to adjust the display to match the meter reading; 2) press the UP and DOWN keys simultaneously; 3) repeat steps (1) and (2) until the displayed 4mA output value is within tolerance 330R User’s Manual...
- Page 17 -999 to 9999 which enables security override for 1 minute S.PAr PARA menu Always appears oFF, on security enable/disable S.Con CONF menu Always appears oFF, on security enable/disable S.CAL CAL menu Always appears oFF, on security enable/disable 330R User’s Manual...
-
Page 18: Operation
The rear contact can be configured to reset the peak/valley values. Closing the contact will reset both values simultaneously to the current PV value as selected by the rcon parameter. 330R User’s Manual... -
Page 19: Alarm Operation
Defines the state of the alarm when the instrument is powered up. The instrument can be configured to never go into alarm upon power up, to always go into alarm or to only go into alarm if the process variable values warrant. 330R User’s Manual... -
Page 20: Alarm Operation Charts
1 = Relay and Alarm message can be turned off by ACK key. 2 = Relay and Alarm message will be on due to latching function unless previously cleared; if it is on, it can be cleared by pressing ACK key. 330R User’s Manual... -
Page 21: Input Linearization
If the PV input = 2 Volts, PV = 0 + (5000 - 0) (2 - 1)/ (5 - 1) = 2500 If the PV input = 3 Volts, PV = (5000 - 0) (3 -1) / (5 - 1) = 3535. 330R User’s Manual... -
Page 22: Square Root
Actual Function PV-2 Linear Approximation PV-1 in-1 = in-2 in-3 in-4 in-5 in-6 in-7 in-8 in-9 in-10 = 5.000 0.000 Input Value (in volts) or 1.000 Note: Custom Linearization is available for any volt or milliamp PV input. 330R User’s Manual... -
Page 23: Security
After 60 seconds of key inactivity, security will be re-armed. (In other words, if no keys are pressed for 60 seconds, the security code will need to be re-entered before the menu can be accessed again). 330R User’s Manual... -
Page 24: Troubleshooting/Service
Note: If after checking the solution you still experience difficulty with your unit, please contact either your Moore Industries representative or one of our application engineers. 330R User’s Manual... -
Page 25: Electrical Noise Solution
-346 to 1832 -210 to 1000 -418 to 2500 -250 to 1371 -328 to 2372 -200 to 1300 32 to 3182 0 to 1750 32 to 3182 0 to 1750 Specifications and information subject to change without notice. 330R User’s Manual... - Page 26 Contact Input External dry contact input or open-collector transistor input for alarm acknowledgement, peak/valley reset or keypad lockout. Isolated from process variable input and digital circuitry. Memory Non-volatile EEPROM. 330R User’s Manual...
- Page 27 Solid state relay (triac) module Resistive load rated at 1 amp at 120/240 VAC. DC logic (SSR drive) module “ON” voltage is 17 Vdc (nominal). “OFF” voltage is less than 0.5 Vdc. (Current limited to 40mA.) 330R User’s Manual...
- Page 28 A user-configurable code is used to enter the full access level. Calibration Comes fully calibrated from the factory. Field calibration can be easily performed in the field with a precision multimeter and input simulator. Process variable offset and gain factors are provided to correct for sensor errors. 330R User’s Manual...
- Page 29 330R User’s Manual...
- Page 30 4. Ship the equipment to the Moore Industries location nearest you. The returned equipment will be inspected and tested at the factory. A Moore Industries representative will contact the person designated on your documentation if more information is needed. The repaired equipment, or its replacement, will be returned to you in accordance with the shipping instructions furnished in your documentation.
