Contemporary In-Wall Camera Enclosure
®
For Sony and Canon
OVERVIEW:
The Vaddio CoverVIEW is a simple and attractive way to install PTZ
cameras into a wall cavity. The system is comprised of two parts: a metal
backbox and a curved ABS plastic bezel with acrylic lens. The backbox
has conduit knockouts on all sides and mounting flanges on both sides.
An adjustable tripod screw slot on the bottom of the box allows for
fastening the PTZ camera securely to the metal back box.
CoverVIEW enclosures fit the Sony EVI-D100, Vaddio WallVIEW 100
PTZ System, Canon VC-C50i and the Vaddio WallVIEW 50i PTZ
System. The CoverVIEW for the Sony EVI-D100 and the Vaddio
WallVIEW 100 PTZ System is available in black or white plastic bezels.
The CoverVIEW for the Canon VC-C50i and the Vaddio WallVIEW 50i
PTZ System is only available in black (Figure 1)
UNPACKAGING – SYSTEM COMPONENT LISTS
Carefully remove all parts from the packaging. Unpack and identify the following parts:
•
One (1) - CoverVIEW ABS plastic bezel with attached acrylic lens
– Black bezel for Sony EVI-D100 or WallVIEW 100 PTZ System, Part # 999-2221-000
– White bezel for Sony EVI-D100 or WallVIEW 100 PTZ System, Part # 999-2221-001
– Black bezel for Canon VC-C50i or WallVIEW 50i PTZ System, Part # 999-2224-000
•
Two (2) - Snap on trim panels (gray only)*
•
One (1) - Metal backbox (black only)*
•
One (1) - Bezel mounting template
•
One (1) - Backbox mounting template
•
One (1) - Assorted mounting hardware
One (1) - ¼"-20 x ¼" screw for camera mounting
Four (4) - ¼" x 2" long screws and four (4) toggle bolts
Four (4) - 3/16" conical wall anchors with four (4) - 1" sheet metal screws
*All plastic pieces (except for the camera) are paintable to match interior décor.
INSTALLATION INSTRUCTIONS
The CoverVIEW is intended for installation into finished drywall and does not require a rough-in kit or partial
pre-installation. The cabling can be pre-wired or cabled at the time of installation and is strictly a function of
integrator or customer preference, not a product requirement.
Drywall Mounting
Marking and cutting the drywall is probably the most challenging part of the CoverVIEW installation. Behind
any stud wall, the studs are either 16" or 24" on center and are either wood or metal. The CoverVIEW will fit
between either stud configurations.
The following steps should be followed for best installation results:
1. Determine the position of the camera. Consider camera height, viewing angles and distances from the
subject matter, sight lines, possible temporary obstructions (audience member heads) and the PTZ
specifications of the camera.
2. Determine the locations of the studs behind the drywall. Ensure that there are NO obstructions such as
horizontal studs behind the drywall and verify that there are NO utilities (electrical, gas, water, phone or
data) in this drywall area between the studs.
®
PTZ Cameras
CoverVIEW Installation and User Guide - Document 341-465 RevA, Page 1 of 4
Installation and User Guide
The
Figure 1:
Above - CoverVIEW in Black,
Below - CoverVIEW in White
Backbox is black and trim pieces are gray
standard. All plastic pieces (except for
the camera) are paintable to match
interior décor*.
