Operating Instructions: TCS Automatic Injector Unit (3525-01 & 3525-02)
The TCS Automatic Air Injector w/Built-in
Furnace is used to melt TCS thermoplastic
material and inject it into the flask.
Item #3525-01 (110V)
Item #3525-02 (220V)
PLEASE READ MANUAL PRIOR TO USE
A
FRONT VIEW
A. F S K
LASK ECURING NOB
B. P B
OWER UTTON
C. T D
EMPERATURE ISPLAY
D. T A K
EMPERATURE DJUSTMENT
E. C A P
LEAR CRYLIC ROTECTOR
F. P C
OWER ORD
G. R /I K
ELEASE NJECT NOB
F
I
TOP VIEW:
J. F L C
LASK OCKING LAMP
K. I P R
NJECTION LUNGER ECEPTACLE
L. F C
IXTURE OVER
M. F P
IXTURE OSTS
IMPORTANT
Be sure the release/inject switch
is in the RELEASE position before
connecting the compressor to the
injector.
A
NOB
F
Yield: Approximately 30 cases per day
Dimensions: Width 8" / Height 23'"/ Depth 13.5"
BACK VIEW:
H. A I H
IR NTAKE
I. A C
DJUSTABLE
H
I
Specifications
Weight: 40 lbs
Available in 110V & 220V
Requires a minimum of 135 psi
Warranty: 1 year
www.tcsdentalinc.com / 866-426-2970
I081808 Rev I
OSE
