EN User Manual | Dishwasher
FFB83717PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FFB83717PM and is the answer not in the manual?

Questions and answers

Related Manuals for AEG FFB83717PM

Summary of Contents for AEG FFB83717PM

  • Page 1 EN User Manual | Dishwasher FFB83717PM...

  • Page 2: Table Of Contents

    FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Children And Vulnerable People Safety

    for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning...

  • Page 4: Safety Instructions

    • Follow the maximum number of 15 place settings. • The appliance door should not be left in an open position to avoid the tripping hazard. • If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard.

  • Page 5: Water Connection

    Make sure that there is access to the • Do not store items or apply pressure on mains plug after the installation. the open door of the appliance. • Do not pull the mains cable to disconnect • The appliance can release hot steam if the appliance.

  • Page 6: Product Description

    status of the appliance. They are not • Disconnect the appliance from the mains intended to be used in other applications supply. and are not suitable for household room • Cut off the mains cable and discard it. illumination. • Remove the door catch to prevent children and pets to get closed in the appliance.

  • Page 7: Internal Light

    3.2 Internal light The appliance has an internal lamp. It comes Beam-on-Floor is off when the appliance on when you open the door or switch the is deactivated. appliance on while the door is open. The lamp goes off when you close the door or switch the appliance off.
  • Page 8 Programme Dishwasher Degree of Programme phases Options load soil Crockery, cut‐ Normal, lightly • Prewash • Extra Power lery, pots, pans dried-on • Dishwashing 50 °C • Glass Care • Intermediate rinse • Spray Zone • Final rinse 55 °C •...

  • Page 9: Consumption Values

    Programme Dishwasher Degree of Programme phases Options load soil Crockery, cut‐ • Prewash lery, pots, pans • Dishwashing 50 - 60 °C • Intermediate rinse • Final rinse 60 °C • Drying • AirDry This programme offers the most efficient use of water and energy consumption for crockery and cutlery with normal soil.

  • Page 10: Information For Test Institutes

    Water (l) Energy (kWh) Duration (min) Programme 1)2) 12.2 1.140 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. The values for programmes other than ECO are indicative only. 5.2 Information for test institutes To receive the necessary information for conducting performance tests (e.g.
  • Page 11 area. Your local water authority can advise area. Set the right level of the water softener you on the hardness of the water in your to assure good washing results. Water hardness German de‐ French de‐ mmol/l mg/l (ppm) Clarke de‐ Water softener grees (°dH) grees (°fH)

  • Page 12: The Rinse Aid Empty Notification

    programme. This activity increases the total If standard detergent or multi-tablets without water consumption of a programme by rinse aid are used, activate the notification to additional 4 litres and the total energy keep the rinse aid refill indicator active. consumption of a programme by additional 2 Wh.

  • Page 13: Acoustic Signals

    6.5 Acoustic signals The duration of the drying phase and the door opening time vary depending on the selected Acoustic signals sound when a malfunction of programme and options. the appliance occurs. It is not possible to When AirDry opens the door, the display deactivate these acoustic signals.

  • Page 14: Cycle Counter

    6.8 Cycle counter The displays shows uC and then the number of cycles. You can view the number of completed Press any button to exit the cycle counter. dishwashing cycles in the cycle counter. 1. Press the on/off button to activate the dishwasher.

  • Page 15: Before First Use

    8. BEFORE FIRST USE 1. Make sure that the current level of the 4. Carefully shake the funnel by its handle to water softener agrees with the get the last granules inside. hardness of the water supply. If not, 5. Remove the salt around the opening of adjust the level of the water softener.

  • Page 16: Daily Use

    4. Close the lid. Make sure that the lid locks CAUTION! into position. Only use rinse aid designed specifically for dishwashers. Fill the rinse aid dispenser when the 1. Open the lid (C). indicator (A) is clear. 2. Fill the dispenser (B) until the rinse aid reaches the marking ''MAX''.

  • Page 17: Cancelling The Delay Start While The Countdown Operates

    5. Close the appliance door to start the Cancelling the delay start while the programme. countdown operates When you cancel the delay start you have to Starting the programme set the programme and options again. 1. Keep the appliance door ajar. Press and hold simultaneously 2.

  • Page 18: Hints And Tips

    10. HINTS AND TIPS 10.1 General 10.2 Using salt, rinse aid and detergent Follow the hints below to ensure optimal cleaning and drying results in daily use and to • Only use salt, rinse aid and detergent protect the environment. designed for dishwasher.

  • Page 19: Care And Cleaning

    10.5 Before starting a programme 4. When the programme is complete, adjust the water softener according to the water Before you start the selected programme, hardness in your area. make sure that: 5. Adjust the released quantity of rinse aid. 6.

  • Page 20: External Cleaning

    11.2 Removal of foreign objects Check the filters and the sump after each use of the dishwasher. Foreign objects (e.g. pieces of glass, plastic, bones or toothpicks, etc) decrease the cleaning performance and can cause damage to the drain pump. CAUTION! If unable to remove the foreign objects, contact an Authorised Service Centre.

  • Page 21: Cleaning The Lower Spray Arm

    2. Wash the spray arm under running water. 7. Reassemble the filters (B) and (C). Use a thin pointed tool, e.g. a toothpick, 8. Put back the filter (B) in the flat filter (A). to remove particles of soil from the holes. Turn it clockwise until it locks.
  • Page 22 2. To detach the spray arm from the basket, holes. Clogged holes can cause press the spray arm upwards and unsatisfactory washing results. simultaneously turn it clockwise. The ceiling spray arm is placed on the ceiling of the appliance. The spray arm (C) is installed in the delivery tube (A) with the mounting element (B).

  • Page 23: Troubleshooting

    5. To install the spray arm (C) back, insert the mounting element (B) in the spray arm and fix it in the delivery tube (A) by turning it clockwise. Make sure that the mounting element locks into place. 6. Install the cutlery drawer on the sliding rails and block the stoppers.
  • Page 24 Problem and alarm code Possible cause and solution The anti-flood device is on. • Close the water tap. The display shows i30. • Make sure that the appliance is correctly installed. • Make sure the baskets are loaded as instructed in the user manual. Malfunction of the water level detec‐...
  • Page 25 Problem and alarm code Possible cause and solution Rattling or knocking sounds from • The tableware is not properly arranged in the baskets. Refer to basket the inside of the appliance. loading leaflet. • Make sure that the spray arms can rotate freely. The appliance trips the circuit-beak‐...
  • Page 26 Problem Possible cause and solution Poor drying results. • Tableware was left for too long inside the closed appliance. Activate the function AirDry to set the automatic opening of the door and to improve the drying performance. • There is no rinse aid or the dosage of rinse aid is not sufficient. Fill the rinse aid dispenser or set the dosage of rinse aid to a higher lev‐...

  • Page 27: Technical Information

    Problem Possible cause and solution Limescale deposits on the tableware, • The level of salt is low, check the refill indicator. on the tub and on the inside of the • The cap of the salt container is loose. door. •...

  • Page 28: Environmental Concerns

    rating plate of the appliance. Refer to the For more detailed information about the chapter "Product description". energy label, visit www.theenergylabel.eu. 14. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it.
  • Page 32 117834020-A-172023...
