Delta Electronics SIL530 Specification Sheet

SMT Power Inductor
SIL530 Type
Features
RoHS compliant.
Magnetically shielded
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor application.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.

Mechanical Dimension:

C
Electrical Characteristics:
L
PART NO.
(uH)
SIL530B - 1R1 1.1
SIL530 - 1R2 1.2
SIL530A - 1R2 1.2
SIL530 - 1R8 1.8
SIL530 - 2R2 2.2
SIL530B - 2R2 2.2
SIL530 - 2R7 2.7
SIL530 - 3R3 3.3
SIL530B - 3R3 3.3
SIL530 - 3R9 3.9
SIL530 - 4R7 4.7
SIL530B - 4R7 4.7
SIL530 - 5R6 5.6
SIL530 - 6R8 6.8
SIL530A - 6R8 6.8
SIL530B - 6R8 6.8
SIL530 - 8R2 8.2
SIL530 - 100 10.0
SIL530A - 100 10.0
SIL530B - 100 10.0
SIL530 - 120 12.0
SIL530 - 150 15.0
SIL530 - 180 18.0
SIL530 - 220 22.0
SIL530B - 220 22.0
SIL530 - 270 27.0
SIL530 - 330 33.0
SIL530 - 390 39.0
SIL530 - 470 47.0
SIL530A - 470 47.0
SIL530B - 470 47.0
SIL530 - 560 56.0
SIL530 - 680 68.0
SIL530 - 820 82.0
SIL530 - 101 100.0
SIL530 - 121 120.0
SIL530 - 151 150.0
SIL530 - 181 180.0
1. Tolerance of inductance :
2. Irated is the DC current which cause the inductance drop less than 35% of its nominal inductance without current
and the surface temperature of the part increase less than 45 C.
3. Operating temperature: -20 C to 105 C (including self-temperature rise).
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
B
A
D
o
25 C, 100KHz, 0.1V
1
2
DCR Irated
( ) MAX
(Adc)
0.0250 5.00
0.0236 2.56
0.0250 3.80
0.0275 2.20
0.0313 2.04
0.0350 3.30
0.0433 1.60
0.0492 1.57
0.0480 2.70
0.0648 1.44
0.0720 1.32
0.0650 2.30
0.1009 1.17
0.1089 1.12
0.0750 1.50
0.0800 2.00
0.1175 1.04
0.1283 1.00
0.1100 1.20
0.1200 1.50
0.1316 0.84
0.1490 0.76
0.1660 0.72
0.2350 0.70
0.2600 1.00
0.2610 0.58
0.3780 0.56
0.3837 0.50
0.5870 0.48
0.4400 0.62
0.4900 0.75
0.6245 0.41
0.6990 0.35
0.9148 0.32
1.0200 0.29
1.2700 0.27
1.3500 0.24
1.5400 0.22
3 0%.
o o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
5.3
1.0
5.3
100.00
10.00
1.00
0.00
o
36
UNIT:mm/inch UNIT:mm/inch
A = 5.0 / 0.197 Max.
B = 5.0 / 0.197 Max.
C = 3.0 / 0.118 Max.
D = 1.5 0.1 / 0.059 0.004
181
151
121
101
820
680
560
470
390
330
270
220
180
150
120
100
8R2
6R8
5R6
4R7
3R9
3R3
2R7
2R2
1R8
1R2
0.01 0.10 1.00 10.00
CURRENT (A)
