Care And Assembly Instructions
THE ITEM IS INTENDED FOR OUTDOOR DOMESTIC USE ONLY NOT FOR COMMERCIAL USE.
Missing parts or damaged parts ?
Please call our Customer Service Center, US & Canada : 1-888-383-1932,
Monday - Friday, 9:00AM - 5:00PM Eastern Time, English & French.
Email: customerservice@agio-usa.com
For additional support on care and maintenance of your Agio outdoor furniture please visit our website
at: www.agio-usa.com/service-center/maintenance/ or http://www.agio-usa.com/service-center/costco-international.
PREPARATION
Before beginning to assemble this product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any parts are missing or
damaged, do not attempt to assemble this product. Stop and call our customer service center.
Manpower Suggested for Assembly : 2 Adults Recommended. Tools Required for Assembly: Wrench (included).
!
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install the product. It should not be used as a toy or tool. Children should not engage in the
operation, assembly, removal, or disassembly of the product.
7 PIECE WOVEN HIGH DINING FIRE SET
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ITM. / ART. 514876
1
.
AGIO
Advertisement
Table of Contents
Related Manuals for Agio 514876
Summary of Contents for Agio 514876
- Page 1 Please call our Customer Service Center, US & Canada : 1-888-383-1932, Monday - Friday, 9:00AM - 5:00PM Eastern Time, English & French. Email: customerservice@agio-usa.com For additional support on care and maintenance of your Agio outdoor furniture please visit our website at: www.agio-usa.com/service-center/maintenance/ or http://www.agio-usa.com/service-center/costco-international. PREPARATION Before beginning to assemble this product, make sure all parts are present.
-
Page 2: Table Of Contents
Table Of Contents Care nd Maintenance................Safety Information................Troubleshooting..................Swivel Chair Parts List ................Swivel Chair Assembly ................ 12-14 Fire Pit Parts List ................15-16 Fire Pit Assembly ................17-22 Furniture Cover ................... Distro Address.................. -
Page 3: Care Nd Maintenance
WARRANTY This product is covered under the manufacturer's warranty against defects in materials and workmanship. The warranty does not cover damage due to neglect, abuse, or weather related damage. To view our complete warranty, please visit our website at https://agio-usa.com/service-center/warranty-registration/. -
Page 4: Safety Information
Problems, Missing Parts? Before returning to your retailer, call our customer service department in the US and Canada at 1-888-383-1932, Monday-Friday, 9 a.m. – 5 p.m Eastern Time. English and French, or you may Email customerservice@agio-usa.com International Regions: Please visit... - Page 5 Safety Information The appliance area must be kept clear and free from combustible materials, gasoline, and other flammable vapors and liquids. Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water.
-
Page 6: Specifications
Safety Information IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS The cylinder supply system must be arranged for vapor withdrawal. This appliance shall be used only outdoors in a well-ventilated space and shall not be used in a building, garage, or any other enclosed space. When this appliance is not in use, the gas must be turned off at the supply cylinder. -
Page 7: Natural Gas Conversion
Safety Information NATURAL GAS CONVERSION Natural gas conversion must be performed only by your natural gas provider or service company. 1. SHUT OFF THE GAS SUPPLY TO THE UNIT AND ANY NEARBY ELECTRICAL SOURCE OR APPLIANCES. 2. Below the burner, carefully disconnect flex connector attached to the orifice holder (see step 1). 3. -
Page 8: Ignition Module
Safety Information Stick the conversion label on the rating plate as shown in Figure 2. Metal Rating Plate Serial Number : Model Number : ARR11400 This appliance has been converted to use Natural Gas G20. 2H @ 20 mBar Nom. Heat Input (gross) 16.0KW High, 2.5 kW Low PIN: 0063CT7348 Appliance Type A Country: GB Minimum clearance from combustible constructions: Rear: 60.9 cm. -
Page 9: Maintenance
Safety Information MAINTENANCE The flames should look like those in Figure 4. To clean the burner, use a soft brush after the burner has cooled completely. Never use a vacuum cleaner on the burner. It is recommended to store the fire pit indoors during winter if it will be subjected to freezing temperatures. -
Page 10: Troubleshooting
Troubleshooting Symptom Symptom Possible Causes Corrective Actions Possible Causes Corrective Actions No LP in tank, or NG Check the LP (propane) tank. Noise is caused by metal main not turned on. You may be out of gas. Or check expanding and Natural Gas valve at main. -
Page 11: Swivel Chair Parts List
Assembly Instructions Two Adults Recommended. Assembly Required Hand tighten Swivel Chair Parts List Fully tighten PARTS LIST DESCRIPTION ORDER PART # AS0190 SEAT FRAME RIGHT ARM AS0191 AS0192 LEFT ARM SWIVEL BASE AS0193 METAL PLATE HW0847 HW0015 SPRING WASHER HW0003 HW0450 (43 MM) SCREW (40 MM) BOLT... -
Page 12: Swivel Chair Assembly
Swivel Chair Assembly WARNING: Do not attempt to assemble the chair if any parts are missing or damaged. Perform all assembly steps on a flat, soft, non-abrasive surface to avoid scratching the finish. - Page 13 Swivel Chair Assembly...
- Page 14 Swivel Chair Assembly "U" BAR "U" BAR CAUTION : Failure to place metal plates (E) and above the "U" bar exactly as shown in the diagram will cause the bolt heads and nuts to damage the structure of the "U" bar. Damage due to over tightening of bolts or improper assembly could cause injury and may void your warranty.
-
Page 15: Fire Pit Parts List
Fire Pit Parts List PARTS LIST DESCRIPTION ORDER PART # CONTROL KNOB FP2329 GAS VALVE FP2330 THERMOCOUPLE FP4591 FLEX CONNECTOR FP4210 ELECTRODE FP4461 IGNITION MODULE FP4464 CHAIN FP1736 PROPANE ORIFICE FP2205 LP REGULATOR HOSE FP4302 FOOT CAPS FC0759 “AA” BATTERY HW0905 NATURAL GAS AIR SHUTTER FP1922... - Page 16 Fire Pit Parts List PARTS LIST DESCRIPTION ORDER PART # 1/4" X 30 MM BOLT HW0958 HEX BOLT DRIVER HW0252 CROSS POINT SCREWDRIVER HW0900 BURNER PAN PROTECTIVE RING FP4603 BURNER ASSEMBLY FP4604 LP SUPPORT FRAME FP4605 FIRE PIT TABLE TOP FP4606 BURNER COVER FP4607...
-
Page 17: Fire Pit Assembly
Fire Pit Assembly WARNING: Perform all assembly steps on a flat, soft, non-abrasive surface to avoid scratching the finish. - Page 18 Fire Pit Assembly...
- Page 19 Fire Pit Assembly Make sure the ignition is right next to the front panel with door.
- Page 20 Fire Pit Assembly...
- Page 21 Fire Pit Assembly √...
- Page 22 Fire Pit Assembly / Montage / Ensamblaje Make sure the battery and battery contacts are clean and dry prior to installation. Ensure the batteries are installed correctly with regard to polarity (+ and -). Remove batteries from furniture that is not to be used for an extended period of time.
-
Page 23: Furniture Cover
Furniture Cover... -
Page 24: Distro Address
Distro Address AGIO Manufacturer: Agio International Corporation 900 E Hamilton Ave, Suite 100, Campbell, CA 95008, USA Importer : Costco Wholesale UK Ltd / Costco Online UK Ltd Hartspring Lane Watford, Herts WD25 8JS United Kingdom 01923 213113 www.costco.co.uk MADE IN CHINA...
