SPECTRA
SPECTRA XL
OVERVIEW
This document provides installation and operation instructions for the following product(s):
PRODUCT NAME
Spectra
Spectra XL
INTRODUCTION
Spectra consoles are easy to learn and simple to
use - delivering all the features you need at an
aff ordable price. We sincerely hope that your new
Spectra will bring you years of trouble-free service.
We take great care to build in reliability and
serviceability at every stage of our development
and production processes.
OVERVIEW
SPECTRA
Spectra is a 19" wide console, capable of controlling
48 physical fi xtures (LEDs, dimmers, moving lights,
etc).
ORDER C ODE
54108-020
54109-020
MANUAL
To view the full manual, visit
SOFTWARE
Spectra runs ZerOS software, which is regularly
updated to bring new features and to keep your
console stable and secure. Software updates
are free of charge and can be downloaded from
strandlighting.com
always be running the latest release of software.
SPECTRA XL
Spectra XL is capable of controlling 96 physical
fi xtures (LEDs, dimmers, moving lights, etc), and
includes a DVI-D output for optional external touch
screen monitor.
ACCESSORIES
Flightcases, Replacement PSUs, Dustcovers and
Side Brackets are all available for Spectra. Visit
strandlighting.com
1
QUICK START GUIDE
9850-000840-00
strandlighting.com
. It is strongly recommended to
for more information.
.
