- Page 1 AIRWAVE User Manual All Contents © Bond Audio LLC 2025...
-
Page 2: Important Safety Information
Do not impede ventilation by placing objects on top of the apparatus which extend past the rear edge of its cabinet. • Please contact Supro directly or a qualified person for tube replacement. • The AC plug is the mains disconnect. The plug should remain accessible after installation. -
Page 3: Table Of Contents
5.3 Shaping Your Tone.............................. 5.3.1 Noise Gate............................5.3.2 EQ..............................5.3.3 Enhancer............................5.3.4 Reverb............................5.4 Importing Cabinets in the Airwave........................5.5 Saving and Loading Presets..........................6. Creating a Preset with a 3rd-Party IR 6.1 IR Choice................................6.2 Importing IRs in the Airwave.......................... - Page 4 10.1 Clipping the Input or Output..........................10.2 Communication with Remote......................... 10.3 System Error..............................11. Want more cabs? 11.1 Two notes Cabinets............................11.2 .tur Files................................12. Setup Manager 13. Two notes Technical Support 14. Troubleshooting 15. Supro Warranty Policy 15.1 USA/Canada Warranty............................ 15.2 International Warranty............................
- Page 5 A total of 128 individual presets and a host of additional software features can be accessed by running the Supro Airwave Two notes application via USB-C connection for PC and MAC or wirelessly via Bluetooth on Android and iOS devices.
-
Page 6: Anatomy And Usage
2. ANATOMY AND USAGE 2.1 FRONT PANEL INPUT Instrument input. VOLUME Controls the gain of the preamp. Higher settings cause break-up in the preamp section. TREB Controls the amount of treble in your tone. MIDS Controls the amount of midrange in your tone. BASS Controls the amount of bass in your tone. -
Page 7: Rear Panel
Two notes system and a “virtual” single-ended 6L6 power amp emulation is automatically engaged. PRE mode is indicated when this switch is Blue in color. In POST mode, the signal from the Airwave’s 6V6 power amp feeds the Two notes system. POST mode is indicated when this switch is Amber in color. -
Page 8: Tubes
4-ohms to the amplifier. RESET This recessed switch causes the Two notes module to reboot. 2.3 TUBES Each Supro tube amplifier is 100% analog. Viewed from the rear of the chassis: ECC83/12AX7 V102... -
Page 9: Torpedo Remote
If after inputting the pin code the Airwave does not show up in the “Devices” menu in Torpedo Wireless Remote, you will need to unpair the Airwave in the list of devices that are paired in the Bluetooth menu of your phone. Once you have done this, please redo the procedure detailed above. -
Page 10: Creating A Preset With A Virtual Cabinet
5. CREATING A PRESET WITH A VIRTUAL CABINET A preset contains: - a cabinet - two (selected from a choice of 8) microphones and their positions within the room - effects settings (eq, Enhancer, Reverb, Twin Tracker) - levels for left and right outputs... -
Page 11: Cabinet Choice
To create a preset, first select a cabinet. Airwave comes with a collection of 12 Virtual Cabinets already loaded into the internal memory. Click on the blue screen or the arrow (next to it) to access the list of cabinets in your Airwave. -
Page 12: Enhancer
0 and +15dB. 5.3.4 REVERB There are 12 room reverbs and one full ‘custom’ reverb in the Airwave. When using the Custom Reverb, you have access to the following parameters: - Dry/wet: adjusts the level of the incoming signal and the reverb. With the know at halfway, both levels are equal. -
Page 13: Importing Cabinets In The Airwave
5.4 IMPORTING CABINETS IN THE AIRWAVE To import or remove cabinets in the Airwave, you need to register your Airwave via Torpedo Remote to your Two notes account. You cannot import or remove cabinets when using Torpedo Remote in Guest mode. Use the CABINET MANAGER tab to manage the Two notes Virtual Cabinets in Airwave. -
Page 14: Saving And Loading Presets
5.5 SAVING AND LOADING PRESETS The preset rack at the top of the screen lets you save and load presets in the Airwave. There are 128 memory slots for presets. Use the PRESET MANAGER tab to manage the presets in Airwave. The Left panel indicates the preset folders on your computer. -
Page 15: Creating A Preset With A 3Rd-Party Ir
The Airwave can load up to 512 IRs. All imports of IRs are done by Torpedo Remote through the IR manager (via computer). Upon upload into the Airwave, the IRs length can be set to 20, 40, 100 or 200 ms long. If the IR is longer it will be shortened by Torpedo remote to the selected length. -
Page 16: Importing Irs In The Airwave
The left panel is the files on your computer. You can browse the folders where you have stored your IRs. The right side represents the IR files that are loaded in the Airwave. You can drag and drop the IRs from the computer (left) to the Torpedo (right). -
Page 17: Output Routing
7. OUTPUT ROUTING 7.1 STEREO ROUTING The Airwave allows for different routings of the In Stereo, both outputs send the same cab sim signal. XLR outputs. They can be set to STEREO or to In Stereo, you have access to the Twin Tracker and all DUAL/MONO. -
Page 18: Dual Mono Routing
7.2 DUAL MONO ROUTING This routing allows you to send independent signals from each XLR outputs. You will be able to set a different EQ and dry/wet reverb level to the right XLR output. The layout of the Torpedo Remote will show you an additional EQ next to the right output fader. -
Page 19: Space Knob Assignment
Setup Manager anywhere between 410hz and 490hz, defaults at 440hz. 9. FLASHING RED LED The Airwave is equipped with a red LED to signal the following events or issues with your Airwave: - Clipping of the input or the output stages of the Two notes module in the Airwave... -
Page 20: Clip Led
10.1 CLIPPING THE INPUT OR OUTPUT It is possible to overload the input or output stages of the Two notes module in the Airwave. The red LED will then light up, according to the signal. Start by turning the Rear panel Output Level down. If the LED is still lighting up when you play, you are clipping the input of the Two notes module in the Airwave. -
Page 21: Want More Cabs
You can preview any cabinets that are not in your license when using Desktop Remote. This is why when you browse the cabinets in the Remote the list is way bigger than what you have in your license or in your Airwave. -
Page 22: Tur Files
This box allows you to transfer the cabinet you are previewing from your computer to your Airwave (as long as you have memory slots available in your unit). When you are previewing a cabinet that you do not own, random silences are inserted and you only have access to one mic to preview the cabinets. -
Page 23: Two Notes Technical Support
13. TWO NOTES TECHNICAL SUPPORT Should you encounter a problem with the Two notes functionality of your Airwave or need help regarding any technical aspects, please note that Two notes Audio Engineering has developed on-line services to provide you with fast and efficient technical support, the Two notes Help Desk. -
Page 24: Supro Warranty Policy
2 years), customer pays shipping to Supro USA and Supro USA pays return ground shipping. If the amplifier is returned to Supro and the cause is proven to be oversight or user error, customer will be responsible for return shipping. -
Page 25: International Warranty
Most often they will be able to assist you with replacement parts or service. 2) If your dealer is unable to help, call the authorized Supro distributor in your country (you can find their details on our website). They have the technical staff and experience to assist you, and also have all of the resources of Supro engineers at their disposal. - Page 26 suprousa.com All Contents © Bond Audio LLC 2025...
