- Page 1 Watchman 450 Installation Guide Created February 2025 (855) 694-2837 cell-gate.com...
- Page 2 cell-gate.com (855) 694-2837...
-
Page 3: Table Of Contents
Contents Items Included............Standard Power Wiring..........InHand Router............Wiring Blue Board............ Wiegand............Gate Status from Gate Operator....Dry Contact Relay, Normally Open....Dry Contact Relay, Normally Closed..... Wet Contact Relay, Normally Open....Wet Contact Relay, Normally Closed..... Mounting to a Pedestal..........(855) 694-2837 cell-gate.com... -
Page 4: Items Included
Items Included • Watchman 450 Unit • Blue Board • Ethernet Switch • InHand Router • 12 Volt DC Power Supply • Keys • Flangenuts 1/4” (x4) • Carriage Bolts 1/4” x 1” (x4) • Customer Information Packet We do not recommend running wires over 60 feet. -
Page 5: Standard Power Wiring
You will need to splice it down to a thinner wire. Use the Type-B grounded plug that is supplied with the transformer. For solar power wiring instructions, please contact CellGate. (855) 694-2837 cell-gate.com... -
Page 6: Inhand Router
InHand Router For Use in W450 Version: AA1WPE-ATT / AA1WPE-VZN Product ID: M780 Power: Indicates the device is on Status: Indicates device state/troubles Cellular: Indicates device communication Signal: Indicates strength of signal cell-gate.com (855) 694-2837... - Page 7 Not for use with this device Do not remove the SIM card tray unless specifically advised by tech support. The SIM card tray contains both AT&T and Verizon SIM cards. They can only be swapped online by tech support. WAN / LAN1: Plugs Cellular 1 &...
-
Page 8: Blue Board
Blue Board Below is the blue board inside the device. It provides power to the router and other accessories, such as cameras. It’s also the central control interface between the faceplate and the router. • Wire main power from transformer to the power connector on the blue board. •... -
Page 9: Wiegand
You will likely need to program the output of the gate operator. Warning: You must wire into a DRY CONTACT the Gate Operator. Applying power to the input on the blue board will damage it. Gate statuses can be inverted. If needed, please call CellGate to invert. (855) 694-2837 cell-gate.com... -
Page 10: Dry Contact Relay, Normally Open
Dry Contact Relay, Normally Open Dry Contact Relay, Normally Closed cell-gate.com (855) 694-2837... -
Page 11: Wet Contact Relay, Normally Open
You must use a diode to maintain warranty. Contact CellGate for diode instructions. Wet Contact Relay, Normally Open Wet Contact Relay, Normally Closed (855) 694-2837 cell-gate.com... -
Page 12: Mounting To A Pedestal
Mounting to a Pedestal If a flush mount is preferred, please contact CellGate for instructions. Corner holes are 5mm in diameter. Gasket is already attached to the back of the device. Attach a 14-gauge grounding wire from one of the carriage bolts to a grounding rod. - Page 13 (855) 694-2837 cell-gate.com...
