Summary of Contents for CellGate CR-Reader
- Page 1 CellGate Support: � (���) ���-����, Option �...
-
Page 2: Product Overview
Before using the device, check the device model and ensure that the shipped box includes the following items: x � x � x � x � x � Embedded junction box CR-Reader Rope Allen wrench Rubber plug (S,M,L) mounting bracket x � x �... -
Page 3: Voltage And Current Specifications
Voltage and Current Specifications Use 12V DC 1A power supply with 18 gauge wiring to power the device. Installation Guidelines Install the device on a at surface. Do not use or place the device near heating objects. Warning! To ensure your safety, avoid touching the power cord, power adapter, and device with wet hands, bending or pulling the power cord, damaging any components, and only use the quali ed power adapter and power cord. -
Page 4: Installation
Installation Step �: Bracket Installation Wall-Mounting Installation Mark the positions of the four holes of the junction box. Drill the four marked holes using a 1/4" (6 mm) drill bit. The drilled holes should be 30 Note: The junction box should be at least 43 inches (1100 mm) above the ground. - Page 5 Flush-Mounting Installation Fill the gap between the hole Cut a hole with dimensions � �/� in �� mm and the junction box with 3 and 3/8 inches high, 3 and concrete or other 3/8 inches wide, and 1 and non-corrosive construction 1/4 inches deep.
-
Page 6: Warranty
Warranty CellGate does not cover intentional mechanical damage or destruction caused by improper installation. Please contact CellGate support team if the device does not operate as expected. Support For assistance, call: 1 (855) 694-2837, Option 3 Additional resources can be found at: www.cell-gate.com Information contained in the document is believed to be accurate and reliable at the time of printing.
