Unite LED Display
5000 Series
135HDL50151A
User Manual (English)
www.philips.com/ppds

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Unite 5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Philips Unite 5000 Series

Summary of Contents for Philips Unite 5000 Series

  • Page 1 Unite LED Display 5000 Series 135HDL50151A User Manual (English) www.philips.com/ppds...

  • Page 2: Table Of Contents

    Unpacking and Installation ......... 9 Input Mode ..............77 2.1. Unpacking ............9 10. Technical Specifications ..........79 2.2. Package Contents ..........10 Warranty policy for Philips Professional Display 2.3. Installation Notes ..........10 Solutions .................83 2.4. Installation process ..........11 2.5. Installation Guidance ........12 2.6.

  • Page 3: Safety Instructions

    When turning off the display by detaching the power cord, wait 6 seconds before re-attaching the power cord for normal operation. • Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your local service center. •...

  • Page 4: Eu Declaration Of Conformity

    135HDL50151A • Environmental absolute ratings Item Min. Max. Unit Operation temperature °C Storage temperature °C Operation humidity % RH Storage humidity % RH • The lifetime of the display stated in this specification is only guaranteed if the display is used under the proper operation conditions.

  • Page 5: Federal Communications Commission (Fcc) Notice (U.s. Only)

    135HDL50151A Federal Communications Commission (FCC) Notice (U.S. Only) NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 6: Polish Center For Testing And Certification Notice

    135HDL50151A Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source. The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A).
  • Page 7 135HDL50151A Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows:+ 1. Remove fuse cover and fuse. 2.
  • Page 8 135HDL50151A China RoHS 根据中国大陆《电器电子产品有害物质限制使用管理办法》，以下部分列出了本产品中可能包含的有害 物质的名称和含量。 有害物质 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr (VI)) (PBB) (PBDE) 外壳 显示面板 电路板组件* 电源适配器 电源线/连接线 遥控器 本表格依据SJ/T 11364 的规定编制。 *: 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路、连接器等。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。 上表中打“X”的部件， 应功能需要， 部分有害物质含量超出GB/T 26572规定的限量要求， 但符合欧盟 RoHS法规要求...

  • Page 9: Turkey Rohs

    Please find out about the local regulations on how to dispose of your old display from your local Philips dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.

  • Page 10: Waste Electrical And Electronic Equipment (Weee)

    For more information about E -waste please visit http://www.india.philips.com/about/sustainability/recycling/index.page and to know where you can drop off your waste equipment for recycling in India please contact on below given contact details.

  • Page 11: Unpacking And Installation

    135HDL50151A Unpacking and Installation 2.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • As this product is high and heavy, the operation of moving the device is recommended to be performed by two technicians. •...

  • Page 12: Package Contents

    135HDL50151A 2.2. Package Contents Please verify that you received the following items with your package content: • LED display cabinet x 5 pcs • Power supply box& accessories • Modular Meeting Room box & accessories • Quick start guide • Crossbeam x 2 pcs •...

  • Page 13: Installation Process

    135HDL50151A 2.4. Installation process This chapter introduces the installation process of the product. 2.4.1. Installation Preparation Inspection： • Packing -- Complete, No breakage. • Complete screen appearance -- No scratches. Installation Preparation: • Good environmental perspective, good vision; • Good ventilation conditions; •...

  • Page 14: Installation Guidance

    135HDL50151A 2.5. Installation Guidance Warning: the height of the AIO depends on the height of the supporting steel structure, the display surface must be flat within the tolerance range of /-0.1 mm and must keep perpendicular to the datum. 2.6. Wall Mount Installation Take out the crossbeams and connect it with screws, as shown in Figure 1 and Figure 2 Figure 1 Crossbeam...
  • Page 15 135HDL50151A Through the installation fixture, determine the position of the upper crossbeam according to the vertical datum line of the level. Fix the upper crossbeam to the wall using expansion screws and remove the fixture after use, as shown in Figure 4 and Figure 5.
  • Page 16 Rail mounting plate C Rail mounting plate D Rail mounting plate E Rail mounting plate F 135HDL50151A Rail mounting plate C Rail mounting plate D Rail mounting plate E Rail mounting plate F Notice: Pull the rails apart to expose the screw holes Notice: Pull the rails apart to M4x10...
  • Page 17 135HDL50151A Hang the cabinet X-X-A on the groove of the crossbeam through the hangers , as shown in Figure 8. Figure 8 Side View of Crossbeam Installation & Diagram of Hanger Installation In the order of A->B->C->D->E, the adjacent cabinets are assembled using positioning posts and magnetic suction, and suspended from left to right, as shown in Figure 9.
  • Page 18 135HDL50151A Before locking the adjacent cabinets, some modules need to be removed in order using the vacuum tool(the light-colored parts in the Figure 10 are the modules that need to be removed.), use the hex screwdriver to lock the B and A, C and B, D and C, E and D cabinets in sequence through the quick locks.
  • Page 19 135HDL50151A Install the Power supply box and slide rails on the cover plate. Remove the connector from the cover plate and install the box on it, then tighten them with screws at the marked hole position, as shown in Figure 12. 500mm Slide Rail A* This Slide Rail is shipped as a whole *Pull the Slide Rail apart and press the pick as shown in the Figure...
  • Page 20 135HDL50151A 11. Use the vacuum tool to remove the 5 modules as shown in Figure 14; and then use the hex screwdriver to lock the Bottom sound bar and the screen(5 modules correspond to five holes). Make sure that the power cord brought on the bottom of the cabinet passes through the corresponding hole on the Bottom sound bar, as shown in Figure 14.
  • Page 21 135HDL50151A 14. Connect the power cord inside the Bottom sound bar to the power cord on the cabinet, and plug the network cable inside the Bottom sound bar into the network port under the cabinet. There are a total of five sets of wires, as shown in Figure 15. Then put all the removed modules back in place in the sequence.
  • Page 22 135HDL50151A The side with this gap The side with this gap M3x6 is the bottom side of the frame is the bottom side of the frame Rear Rear Front Front Left �nishing frame Right �nishing frame Figure 17 Install the left & right finishing frame...
  • Page 23 135HDL50151A 17. Install the edge finishing frames and front panels of bottom sound bar on the display, as shown in Figure 18. Top �nishing frame M4x16 (The screws removed from the cabinet corner protector) Left �nishing frame Right �nishing frame M3x6 M3x6 M3x6...

  • Page 24: Pedestal Mounted Installation

    135HDL50151A 2.7. Trolley Installation Contents Packaging contents of the trolley: Note: The trolley is an optional accessory with the part number: BM005015/00. The side with Unite LED Display 5000 Series these screw holes 135HDL5015IA is the front side The side with these screw holes is the front side Front 135°...
  • Page 25 135HDL50151A Insert Part B to Part A and fix them with M6x16 screws. M6x16 M6x16 M6x16 M6x16 Front 135° view Front 135° view Install the right Crossbeams* and fix them with M8x60 screws. *Crossbeams are included in the packaging of the display. M8x60 M8x60 M8x60...
  • Page 26 135HDL50151A Insert the left crossbeams* to the right crossbeams and fix them with M8x60 & M4x12 screws. *Crossbeams are included in the packaging of the display. M8x60 M4x12 M8x60 M4x12 Front 135° view...
  • Page 27 135HDL50151A Step 1: Loosen the Lock’s fixing screws(as shown in the picture),re-lock them after Step 2; Step 2: Insert Part C & D to Part A and fix them with M6x16 screws. M6x16 M6x16 Front 135° view...
  • Page 28 135HDL50151A After completing all Trolley installations, refer to the previous steps (Step 2.6 Wall Mount Installation) for Display installation. Install the Back Cover Plate after completing all display installations(Step 2.6 Wall Mount Installation). Rear 135° view...

  • Page 29: Pressure Plate

    135HDL50151A Install the Pressure plate* and fix them with M5x12 screws*, after completing Back Cover Plate installation. *Pressure plate and M5x12 screws are included in the packaging of the display. M5x12 Pressure plate M5x12 mm Pressure plate Rear 135° view Schematic diagram of the �xed position of the pressure plate Front 45°...

  • Page 30: Parts And Functions

    135HDL50151A Parts and Functions 3.1. Inserting the batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace the batteries: 1. Press and then slide the cover to open it. 2. Insert the batteries with the correct polarity (+) and (–). 3.

  • Page 31: Remote Control

    135HDL50151A 3.2. Remote Control [ ] INFO button Show Information OSD. 3.2.1. General functions NAVIGATION buttons Root Menu: Go to the OSD of Smart picture. Main Menu: Move the selected item up to make adjustment. IR Daisy Chain Menu: Increase the controlled Group ID number.

  • Page 32: Id Remote Control

    135HDL50151A 3.2.2. ID Remote Control Press the [ID] button and the red LED blinks twice. 1. Press [ID SET] button for more than 1 second to enter the Set remote control ID number when using several displays. ID Mode. The red LED lights up. Press the [ID SET] button again will exit the ID Mode.
  • Page 33 135HDL50151A 3.2.3. Remote Control buttons on Android [PLAY] buttons source Control playback of media files. [ ] Play the media files directly. [ ] Pause playing. [ ] Stop playing media files. After stopping playing by pressing [ ] button, press [ ] again, playback will be started from the beginning of the file.

  • Page 34: Volume Button

    135HDL50151A ] OPTIONS button Open toolbox in Media Player or PDF Player. 1. Media Player or PDF Player -> Compose -> Edit or add a new playlist -> press [ ] to open toolbox. The toolbox will slide in from the left side of the screen. [ ] POINTER button Reserved.

  • Page 35: Handling The Remote Control

    135HDL50151A 3.3. Handling the remote control • Do not drop or apply shock to the remote control. • Do not allow any liquid to get inside the remote control. If water has entered the remote control, wipe the remote control with a dry cloth immediately.

  • Page 36: Connecting External Equipment

    135HDL50151A Connecting External Equipment 4.1. Connecting External Equipment (Multimedia Player) 4.1.1. Using HDMI video input HDMI IN Multimedia Player [HDMI IN] HDMI Out Connecting a PC 4.2. 4.2.1. Using DVI input IR-IN IR-OUT AUDIO DVI-I IN LINE IN Audio Out DVI Out [AUDIO IN] [DVI IN]...

  • Page 37: Connecting Audio Equipment

    135HDL50151A 4.2.3. Using DP input RS232 RS232 DVI-I DP IN DP Out [DP IN] 4.3. Connecting Audio Equipment 4.3.1. Connecting an external audio device Audio In [AUDIO OUT] Stereo Ampli�er AUDIO...

  • Page 38: Connecting Multiple Displays In A Daisy-Chain Configuration

    135HDL50151A 4.4. Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a menu board. 4.4.1. Display control connection Connect the [RS232 OUT] connector of DISPLAY 1 to the [RS232 IN] connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [RS232]...

  • Page 39: Wire-Connecting To Network

    135HDL50151A 4.7. Wire-connecting to Network INTERNET ROUTER [RJ-45] [RJ-45] Network Settings: 1. Switch the router on and enable its DHCP setting. 2. Connect the router to this display with an Ethernet cable. Setup 3. Press [ ] HOME button on the remote control, then select Connect to network 4.

  • Page 40: Operation

    135HDL50151A Operation 2. Admin mode: • Press “Home + 1888” to enter the Admin mode. Please NOTE: The control button described in this section is mainly make sure that you see the Home OSD menu after “Home” is pressed, and then press 1888 in sequence. on the remote control unless specified otherwise.

  • Page 41: Media Player

    ■ USB AutoPlay: media player autoplay media file of USB storage. Days of the week: „ Set Sunday, Monday, Tuesday, Wednesday, Thursday, Friday, Saturday. Every week: „ Set a weekly schedule. Save: 5) Help page „ Save the schedule. Display QR to link to Philips support website.

  • Page 42: Media Player Introduction

    4. If an empty playlist is selected, the App will guide you path will then be displayed. through selecting the media source. All media files should be stored in /philips/ of root directory. For example, videos: {root dir of storage}/philips/video/...
  • Page 43 135HDL50151A 7-1 From the side menu bar, the following functions are 10. After selecting the desired file, press “Play” key to play available: the media file immediately. - select all: select all storage files. - delete all: delete all playlist files. - add/remove: update playlist from source.

  • Page 44: Browser

    Note: If the playlist contains video and music files, the screen becomes black when playing music file. Step 2. Copy “mpplaylistX.txt” to “philips” folder of internal storage. You may use FTP to do this. 3. Use the on-screen keyboard to enter URL and press the File path : /storage/emulated/legacy/philips (for OK button, the data will be saved in the List.
  • Page 45 135HDL50151A • Select a browser file. 4. Press “Option” and a list will appear on the left side. • Import the browser file and the URL will be listed on the Import: Import the file of URL list screen. Export: Export the file of URL list Delete all: Delete all URL records from the main screen Back: Close the side menu bar •...
  • Page 46 135HDL50151A • Select the storage where the file will be exported to. • A dialog box displays the path of the file to be saved as well as the file name. Press the “Save” button to save the URL. 7. Press “Settings” then enter the next page. 5.
  • Page 47 File name: bookmarklist.txt. Content: b. If the enable checkbox is checked, you can set the reload time. Step 2. Copy bookmarklist.txt to “philips” folder of your internal storage. You may use FTP to do this. File path: /storage/emulated/legacy/philips (for DL, Ex. /storage/emulated/legacy/philips/bookmarklist.txt 7.3 Signage mode...

  • Page 48: Pdf Player

    135HDL50151A 5.6. PDF Player If the network is disconnected while the OSD scheduler is opening the browser app, the browser app will automatically open the URL 1 address home page from 5.6.1. OSD menu interaction with PDF player: local storage. 1.
  • Page 49 4. If an empty playlist is selected, the App will guide you through selecting the media source. - Back: return to the previous menu. All media files should be stored in /philips/ of root directory. For example, pdfs : {root dir of storage}/philips/pdf/...
  • Page 50 Ex. pdfplaylist1.txt, pdfplaylist2.txt Content: Step 2. Copy pdfplaylistX.txt to “philips” folder of the internal storage. You may use FTP to do this. File path : /storage/emulated/legacy/philips (for DL, Ex. /storage/emulated/legacy/philips/pdfplaylist1.txt Step 3. Add the PDF files to the “PDF” folder in the “philips”...

  • Page 51: Custom App

    135HDL50151A Setting 5.7. Custom App Set up the application for Customer Source. 6.1. Settings Note: (1) It only displays the App installed by user. Enter PD settings by clicking “Settings” icon in Admin mode. (2) System’s pre-installed App is not displayed. 5.7.1.
  • Page 52 135HDL50151A Wi-Fi Preference Wi-Fi Off Settings -> Network & Internet -> Wi-Fi -> Wi-Fi Preference Wi-Fi On Using WPS WPS network can be enabled using 2 options: PBC (Push Button Configuration), in which the user simply has to push a button to connect. PIN (Personal Identification Number), in which a PIN will be On the available network list, select an AP (access point) on entered in client WPS device to connect.

  • Page 53: Connected Devices

    135HDL50151A 6.1.1.4. Wi-Fi Hotspot Note: This system provides “Wi-Fi Hotspot”. Wi-Fi connection will be disabled automatically when Ethernet connection is enabled. Ethernet Static IP “Wi-Fi hotspot”: Share network through Wi-Fi. When it is enabled, the Wi- When the Connection Type is changed to “Static IP”, the user Fi turns off connection and becomes a hotspot AP (access can manually set the Ethernet IP Address, Gateway, Netmask point).
  • Page 54 Philips logo and replace it with the user selected boot animation file. If user does not set a boot animation file for User mode, the default Philips boot animation will be displayed during boot time. Click “Choose Boot Animation” to pop up a dialog for Boot animation file can be replaced by using the “SAVE”...

  • Page 55: Email Notification

    The screenshot feature is suspended when the system (5). Save to enters sleep mode. The function of mailing out the The screen images will be saved in the folder “philips/ screenshot is consequently suspended. The screenshot- screenshot” of the internal storage.
  • Page 56 135HDL50151A SMTP Set up the sender E-mail address and SMTP server information. There are two types of SMTP server for user to set up: “Gmail” and “Other”. By using the “Other” option, user can manually set up an STMP server, security type and server port.
  • Page 57 135HDL50151A You may be prompted to log in to your Google Account again to confirm your identity. Step 4 - Create the App Password Click on the “App Password” option to create a new application password: Step 5 - Add New App Name Step 3 - Use your phone to complete configuration First, select a device (for example, Windows Computer) and Use on-screen instructions and available options to complete...
  • Page 58 135HDL50151A Record the auto-generated app password or simply select it (4). Port: The port number for the FTP server is available in the and copy to the clipboard for later use. range from 1025 to 65535, the default setting is 2121. The following port number cannot be used: 8000 / 9988 / 15220 / 28123 / 28124 and SICP network port (default 5000).

  • Page 59: Network Application

    135HDL50151A 6.1.3.3. Source Settings (1). FORGET button Clear the custom source application. It will be grayed out if Settings -> Signage Display -> Source Settings the customer source application has not been set. Users can configure the detailed options of the source APK. (2).

  • Page 60: Important Note

    Clear the data under {storage}/philips/folder of the internal and external storage. (1). All Import & Export Clear the folder “Philips” from the internal storage and USB. Settings -> Signage Display -> System Tools -> Import & Export (2). Internal Storage Clear the folder “Philips”...
  • Page 61 Note: Security If the selected storage (internal storage, USB external storage ) does not contain Philips/folder, then the system will create Settings -> Signage Display -> System tools -> Security it automatically. External Storage Lock A list of all available storage (internal storage and USB...
  • Page 62 If disabling logging, all data will be saved to a zip file such Only the USB port near the Ethernet port can support scaler as {root directory of USB storage}/ philips/Log/xxBDL4650D- firmware update. Log-{ yyyy-MM-dd-HH-mm-ss }.zip System will automatically search “{panel size}_4650D.bin” in...
  • Page 63 135HDL50151A 6.1.5. Security The prefix of the filename for the panel size must match the panel size of the platform. Settings->Security For example, in 65BDL4650D platform, only 65_4650D.bin can be accepted. Please note that: Keep the system power on during Scaler FW update, do not 6.1.5.1.

  • Page 64: Developer Options

    135HDL50151A On-screen keyboard Let user set default software IME (Virtual keyboard) and control detailed IME settings. The Japanese IME will automatically be installed when user selects Japanese language in OOBE. Developer options Settings -> System -> Developer options Physical keyboard Android developer options for developers, default is on and USB debugging is on by default.

  • Page 65: Supplementary

    135HDL50151A 6.2. Supplementary mode Loop delay-time Folder1 mode Loop delay-time Folder2 6.2.1. Quick Info An example of a desc.txt file is: Press “Info + 77” to startup quick info. 1920 1080 30 Quick info will show “Network” and “Monitor Information”. p 1 0 part0 Note: p 0 0 part1...
  • Page 66 Manager. 2.1 The next steps are the same as described above. Please note, each model may have different <internal storage path>. (b) Via Adb Shell 1. Make sure that your PC can connect to Philips Android Signage Display using adb.

  • Page 67: Osd Menu

    135HDL50151A OSD Menu 7.2. OSD Menu Overview An overview of the On-Screen Display (OSD) structure is 7.2.1. Picture menu shown below. You can use it as a reference for further adjustment of your display. Picture Brightness 7.1. Navigating the OSD Menu Contrast Screen Sharpness...

  • Page 68: Screen Menu

    135HDL50151A 7.2.2. Screen menu Noise reduction Reduce picture noise. You can select a suitable noise reduction level. Picture H position The options are: {Off} / {Low} / {Medium} / {High}. V position NOTE: This item applies to VGA input only. Screen Clock Gamma...

  • Page 69: Audio Menu

    135HDL50151A 7.2.3. Audio menu This mode displays the image pixel- by-pixel on screen without scaling the Picture Balance original image size. Treble 16:9 Screen Bass The picture is reproduced in 16:9 Volume Audio format and a black band at the top Audio out (line out) and bottom.
  • Page 70 135HDL50151A Sync. Volume The options are: {Small} / {Medium} / {Large}. Enable/disable audio out (line out) volume adjustability to PIP position sync with internal speakers volume, but PD Internal speaker Select the position of sub picture in PIP (Picture-in-Picture) sound will be forced to be mute. mode.

  • Page 71: Configuration1 Menu

    Choose from : {Off} / { On} Configuration1 reset Action Advanced Option Light sensor (require Philips accessory CRD41 External Sensor Box) Choose to turn on or off backlight adjustment according to environment brightness. Choose from : {Off} / { On}...

  • Page 72: Configuration2 Menu

    135HDL50151A • 20/40/60/80/100. Factory reset Logo Choose to enable or disable the picture of Logo when ENERGY STAR ® turning on your display. The options are: Cancel Reset • {Off} • {On} • {User} NOTE: If it is set to {USER}, the rotation function is not 7.2.6.

  • Page 73: Advanced Option Menu

    135HDL50151A 7.2.7. Advanced option menu Monitor information Show information about your display, including model number, serial number, operation hours and software version. Monitor information Model name XXXXXX Serial NO. Operation hours 74 H 33 M SW Version V0.217 DP Version The options are: {DP 1.1} / {DP 1.2}.
  • Page 74 135HDL50151A • {Lock All} / {Lock all but Volume} / {Lock all but Power} • {Position} - Select the position of this display in the screen / {Lock all except PWR & VOL} - Disable the keyboard matrix. function. • {Frame comp.
  • Page 75 135HDL50151A 1. Press [OK] button to enter or make a selection. 4. For additional schedule settings, press [ ], then repeat the steps above. A check mark in the box next to the number of 2. Press [ ] back button to return. the schedule item indicates that the selected schedule is in 3.
  • Page 76 135HDL50151A Power Save Power save modes Mode 1: [TCP off, WOL on, auto off] DC off -> Power off, Android(ARM) off, LED: Red. Power Save -> Power off, Android(ARM) off, LED: Red Mode 2: [TCP off, WOL on, auto on/off] DC off ->...

  • Page 77: Supported Media Formats

    135HDL50151A Supported Media Formats USB Multimedia Codec Formats Video Decode Type Video Codec Container Decode Encode Channel Remark MPEG program stream (.DAT, .VOB, .MPG, .MPEG) MPEG transport stream (.ts) Max Resolution: 1080P@60fps MPEG1/2 MPEG1/2 MP4 (.mp4) Max Bit Rats : 40Mbps AVI (.avi) MKV (.mkv) MP4 (.mp4)
  • Page 78 135HDL50151A Image Decode Type Image Codec Photo Decode Encode Channel Remark Max Resolution: 7000 x 7000 JPEG JFIF file format 1.02 File Format: JPG, JPEG The limitation of max resolution depends on DRAM Max Resolution: 15360 x 8640 File Format: BMP The limitation of max resolution depends on DRAM Max Resolution: 15360 x 8640...

  • Page 79: Input Mode

    135HDL50151A Input Mode DVI/VGA timing support: Item Mode Resolution H.Freq. (KHz) V.Freq. (Hz) Comment IBM VGA 10H 640x350 31.469 70.086 IBM VGA 12H 640x480 31.469 59.94 Tiling mode not supported MACINTOSH 640x480 66.67 Tiling mode not supported VESA 640x480 37.861 72.809 Tiling mode not supported VESA...
  • Page 80 135HDL50151A 4K2K Item Resolution H.Freq. (KHz) V.Freq. (Hz) Comment 3840x2160 53.946 23.900 3840x2160 24.000 3840x2160 56.25 25.000 3840x2160 67.432 29.900 3840x2160 67.5 30.000 4096x2160 24.000 3840x2160 60.000 Tiling mode not supported Custom zoom not supported Video Timing support(HDMI/DVD HD/DVI) Item Mode Resolution Comment...

  • Page 81: Technical Specifications

    135HDL50151A Technical Specifications LED Module: Item Specifications LED Type SMD1212 LED brand DSBJ Pixel constitation 1R1G1B LED part number DS1212T-RGB-S07 LED Pole type common anode LED Lifetime (Hrs, half brightness) 100,000 Pixel Pitch (mm) 1.5625 Module Size (WxH in mm) 300x168.75 Module Resolution (W×H in pixels) 192x108...
  • Page 82 135HDL50151A Picture: Item Specifications Brightness (nits) before calibration Brightness (nits) after calibration Color Temperature (K) default 6500 adjustable Color Temperature (K) adjust range 2000~10000 Viewing Angle (°) H/V 160/160 Brightness Uniformity ≥95% Color Uniformity ±0.006Cx,Cy within(after calibration) Color coordinates 0.312 0.329 Contrast Ratio 8000:1 Calibration (Brightness/Color)
  • Page 83 135HDL50151A I/O (CRD20049/99): Item Specifications DVI-I IN Audio 3.5mm Line In / Out DP-In / Out HDMI 2.0 in USB 3.0 A RS232 in/out 2.5 mm x1/1 IR Pass Trough 3.5 mm x1/1 RJ45 1G IR/OSD Key Speaker Out USB for Service RJ45 for Cabinet use Function (CRD20049/99): Item...
  • Page 84 135HDL50151A Miscellaneous: Item Specifications Regulatory approvals Certification FCC: FCC Part 15 EMI Class A EN 55032 EN 55035 EN/IEC 61000-3-2 EN 61000-3-3 LVD: EN 62368-1 ETL: UL 62368-1 Warranty 24 month. Extendable to 39 months Working environment (indoor/outdoor) Indoor...

  • Page 85: Solutions

    LIMITED WARRANTY In the unlikely event the product requires service, we will arrange for your Philips product to be serviced free-of-charge within the warranty period, provided that the product was used in accordance with the user manual (e.g. in the intended environment).
  • Page 86 Warranty period for PHILIPS signage display is listed as below, for areas not covered in this table, please follow their warranty statement. Standard warranty period for PHILIPS signage display is listed as below, for areas not covered in this table, please follow the local warranty statement.
  • Page 87 This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license.
