DVD/CD RECEIVER
KD-DV6406/KD-DV6405
For canceling the display demonstration, see page 5.
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0520-005A
[A]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KD-DV6406 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JVC KD-DV6406

Summary of Contents for JVC KD-DV6406

  • Page 1 DVD/CD RECEIVER KD-DV6406/KD-DV6405 For canceling the display demonstration, see page 5. For installation and connections, refer to the separate manual. INSTRUCTIONS GET0520-005A...
  • Page 2 Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

  • Page 3: Table Of Contents

    CONTENTS How to reset your unit INTRODUCTIONS Playable disc type ........4 Preparation ..........5 OPERATIONS Basic operations • Your preset adjustments will also be erased. • Using the control panel ....... How to forcibly eject a disc • Using the remote controller (RM-RK252) ..Listening to the radio ........

  • Page 4: Playable Disc Type

    Playable disc type Disc type Recording format, file type, etc Playable DVD-Video (Region Code: 4) * DVD-Audio DVD-ROM DVD Recordable/Rewritable DVD-Video (DVD-R/-RW * , +R/+RW * DVD-VR • DVD Video: UDF bridge DivX/MPEG1/MPEG2 • DVD-VR • DivX/MPEG-1/MPEG-2/MP3/ MP3/WMA/WAV WMA/WAV: ISO 9660 level 1, level 2, Romeo, Joliet JPEG/MPEG4 DVD+VR...

  • Page 5: Preparation

    Preparation Cancel the display demonstration and set the clock • See also page 24. Turn on the power. Enter the PSM settings. Cancel the display demonstrations Select “DEMO,” then “DEMO OFF.” Set the clock Select “CLOCK HOUR,” then adjust the hour. Select “CLOCK MIN”...

  • Page 6: Basic Operations

    Basic operations Using the control panel • FM/AM: Search for station. Enter functions mode. • DISC/CD-CH: Select chapter/track. • Press M MODE, then one of the following buttons • IPOD: Select track. (within 5 seconds)... • Turn on the power. MO : Turn on/off monaural reception.

  • Page 7: Display Window

    Display window Tr (track) indicator EQ (equalizer) indicator Source display / Track number / Folder number / Disc information indicators— Disc number / Title number / PBC indicator / Time TAG (Tag information), (folder), (track/file) countdown indicator Playback source indicators—DISC, CH (CD changer) Audio video indicator Main display (Time, menu, playback information) iPod indicator...
  • Page 8 button • Turns the power on if pressed briefly or attenuates the sound when the power is on. • Turns the power off if pressed and held. ∞ buttons • FM/AM: Selects the preset stations. • DISC: – DVD-Video: Selects the title. –...
  • Page 9 fi * ASPECT button buttons • Not applicable for this unit. • DVD-Video: Makes selection/settings. • CD-CH: Changes discs in the magazine. PHONE button • Not applicable for this unit. buttons • DVD-Video: Makes selection/settings. * SETUP button • DivX/MPEG Video: Skips back or forward by •...

  • Page 10: Listening To The Radio

    Listening to the radio Select “FM/AM.” Select the bands. Search for a station to listen—Auto Search. Manual Search: Hold either one of the buttons until “M” flashes on the display, then press it repeatedly. • When receiving an FM stereo broadcast with sufficient signal strength, “ST” lights up on the display.

  • Page 11: Disc Operations

    To listen to a preset station Preset number flashes for a while. Disc operations Before performing any operations... Turn on the monitor to watch the playback picture. If you turn on the monitor, you can also control playback of other discs by referring to the monitor screen.

  • Page 12: Operations Using The Control Panel

    Change the display information. Current chapter number and Elapsed playing time Current chapter number and Clock Current title and chapter number (back to the beginning) Current chapter number and Elapsed playing time Current chapter number and Clock Current program (or playlist) number and chapter number (back to the beginning) Elapsed playing time Folder number and Clock...
  • Page 13 After pressing M MODE, press the following buttons to... Disc type Skip 10 chapters (during CHAPTER RPT: play or pause) Repeat current chapter — TITLE RPT: Repeat current title Skip 10 chapters (during CHAPTER RPT: play or pause) Repeat current chapter PROGRAM RPT: —...

  • Page 14: Operations Using The Remote Controller

    Operations using the remote controller (RM-RK252) Disc Button Stop play Stop play Start play/Pause (if pressed during play) Start play/Pause (if pressed during play) • Reverse/forward chapter search * Reverse/forward track search * (No sound can sound can be heard.) be heard.) •...
  • Page 15 Stop play Stop play Stop play Start play/Pause (if pressed during Start play/Pause (if pressed during Start play/Pause (if pressed during play) play) play) Reverse/forward track search * Reverse/forward track search * Reverse/forward track search * • Forward slow motion * during pause.

  • Page 16: Operations Using The On-Screen Bar

    Using menu driven features... (DVD-Video/ Operations using the DVD-VR) on-screen bar Press TOP M/MENU to enter the menu screen. (DVD/DVD-VR/DivX/MPEG Video/VCD) fi Press to select an item you want to These operations are possible on the monitor using the start play. remote controller.
  • Page 17 On-screen bar Ex.: DVD-Video Information Operation Playback status Disc type Play • DVD-Video/DTS-CD: Audio signal format type and channel Forward/reverse search • VCD: PBC Forward/reverse slow-motion Playback mode * Pause Stop DVD-Video: T. RPT: Title repeat C. RPT: Chapter repeat Operation icons DVD-VR: C.

  • Page 18: Operations Using The Control Screen

    Track information Operations using the control Track list with the current track selected screen (DivX/MPEG Video/MP3/WMA/WAV/CD) To select a playback mode These operations are possible on the monitor using the While control screen is displayed... remote controller. Show the control screen. DivX/MPEG Video: Press during play.

  • Page 19: Operations Using The List Screen

    Current page/total number of the pages included Operations using the list in the list screen Current folder/track (highlighted bar) (DVD-VR/DivX/MPEG Video/MP3/WMA/WAV) These operations are possible on the monitor using the List screen (DVD-VR) remote controller. You can use ORIGINAL PROGRAM or PLAY LIST screen Before playing, you can display the folder list/track list anytime while playing DVD-VR with its data recorded.

  • Page 20: Listening To The Cd Changer

    Listening to the CD changer It is recommended to use a JVC MP3-compatible CD changer with your unit. You can connect a CD changer to the CD changer jack on the rear of the unit. • You can only play conventional CDs (including CD Text) and MP3 discs.

  • Page 21: Listening To The Ipod

    Listening to the iPod Before operating, connect the Interface adapter for iPod, KS-PD100 (separately purchased) to the CD changer jack on the rear of the unit. Preparation: Make sure “CHANGER” is selected for the external input setting, see page 25. Select “IPOD.”...

  • Page 22: Listening To The Other External Components

    Listening to the other external components You can connect an external component to: • CD changer jack on the rear of this unit using the following adapters: – Line Input Adapter, KS-U57 – AUX Input Adapter, KS-U58 Preparation: Make sure “EXT INPUT” is selected for the external input setting, see page 25. •...

  • Page 23: Settings

    Selecting a preset sound mode You can select a preset sound mode suitable to the music genre (c-EQ: custom equalizer). Preset value setting for each sound mode Preset value Sound mode BASS TREBLE LOUD (loudness) USER ROCK CLASSIC –02 HIP HOP JAZZ Adjusting the sound LOUD *...

  • Page 24: General Settings - Psm

    General settings — PSM You can change PSM (Preferred Setting Mode) items Select or adjust the selected PSM item. listed in the table below and on page 25. Enter the PSM settings. Repeat steps 2 and 3 to adjust other PSM Select a PSM item.
  • Page 25 • Pressing DISP for more than one second can scroll the display regardless of the setting. EXT INPUT * • CHANGER : To connect a JVC CD changer, [20], or an Apple iPod, [21]. External input • EXT INPUT : To connect portable audio player to the CD changer jack, [22].

  • Page 26: Disc Setup Menu

    Disc setup menu These operations are possible on the monitor using the remote controller. Enter the disc setup menu while stop. Select a menu. Select an item you want to set up. • To cancel pop-up menu, press RETURN. Select an option. To return to normal screen Menu Item...
  • Page 27 Menu Item Setting MONITOR TYPE Select the monitor type to watch a wide screen picture on your monitor. OSD POSITION Select the on-screen bar position on the monitor. • 1 : Higher position • 2 : Lower position (Guidance below the disc setup menu will disappear.) DIGITAL AUDIO Select the signal format to be emitted through the DIGITAL OUT (Optical) terminal.

  • Page 28: Title Assignment

    Title assignment More about this unit You can assign titles to 30 station frequencies (FM and General AM) using 8 characters (maximum) for each title. Turning on the power Select a station you want to assign a title • By pressing SOURCE on the unit, you can also turn on (see also page 10).
  • Page 29 (performer), and Tag (Version 1.0, 1.1, 2.2, 2.3, or * <.mod> is an extension code used for the MPEG-2 files 2.4) for the MP3/WMA/WAV files. recorded by JVC Everio camcorders. • This unit can display only one-byte characters. No • Audio stream should conform to MPEG1 Audio other characters can be correctly displayed.
  • Page 30 This unit can display up to 40 characters. Notice: When operating an iPod, some operations may not be performed correctly or as intended. In this case, visit the following JVC web site: <http://www.jvc. co.jp/english/car/support/ks-pd100/index.html>...
  • Page 31 About sounds reproduced through the rear terminals • Through the analog terminals (Speaker out/LINE OUT): 2-channel signal is emitted. When playing a multi-channel encoded disc, multi-channel signals are downmixed. DTS sound cannot be reproduced. (AUDIO—DOWN MIX: see page 27.) • Through DIGITAL OUT (optical): Digital signals (Linear PCM, Dolby Digital, DTS, MPEG Audio) are emitted through this terminal.

  • Page 32: Output Signal

    Output signals through the DIGITAL OUT terminal Output signals are different depending on the “DIGITAL AUDIO OUTPUT” setting on the setup menu (see page 27). Output Signal Playback Disc STREAM/PCM DOLBY DIGITAL/ PCM ONLY DVD-Video 48 kHz, 16/20/24 bits 48 kHz, 16 bits stereo Linear PCM * Linear PCM 96 kHz, Linear PCM 48 kHz, 16 bits stereo Linear PCM...
  • Page 33 Language codes Code Language Code Language Code Language Code Language Code Language Afar Persian Kazakh Norwegian Sesotho Abkhazian Finnish Greenlandic Occitan Sundanese Afrikaans Fiji KM Cambodian OM (Afan) Oromo SW Swahili AM Ameharic Faroese Kannada Oriya Tamil Arabic Frisian Korean (KOR) Panjabi Telugu Assamese...

  • Page 34: Maintenance

    Maintenance How to clean the connectors To keep discs clean Frequent detachment will deteriorate the connectors. A dirty disc may not play correctly. To minimize this possibility, periodically wipe the If a disc does become dirty, wipe it with connectors with a cotton swab or cloth moistened with a soft cloth in a straight line from center alcohol, being careful not to damage the connectors.

  • Page 35: Troubleshooting

    Troubleshooting What appears to be trouble is not always serious. Check the following points before calling a service center. Symptom Remedy/Cause • Sound cannot be heard from the speakers. • Adjust the volume to the optimum level. • Check the cords and connections. •...
  • Page 36 Symptom Remedy/Cause • Disc cannot be played back. • Change the disc. • Record the tracks using a compliant application in the appropriate discs (see page 4). • Add the extension code <.divx>, <.div>, <.avi>, <.mpg>, <.mpeg>, <.mp3>, <.wma>, or <.wav>...
  • Page 37 Symptom Remedy/Cause • The iPod does not turn on or does not work. • Check the connecting cable and its connection. • Charge the battery. • Update the firmware version. • The sound is distorted. Deactivate the equalizer either on this unit or the iPod. •...

  • Page 38: Specifications

    Specifications Maximum Power Output: Front/Rear: 50 W per channel Continuous Power Output Front/Rear: 19 W per channel into 4 Ω, 40 Hz to (RMS): 20 000 Hz at no more than 0.8% total harmonic distortion Load Impedance: 4 Ω (4 Ω to 8 Ω allowance) Tone Control Range: Bass: ±12 dB at 100 Hz...
  • Page 39 Signal Detection System: Non-contact optical pickup (semiconductor laser) Number of Channels: 2 channels (stereo) Frequency Response: DVD, fs=48 kHz/96 kHz: 16 Hz to 22 000 Hz CD, fs=44.1 kHz: 16 Hz to 20 000 Hz Dynamic Range: 96 dB Signal-to-Noise Ratio: 98 dB Wow and Flutter: Less than measurable limit...
  • Page 40 Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit © 2007 Victor Company of Japan, Limited 1207DTSMDTJEIN...

This manual is also suitable for:

Kd-dv6405
