REFRIGERATOR
RT6500M-SM.indd 1
REFRIGERATOR
Basic Model : RT18 / RT21
Model Code : RT21M6215** (Internal Display, Recess Handle,
RT18M6***/
RT21M6***/
Twin Cooling, Auto Ice Maker)
RT21M6211** (Internal Display, Recess Handle,
Twin Cooling, Twist Ice Maker)
RT18M6215** / RT18M6213** (Internal Display,
Recess Handle, Twin Cooling,
Auto Ice Maker)
RT18M6211** (Internal Display, Recess Handle,
Twin Cooling, Twist Ice Maker)
RT18M6114** (Internal Display, Recess Handle,
Twin Cooling, No Ice Maker)
CONTENTS
1. PRECAUTIONS
2. PRODUCT SPECIFICATIONS
3. DISASSEMBLY & REASSEMBLY
4. TROUBLESHOOTING
5. PCB DIAGRAM
6. WIRING DIAGRAM
7. BLOCK DIAGRAM
8. REFERENCE INFORMATION
2017-01-03
4:49:14
