{ServiceManual}{Production}{KodakServiceSupport}{ExternalAndInternal}
Kodak EasyShare C653 ZOOM DIGITAL CAMERA
Kodak EasyShare C623 ZOOM DIGITAL CAMERA
Important
Qualified service personnel must repair this equipment.
© EASTMAN KODAK COMPANY, 2007
SERVICE MANUAL
for
Minor Repairs
of the
Service Code: 1754
Service Code: 2774
Publication No. SM1754-2
Restricted Information
KODAK SERVICE AND SUPPORT
11JAN07
Confidential
Advertisement
Table of Contents
Related Manuals for Kodak EasyShare C653
Summary of Contents for Kodak EasyShare C653
- Page 1 {ServiceManual}{Production}{KodakServiceSupport}{ExternalAndInternal} Publication No. SM1754-2 11JAN07 SERVICE MANUAL Minor Repairs of the Kodak EasyShare C653 ZOOM DIGITAL CAMERA Service Code: 1754 Kodak EasyShare C623 ZOOM DIGITAL CAMERA Service Code: 2774 Important Qualified service personnel must repair this equipment. Confidential Restricted Information ©...
-
Page 2: Table Of Contents
Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault. -
Page 3: Section 1: Illustrated Parts List
Figure 2 P252_0123BA Note • You must use the Kodak DOCK ADAPTER KIT D-22 when connecting either the Kodak EasyShare C653 ZOOM DIGITAL CAMERA or the Kodak EasyShare C623 ZOOM DIGITAL CAMERA to the Kodak EasyShare CAMERA DOCK 6000. • The Kodak EasyShare C653 ZOOM DIGITAL CAMERA and Kodak EasyShare C623 ZOOM DIGITAL CAMERA are compatible with: –... -
Page 4: Visual Index
SERVICE MANUAL Visual Index P284_1000DCA P284_1000DC Item Description “BACK COVER AY” on Page 5 “MONITOR LCD” on Page 6 “FRONT COVER AY and BATTERY DOOR AY” on Page 7 “MAIN BOARD” on Page 8 “STROBE BOARD AY” on Page 9 “LENS AY and FRAME AY”... -
Page 5: Equipment Parts
Illustrated Parts List Equipment Parts Important You must do: • open the BATTERY DOOR • if installed, remove the BATTERY Figure 1 BACK COVER AY P284_1001HCA P284_1001HC Figure 1 BACK COVER AY Item Part No. Description Quantity Notes 3F6410 SCREW - pan head, B-tight, 1.7 x 4.5 3F9664 COVER AY - back, C653 3F9687... -
Page 6: Monitor Lcd
SERVICE MANUAL Figure 2 MONITOR LCD P284_1002HCA P284_1002HC Figure 2 MONITOR LCD Item Part No. Description Quantity Notes 3F9676 PIN - strap 3F9684 MONITOR LCD 3F6410 SCREW - pan head, B-tight, 1.7 x 4.5 3F9674 FRAME - monitor LCD 3F9675 SHEET - monitor LCD 11JAN07 –... -
Page 7: Front Cover Ay And Battery Door Ay
Illustrated Parts List Caution • The MODE DIAL must be in the “OFF” position. • Dangerous Voltage • You must do a discharge to the STROBE CAPACITOR at the SOLDER JOINTS after removing the FRONT COVER. Figure 3 FRONT COVER AY and BATTERY DOOR AY P284_1003HCA P284_1003HC Figure 3 FRONT COVER AY and BATTERY DOOR AY... -
Page 8: Main Board
FUSE - 4.00 A, F1904 See MAIN BOARD, 2 of 2. * This part is not available because you must do a calibration of the CAMERA using Kodak proprietary technology to comply with the specification, or the part is not in stock. -
Page 9: Strobe Board Ay
FUSE - 2.50 A, F2001 See STROBE BOARD. * This part is not available because you must do a calibration of the CAMERA using Kodak proprietary technology to comply with the specification, or the part is not in stock. SM1754-2 – 11JAN07... -
Page 10: Lens Ay And Frame Ay
CUSHION - battery contact, L FRAME AY * This part is not available because you must do a calibration of the CAMERA using Kodak proprietary technology to comply with the specification, or the part is not in stock. 11JAN07 – SM1754-2... -
Page 11: Section 2: Alphabetical Index
Alphabetical Index Section 2: Alphabetical Index Alphabetical Index Part No. Description Figure No. BOARD - main 3F9671 BOARD AY - battery CABLE - flexible flat, 24-pin - - - - CAPACITOR - strobe 3F9680 CONTACT - battery, A 3F9681 CONTACT - battery, B 3F9687 COVER AY - back, C623 3F9664... -
Page 12: Section 3: Diagnostics
SERVICE MANUAL Section 3: Diagnostics Error Codes The error codes are not available because the SERVICE SOFTWARE is a requirement for viewing the error codes. Checkout Procedures Checking the General Functions of the CAMERA Important You must do these procedures before returning the CAMERA to the customer. [1] Install: •... - Page 13 Diagnostics [20] Check that the VIEWFINDER is in focus when it moves from the “Wide” to the “Tele” position. [21] Capture an image. [22] Check: BUTTON • “menu” 1. Press the “menu” BUTTON. • 4-WAY 2. Check that the MONTIOR LCD illuminates. •...
-
Page 14: Monitor Lcd
SERVICE MANUAL [23] Press the SHUTTER BUTTON to capture an image. [24] Check: • image displays on the MONITOR LCD • icons display on the MONITOR LCD – mode of the FLASH – quality of the image – type of memory •... - Page 15 Diagnostics Position “Video” 1. Rotate the MODE DIAL to the “Video” position. 2. Check that “Video:” displays on the MONITOR LCD. 3. Press the SHUTTER BUTTON to the following positions to capture a video: • S1 for the image to be in focus •...
-
Page 16: Checking The Actuation, Flash, And Power-On Counters Without The Service Software
[2] Place the CAMERA on the CAMERA DOCK. [3] Press the TRANSFER BUTTON on the CAMERA DOCK. [4] Download the images and the video file with the Kodak EasyShare SOFTWARE. [5] Check the quality of the images. [6] Remove the CAMERA from the CAMERA DOCK. -
Page 17: Checking The External Components Of The Camera
Diagnostics Checking the External Components of the CAMERA [1] Check the COVERS of the CAMERA for scratches. [2] If necessary, install new COVERS. [3] Clean: • COVERS • SCREEN on the MONITOR LCD • VIEWFINDER WINDOW • FLASH COVER [4] Check and clean the LENS. SM1754-2 –... -
Page 18: Section 4: Publication History
Publication History Section 4: Publication History Publication Publication Changed File Date Pages Name Notes 11JAN07 SM1754-2 sm1754_2.fm New Publication Kodak and EasyShare are trademarks of Eastman Kodak Company. Printed in U.S.A. • sm1754_2.fm EASTMAN KODAK COMPANY Rochester, NY 14650...
