- Page 1 Arkel ArLine-NB Quick Installation Guide V1.07 ARKEL ARLINE - NB REMOTE ALARM, MONITORING AND INTERCOM SYSTEM FOR LIFTS QUICK INSTALLATION GUIDE...
- Page 2 This document has been created to be a guide for Arkel customers. Reproduction, transfer, distribution or storage of part or all the contents in this document in any form without the prior written permission of Arkel is prohibited. Arkel reserves the right to make changes and improvements to any of the products described in this document without prior notice.
-
Page 3: Table Of Contents
........................10 NFORMATIONS ALARM AND INTERCOM TABLE ..........................10 6.1. )..........................10 TART LARM MERGENCY 6.2..............................11 LARM ERMINATION 6.3..................................11 NTERCOM FIREFIGHTER MODE ..............................11 ARKEL ARLINE PARALLEL INSTALLATION ......................11 POSSIBLE ERRORS AND SOLUTIONS ........................12... -
Page 4: Safety Precautions
ARKEL reserves the right to make changes in the product and this manual for functional or commercial reasons. General Information Arkel ArLine-NB is a remote alarm system designed for lifts. It complies with EN 81-28, EN 81-20 and EN 81-70 •... - Page 5 Arkel ArLine-NB Quick Installation Guide V1.07...
-
Page 6: Arkel Arline-Nb External Connection Diagram
3.2. Arkel Arline-NB External Connection Diagram The Arkel Arline NB system can be installed and connected independently from the control panel and ARKEL systems, following the standards. The person performing the installation should follow the diagram below. Note-1: The Arkel Arline-NB system uses the CanBUS system to implement certain features. The necessary adjustments to enable these features are explained under the "Arkel Arline-NB Parallel Installation Solutions"... -
Page 7: Setting Parameters
Setting Parameters There are three ways to set parameters in the Arkel ARLINE MNB system. The parameters can be set with SMS, ARKEL Cloud or ARKEL AREM. After setting the parameters once, the device keeps the settings in the memory without any connection or setting. -
Page 8: Sms Parameters And Its Definitions
Setting Parameters Over Cloud ARKEL Cloud System ARKEL Cloud is a web-based user interface for ARKEL's Internet-connected devices. With this interface users can make device recordings, settings, view all their devices and perform remote monitoring of lifts. Users can access to the ARKEL Cloud system from the 'cloud.arkel.com.tr' address. - Page 9 Adding Buildings In ARKEL Cloud, devices are added under the buildings created by the user. Therefore, a building record must be created before adding devices. To add a new building, click on the 'Buildings' tab in the main menu, by clicking the “Add a New Building”...
-
Page 10: Start-Up Tests (En 81-28:2018, 6.3)
Adding Devices To define a new Arkel ArLine-NB device to the building, click on the 'Devices (Arkel ArLine)' link in the main menu on the left side of the screen. Enter the device adding page with the 'Add New Device' button. -
Page 11: Alarm Termination
Mode will remain active as long as there is energy on the input. If energy is cut off from the input, the Firefighter Mode will automatically terminate. To activate the Firefighter Mode on the CanBUS, information from an ARKEL elevator controller is required. To •... -
Page 12: Possible Errors And Solutions
3. Try triggering the alarm with another intercom unit. 4. If the FILTER LED is on the Arkel Arline-M device, the alarm will not sound. However, if you press the alarm button on the cabin unit that has been set up for more than 25 seconds, the filter will be disabled.
