D-Link DFE-520TX Quick Installation Manual
D-Link DFE-520TX Quick Installation Manual

D-Link DFE-520TX Quick Installation Manual

10/100mbps ethernet adapter
Hide thumbs Also See for DFE-520TX:

Advertisement

Quick Links

Contents of Package:
DFE-520TX Fast Ethernet Adapter
Quick Install Guide
CD-ROM, which includes driver software
If any of the above items are missing, please contact your reseller.
DO NOT insert the DFE-538TX into the computer's PCI
DO NOT insert the DFE-520TX into the computer's
PCI slot before installing the drivers.
Pre-installation Procedures:
If you have already installed the DFE-520TX into a PCI slot, advanced users may
utilize the "Add New Hardware Wizard" to manually specify the location of the
driver on the CD-ROM.
Otherwise, we strongly recommend canceling the "Add New Hardware Wizard"
and instead using the "Install Drivers" program in the CD-ROM.
Here is quick summary of the proper installation procedure:
Run the driver installation from the DFE-520TX CD-ROM.
Turn Off the computer and install the DFE-520TX into the PCI slot.
Restart the computer to complete the installation.
Installing the DFE-520TX Drivers
Turn ON the computer.
Insert the driver CD, which is included with the DFE-520TX, into the
CD-ROM drive.
l t b f
i
t lli
th d i

Advertisement

loading
Need help?

Need help?

Do you have a question about the DFE-520TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for D-Link DFE-520TX

  • Page 1 PCI slot before installing the drivers. Pre-installation Procedures: If you have already installed the DFE-520TX into a PCI slot, advanced users may utilize the “Add New Hardware Wizard” to manually specify the location of the driver on the CD-ROM.
  • Page 2 For Windows 2000, Windows XP and Windows 2003 users, the following screen will appear. Click OK For Windows 98/98SE and ME users, this screen will be displayed. Click Yes Next, TURN OFF the computer and unplug the power cord. Installing the DFE-520TX into the computer’s PCI slot...
  • Page 3 Note: To avoid static electric charges, please touch an unpainted screw on the outside of the power supply before installing or working with the DFE-520TX. • Turn off your computer and unplug the power cord. • Remove the back cover of your computer. (Refer to your computer’s manual if needed.)
  • Page 4 Type “winipcfg.” (In Win2000, type “ipconfig/all.”) In some cases it may be necessary to “Release and Renew” the IP address. Make sure to select the DFE-520TX as the specified adapter in the pull down menu. • If the IP address belongs to the same IP range and subnet mask as the...
