- Page 1 Genesis os-Boss dcx2 Dual DC-DC Converter Genesis Technologies Inc. www.genesisusa.com 5812 South 129 E. Ave. - Tulsa, Oklahoma 74134...
- Page 2 Thank you for purchasing the Genesis os-Boss dcx2 Dual DC-DC Converter. It is our goal always to provide quality products and service at a fair price, and treat every customer in a fair and forthright manner. We believe this is the only way to endure in the railroad industry marketplace over the long-term.
- Page 3 What's Included with the Genesis os-Boss dcx2 Dual DC-DC Converter 19062-000 os-Boss dcx2 Dual DC-DC Converter 19062-302 6-position Spring-Cage Mating Female Connector 19062-901 User Guide for os-Boss dcx2 Dual DC-DC Converter Genesis Technologies Inc. www.genesisusa.com...
-
Page 4: Features Summary
Today's surge and lightning protec,on technology is substan,ally be<er than that of even a decade ago, and the os-Boss dcx2 uses conserva,ve and industry proven design techniques to guard against damage caused by lightning and voltage surges. Circuit protec,on is further improved by self-rese>ng fuses that will limit input or output currents that could damage the internal electronic circuitry. - Page 5 2.5 amperes), the respec,ve track LED will flash. See Table 1b for a descrip,on of indica,ons and meanings. Figure 1 - os-Boss dcx2 Enclosure Front Table 1b - Track Status Indicators vs. Output Current Genesis Technologies Inc. Page 2 www.genesisusa.com...
- Page 6 AWG #14 or larger wire that is no longer than 48 inches. 2. If a B1 or P-150 style relay rack moun,ng base is used to mount the os-Boss dcx2, the relay rack must also be grounded by connec,ng to a nearby ground buss using an AWG #14 or larger wire that is no longer than 48 inches.
-
Page 7: Installation
“drop” and the circuit will appear to be occupied. Also, should the DC-DC converter fail, again the Track Circuit Relay will “drop.” The os-Boss dcx2 is func,onally similar to a conven,onal DC-DC converter with several excep,ons: ◦ the Track Current Limit Resistor is built-in to the os-Boss dcx2;... - Page 8 48 inches or less in length. 35mm DIN-Rail Mounting An op,onal 35mm DIN-Rail base is required to mount the os-Boss dcx2 on DIN-Rail. The DIN-Rail base is available from Genesis and will be factory installed if ordered with the os-Boss dcx2. Two 6-32 machine screws (maximum length 1/4”) are required if DIN-Rail base is user installed.
- Page 9 Os-Boss dcx2 B/N Power Source The input opera,ng power (B = ba<ery posi,ve and N = ba<ery nega,ve) source for the os-Boss dcx2 should be between 11.5 VDC and 24 VDC. Opera,on at voltages as low as 9.5 VDC and as high as 30 VDC are possible, but are not recommended for normal opera,on.
- Page 10 User Guide os-Boss dcx2 Dual DC-DC Converter Genesis Technologies Inc. Page 7 www.genesisusa.com...
-
Page 11: Three-Year Limited Warranty
Dual DC-DC Converter Three-Year Limited Warranty Genesis warrants all new products for three-years against parts failure and workmanship unless the warranty terms are specifically stated otherwise on the invoice or packing slip for that product when shipped. Warranty is explicitly for parts and workmanship and not for design or func,on.
