- Page 1 Eccentric Installation Instructions by Rogerseller Wall Mixer with Outlet Bath and Basin...
-
Page 2: Specification
Specification Eccentric by Rogerseller Parts List Optional Extras Wall Mixer with Outlet In-Wall Body/Assembly For installations with a greater Chrome 2. Ceramic Cartridge finished wall depth: 3. Splined Valve Stem 20mm Extended Body Other finishes available 4. Lock-nut 3606005200IW 5. Spline Extension... -
Page 3: Pre-Installation
Pre-Installation Checklist • Flush to remove any foreign matter from plumbing lines. • Ensure mixer is in the closed position during installation and testing. • In-line filters are recommended to ensure clean flow of water to the mixer. Mounting When mounting the body onto the wall frame, take note of the dimensions shown so the mixer is correctly positioned with the finished wall. -
Page 4: Installation
Installation Step 1 Valve Stem Install the spline extension onto the valve Spline Extension stem if not already done so. Screw Measure Step 2 27-28mm Trimming spline extension: Measure 27–28mm from the finished wall and trim spline extension at this finish point. Trim at nearest cutting groove towards wall... - Page 5 Installation Handle Step 5 Handle Screw Locate the handle and tighten handle screw Handle Button with 2.5mm allen key. If the handle isn't horizontal, remove the handle and mark both the valve stem and spindle extension. Remove extension and reposition by rotating one tooth at a time until horizontal is achieved.
- Page 6 Templates Plumbers Template (Mixer Orientation) Ensure if pairing with outlet to note offset nature of handle when roughing in. Please refer to handle orientation and template for offset location. Offset Drill Hole Tilers Template (Hole Cut Out) Offset Drill Hole 44 (Hole Drill Out) Minimum tolerances apply...
- Page 7 Warranty Rogerseller tapware, bathroom fittings and sanitaryware are covered by a five (5) year warranty from date of purchase. For full terms and conditions please refer to rogerseller.com.au Dimensions are approximate. Information in this installation instruction is representative of the product available at the time of printing.
