- Page 1 Tonic Installation Instructions by Rogerseller Gooseneck Pull Out Sink Mixer...
- Page 2 Tonic by Rogerseller Parts List Gooseneck Pull Out Mixer Tap Assembly Sink Mixer 2. Pull-out Hand Piece 3606013801 — Chrome 3. Outlet/Fixing Rod 12. 1.5m Pull-out Hose 4. Rubber Base Washer 13. Counter Weight 5. Rubber Horseshoe Washer 14. Counter weight Hose Clip 6.
-
Page 3: Installation
Installation Step 1 If not already done so, disassemble the Mixer Tap Assembly the mixer tap assembly, pull out hose and Guide the 1.5m pull-out hose and mixer tap assembly into the sink hole. Bench Hole Requirements: Outlet/Fixing Minimum Hole Size - Ø32mm Maximum Hole Size - Ø35mm 1.5m Pull-out Hose Base... - Page 4 Installation Step 3 Connect the dual check valve assembly to hoses to the appropriate inlets. (shown in the illustration) Screw all in a clockwise direction by hand until they come to a stop. Mixed Outlet Cold Inlet Hot Inlet (marked with "H") Step 4 Connect inlet hoses to the mains supply then connect the 1.5m Pull-out hose to the dual...
- Page 5 Due to our policy of continuous product development, the designs and expert prior to purchase. Each product is covered by a limited warranty. Full terms and conditions are available from your product expert. rogerseller.com.au...
