Model#: M01DB72
M01LB72
USE AND CARE GUIDE
FIREPLACE WITH 2
BARN
DOORS
IMPORTANT
Questions, problems, assembly help, missing parts?
We will gladly help and ship your replacement parts free of charge.
If you have any question related to product, please free to contact our
Customer service mail: oxharkflame@oxharkflame.com / TEL: 302-281-1886
IMPORTANT
THIS INSTRUCTION CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M01DB72 and is the answer not in the manual?

Questions and answers

Related Manuals for Oxhark Flame M01DB72

Summary of Contents for Oxhark Flame M01DB72

  • Page 1 Model#: M01DB72 M01LB72 USE AND CARE GUIDE FIREPLACE WITH 2 BARN DOORS IMPORTANT Questions, problems, assembly help, missing parts? We will gladly help and ship your replacement parts free of charge. If you have any question related to product, please free to contact our Customer service mail: oxharkflame@oxharkflame.com / TEL: 302-281-1886...

  • Page 2: Before You Start

    ! WARNING Do not allow children to climb on unit. Serious or fatal crushing injuries can occur from furniture tip-over, to prevent this furniture from tipping over it must be permanently fixed to the wall. Fixing devices for the wall are not included since different wall materials require different types of fixing devices.
  • Page 3 HARDWARE PART LIST NOT SHOW ACTUAL SIZE Cam Lock Cam Bolt Wood Dowel Screw Screw Screw...

  • Page 4: Angle Bracket

    HARDWARE PART LIST NOT SHOW ACTUAL SIZE Shelf Support Bolt Hinge Handle Screw Angle Bracket...

  • Page 5: Board Identification

    BOARD IDENTIFICATION NOT SHOW ACTUAL SIZE...
  • Page 6 STEP 1 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Securely screw the Cam Bolts (2) into the designated small holes of Part (Q), Part (R), Part (T) as shown. Fully tighten with a Phillips screwdriver.
  • Page 7 STEP 2 1. Align and attach the Part (Q) and Part (R) to the Part (S) by using the Cam Locks (1). 2. Then attach the Part (T) to the Part (Q) and Part (R) by using the Cam Locks (1) as shown.
  • Page 8 STEP 3 1. Securely screw the Cam Bolts (2) into the designated small holes of Bottom (B) as shown.
  • Page 9 STEP 4 1. Attach the assembled Part (Q), Part (R), Part (S) and Part (T) to the Bottom (B) with sixteen Cam Locks (1). 2. Then turn it over and securely screw the Cam Bolts (2) into the designated small holes of Bottom (B) as shown. Turn it over...
  • Page 10 STEP 5 1. Insert the Wood Dowels (3) into the Lower Sides (H&K), and Lower Partitions (I&J) as shown. 2. Securely screw the Cam Bolts (2) into the designated small holes of Lower Partition Verticals (N) as shown.
  • Page 11 STEP 6 1. Attach the Lower Partition Verticals (N) to the Lower Partitions (I&J) with four Cam Locks (1) as shown.
  • Page 12 STEP 7 Attach the Lower Sides (H&K) and Lower Partitions (I&J) to the Bottom (B) with eight Cam Locks (1) as shown.
  • Page 13 STEP 8 1. Insert the Wood Dowels (3) into the Part (M), Part (G), Part (E) and Part (F) as shown. 2. Securely screw the Cam Bolts (2) into the designated small holes of Upper Side Verticals (L) as shown.
  • Page 14 STEP 9 1. Securely screw the Cam Bolts (2) into the designated small holes of back side of Center Shelf (D) as shown. 2. Position the Rail (M) onto the inserted Wood Dowels and insert three Screws (4) through the countersunk holes on the Rail (M) and screw into the Center Shelf (D) as shown.
  • Page 15 STEP 10 1. Secure the installed (D) board to the lower (H), (I), (J), and (K) boards with eight cam locks(1) as shown in the diagram.
  • Page 16 STEP 11 1. Securely screw the Cam Bolts (2) into the designated small holes of back side of Center Shelf (D) as shown.
  • Page 17 STEP 12 1. Attach the Upper Side Verticals (L) to the Left Upper Side (E) and Right Upper Side (F) with the Cam Locks (1) as shown.
  • Page 18 STEP 13 1. Attach the Upper Side (E) and (F) to the Center Shelf (D) with four Cam Locks (1) as shown. 2. Fasten the Upper Partition (G) to the Center Shelf (D) with two Cam Locks (1) as shown.
  • Page 19 STEP 14 1. Securely screw the Cam Bolts (2) into the designated small holes of Top (A) as shown.
  • Page 20 STEP 15 1. Secure the installed (A) board to the lower (E), (G) and (F) boards with six cam locks(1) as shown in the diagram.
  • Page 21 STEP 16 1.Take Upper Back panels (O) and place them into the designated grooves. 2.Use the provided screws (6) to secure the (O) panels onto the fireplace frame through the pre-drilled holes. Note: For the grooves on panels , which do not have prde-drilled holes, simply screw the screws(6) into place.
  • Page 22 STEP 17 1.Take two rear panels (P) and place them into the designated grooves. 2.Use the provided screws (6) to secure the (P) panels onto the fireplace frame through the pre-drilled holes. Note: For the grooves on panels , which do not have pre-drilled holes, simply screw the screws(6) into place.
  • Page 23 STEP 18 Insert the Shelf Supports (7) into the desired holes in the sides of the side compartments. Make sure you place the four Shelf Supports in the same level so the shelf is not tilted. Tilt and rest the Adjustable Shelves (C) onto the Shelf Supports (7).
  • Page 24 STEP 19 1. Attach the Handle (10) to the front side of Left Door (U) with the provided Bolts (8) as shown. 2. Assemble the Hinges (9) to the Doors (U) with the provided Screws (5) as shown. 3. Repeat to assemble the Right Door (V) as shown.
  • Page 25 STEP 20 1. Assemble the Door (V) to the assembled mantel with the provided Screws (5) as shown. 2. Repeat the same procedure to attach the other Door (U) to the other Lower Side Panel (H).
  • Page 26 STEP 21...
  • Page 27 STEP 22 1. Unpack the fireplace insert from the firebox box, then lift the fireplace insert carefully into the back of the assembled mantel and center it in the opening. DO NOT drag the insert across the Base (B) as it may scratch the unit.

  • Page 28: Maximum Load

    Maximum Load This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, collapse, and serious injury.

  • Page 29: Maintenance

    Maintenance To clean and care for your furniture: - Use a soft, clean cloth that will not scratch the surface when dusting. - Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area. - Using solvents of any kind on your furniture may damage the finish.
  • Page 30 Your assembly should now be complete. Thank you for your purchase. “KEEP THESE INSTRUCTIONS FOR FURTHER REFERENCE"...
