Siemens MBPG1600 Installation Instructions

s
Breaker Mounting Base
Base del Montaje del Interruptor
Base de Support de Disjoncteur
Installation Instructions / Instructivo de Instalación
Hazardous Voltage. Hazardous Voltage.
Will cause death or serious injury. Will cause death or serious injury.
Turn off and lock out all power supplying this device before Turn off and lock out all power supplying this device before
working on this device. working on this device.
Replace all covers before power supplying this device is Replace all covers before power supplying this device is
turned on. turned on.
Use only with Siemens certified Components.
Utilizar únicamente con componentes certificados de Siemens.
A utiliser uniquement avec les composants certifiés Siemens.
NOTE - These instructions do not purport to cover all details or variations in equipment, or to provide for every possible
contingency to be met in connection with installation, operation or maintenance. Should further information be desired
or should particular problems arise, which are not covered sufficiently for the purchaser's purposes, the matter should
be referred to the local Siemens sales office. The contents of this instruction manual shall not become part of or modify
any prior or existing agreement, commitment or relationship. The sales contract contains the entire obligation of
Siemens. The warranty contained in the contract between the parties is the sole warranty of Siemens. Any statements
contained herein do not create new warranties or modify the existing warranty.
Trademarks - Unless otherwise noted, all names identified by ® are registered trademarks of Siemens AG or Siemens
Industry, Inc. The remaining trademarks in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owner.
Tensión peligrosa. Tensión peligrosa.
Puede causar la muerte o lesiones graves. Puede causar la muerte o lesiones graves.
Desenergice totalmente antes de instalar o darle servicio. Desenergice totalmente antes de instalar o darle servicio.
Reemplace todas las barreras y cubiertas antes de Reemplace todas las barreras y cubiertas antes de
energizar el interruptor. energizar el interruptor.
4 X 1/4 - 20 x 4.0"
3/8 – 16UNC x 1.75"
12X
MBPG1600
3VL9800-4TU31
1 / 5
U.S. Cat. No.
Item: MBPG1600
MBPG1601
For Use With Frame PG
Para Usar Con Caja Base PG
Tension dangereuse. Tension dangereuse.
Danger de mort ou risque de blessures graves. Danger de mort ou risque de blessures graves.
Couper l'alimentation de l'appareil et barrer avant de Couper l'alimentation de l'appareil et barrer avant de
travailler. travailler.
Remplacez touts les couverts avant que Remplacez touts les couverts avant que
l'approvisionnement de pouvoir soit alimenté. l'approvisionnement de pouvoir soit alimenté.
4 X 1/4 - 20 x 4.0"
3/8 – 16UNC x 1.75"
12X
MBPG1601
3VL9800-4TV31
Euro Order No.
3VL9800-4TU31
3VL9800-4TV31
9/16
7/8
9/16
3/8"
Cal. ISO 6789
I.L. No. 806952A02
