FD702XW HGU Products
1GE+1FE+WIFI+CATV
User Manual
Version：V1.1
Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the FD702XW and is the answer not in the manual?

Questions and answers

Related Manuals for C-Data FD702XW

Summary of Contents for C-Data FD702XW

  • Page 1 FD702XW HGU Products 1GE+1FE+WIFI+CATV User Manual Version：V1.1 Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
  • Page 2 FCC compliance statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Content 1 Note ..............................1 1.1 Installation Precautions ....................... 1 1.2 Precautions for Use ......................1 2 Brief ............................... 3 2.1 Product Features ........................3 2.2 Product Operation Introduction ................... 4 2.3 Product Specifications ......................4 2.4 Device Interface Definition ....................4 2.5 LED Description .........................
  • Page 4 11 TR069 Remote Management ..................... 25 11.1 Configure Channel for TR069 Remote Management ............25 11.2 TR069 Client Configuration .................... 25 12 Device Management ........................26 12.1 ONU Remote Access Configuration ................26 12.2 Restore Default Setting ....................26 12.3 Firmware Upgrade ......................27 12.4 Device Reboot .........................
  • Page 5 1 Note 1.1 Installation Precautions  Do not place the equipment near flammable or conductive items, high temperatures (such as direct sunlight) or in wet conditions, or on a PC chassis, and check that the surrounding appliances are stable.  Check the cable for aging. Check and verify that the AC or DC input voltage is within the permissible range of the device and that the polarity of the DC is correct.
  • Page 6  To ensure safety, do not open the enclosure of the device, especially when the device is powered up.  Unplug the power supply before cleaning the equipment. Use a soft dry cloth to clean the equipment to avoid the use of liquids or sprays. ...
  • Page 7 2 Brief Realtek series XPON ONU is satisfying with Telecom, Radio and Television, and Fiber To The Home (FTTH) multi service access. It’s based on the mature, stable, high cost performance EPON/GPON technology and has Gigabit and Fast Ethernet switching HFC technology, WLAN technology and powerful routing forwarding technology.
  • Page 8 Light reflection loss: >45dB ⚫ Product Operation Introduction The dual-mode ONU is a "combination" of GPON and EPON ONU. Compared with the single- mode EPON/GPON ONU, the main difference lies in the registration process. The dual-mode ONU adds a pre-judgment to the current application system (EPON/GPON). That is, the dual-mode ONU first switches mode, and then starts and completes registration process in the corresponding mode.
  • Page 9 2.5 LED Description Indicator Description On：CATV optical normal CATV CATV status Off：The CATV signals are not received Blinking：Data is being transmitted WIFI WIFI On：Wi-Fi function Opens On: Ethernet connection is normal Blinking: Data is being transmitted through the FE port status Ethernet port Off: Ethernet connection is not set up On: Ethernet connection is normal...
  • Page 10 2.7 Applications 3 Login Web Management Locally 3.1 Physical Connection of ONU and PC a) Local NIC of PC connects to LAN port or ETH port of ONU via wires. b) Set the IP address of PC’s local NIC as 192.168.101.X (X：2-254).
  • Page 11 3.2 PC Access the WEB of ONU Make sure you can ping the ONU like #3.1. Open the IE Web broswer (IE, Firefo x, Google), copy and paste URL: http: //192.168.101.1, the following pop-up Prompt landi n-g page: adminisp adminisp Input UserName：...
  • Page 12 You can start further configuration. 4 ONU Register Information Config(When adaptive to GPON mode) 4.1 View ONU Register Status 1. Login ONU WEB, select Status -> Internet Info -> GPON Info, view the ONU register status： 4.2 View ONU Optical Power Information 1.
  • Page 13 4.3 LOID Authentication Config LOID of ONU is mainly applicable of the authentication mode of LOID and LOID + Password for ONU. By default, ONU registers for the OLT by SN and rarely uses LOID for register. Normally, we needn’t to configure LOID. But the configuration as follows: 1.
  • Page 14 5.2 View ONU Optical Power Information 1. Login ONU WEB, select Status -> Internet Info -> GPON Info, view Rx power and Tx power of ONU： 5.3 LOID Authentication Config LOID of ONU is mainly applicable of the authentication mode of LOID and LOID + Password for ONU.
  • Page 15 Home Gateway Unit (HGU) ONU supports route function, so that there are route mode and bridge mode for internet. The difference between route mode and bridge mode as follows : Route mode：ONT as a home gateway equipment, ONT IP address can be obtained in three ways, which includes DHCP, Static IP Address and PPPoE.
  • Page 16 【Bind port】Bundel the physical ports (Lan port 1-4 and wireless) with PPPoE WAN connection. Note: By default, all LAN ports and WIFI data are not bound by this WAN connection (a LAN and WIFI SSID can only be bound to a WAN conection at the same time). 2.
  • Page 17 Configure DHCP WAN Connection for Internet in Route Mode 6.1.2 1．Login ONU WEB, select Internet -> Internet Config -> Internet Config, and then there are some parameters for us to configure as follows: 【WAN Connection name】Select ‘Add WAN Connection’ 【Mode】Select ‘ Route ’ 【...
  • Page 18 LAN and WIFI SSID can only be bound to a WAN conection at the same time). 2.After configuring the parameters of DHCP WAN connection as belows, click ‘Apply’ to finish the setting： Configure Static IP Address WAN Connection for Internet in Route Mode 6.1.3 1．Login ONU WEB, select Internet ->...
  • Page 19 【WAN Connection name】Select ‘Add WAN Connection’ 【Mode】Select ‘ Route ’ 【 Connection Mode 】 Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘ Ipv4/Ipv6 ’. 【Internet way】Select ‘Static’ 【NAT】Check ‘ NAT ’ feature；NAT is mainly used for address translation function of local network and external network.
  • Page 20 2. After configuring the parameters of Static IP WAN connection as belows, click ‘Apply’ to finish the setting： 6.2 Configure Bridge WAN Connection for Internet 1．Login ONU WEB, select Internet -> Internet Config -> Internet Config, and then there are some parameter for us to configure as follows: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506...
  • Page 21 【WAN Connection name】Select ‘Add WAN Connection’ 【Mode】Select ‘Bridge’ 【Connection Mode】 Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’. 【NAT】 Don’t check ‘NAT’ feature；NAT is mainly used for address translation function of local network and external network. HGU ONU doesn’t deal with the packets from the teminal, so we needn’t enable the NAT function.
  • Page 22 2. After configuring the parameter of Bridge WAN connection as above, click ‘Apply’ to finish the setting： 6.3 View the WAN Connection Status 1．Login ONU WEB, select Status -> Internet Info -> IPv4 Status. In here, we can view WAN connection status, check the route WAN connection if it gets an IP address and Bridge WAN connection if it is UP.
  • Page 23 7 ONU LAN Configuration 7.1 LAN IP Address Configuration 1．Login ONU WEB, select Internet -> DHCP Server -> IPv4 DHCP Server, and then there are some parameters for us to configure as follows: 【 IP address 】 Set local management IP address of ONU. The default IP address is 192.168.101.1 【Subnet mask】Set the mask of local management IP address of ONU 【Disable DHCP Server/Enable DHCP Server】Enable or disable ONU DHCP Server...
  • Page 24 7.2 View LAN Client 1．Login ONU WEB, select Status -> LAN & WLAN -> WLAN Status. View client that access via wireless (WIFI). As follows: 2．Login ONU WEB, select Status -> LAN & WLAN -> LAN Status. View client that access via LAN ports .
  • Page 25 8.2 IGMP Snooping Setting 1．Login ONU WEB, select Application -> IGMP Config -> IGMP Snooping. Enable or disable IGMP Snooping function and click ‘Save/Apply’ button to finish the setting as follows: 8.3 IGMP Proxy 1．Login ONU WEB, select Application -> IGMP Config -> IGMP Proxy. Enable or disable IGMP Proxy function and click ‘Save’...
  • Page 26 9 WLAN Configuration 9.1 WLAN Basic Configuration 1. Login ONU WEB, select Internet->WLAN Config->WLAN Config, and then there are some parameters for us to configure as follows: 【Enable wireless】Enable or disable the wireless function； 【Virtual SSID】Click ‘Virtual SSID’ button to enter the virtual SSID config page； 【Band】The default is 2.4GHz（B+G+N）；...
  • Page 27 2. After setting wireless configuration, click ‘Save/Apply’ button to finish setting. 9.2 WLAN Password Configuration 1．According to #8.1, click ‘Advanced’ button to enter ‘Wireless settings-Security’ page, we can set ‘Network authentication mode’ , ‘encryption’ and WIFI password. 2．After setting wireless password configuration, click ‘Save/Apply’ button to finish setting. 9.3 WLAN Virtual SSID 1．Login ONU WEB, select Internet->WLAN Config->WLAN Config, and then click ‘Virtual SSID’...
  • Page 28 2．After setting wireless password configuration, click ‘Save/Apply’ button to finish setting. Note: we can refer to #8.2 about setting the password of virtual SSID. 10 CATV Configuration CATV management is mainly applied to ONU with light machine, we need to configure the ONU optical machine parameters through the ONU’s WEB.
  • Page 29 11 TR069 Remote Management ONU TR069 remote management is mainly used for some network that support TR069 server centralized remote management, the current management is mainly used in many large networks, ONU as TR069 remote management of the client need to do the following settings. 11.1 Configure Channel for TR069 Remote Management Firstly, refered to #5.1, set a Route WAN connection with ‘Service mode’...
  • Page 30 12 Device Management 12.1 ONU Remote Access Configuration Login the ONU WEB, select Management -> Wan Access Control -> Wan Access Control. In this page, we can enable or disable the ping remote access and WEB remote access of ONU. 12.2 Restore Default Setting Login the ONU WEB.
  • Page 31 Note:Restore Setting on the ONU WEB is take effect to WIFI information of ONU and LAN port configuration only. It doesn’t take any effect to WAN connection. 12.3 Firmware Upgrade Login the ONU WEB. Select Management -> Firmware Upgrade -> Firmware Update. Click ‘选择文件’...
  • Page 32 Concluding Remarks Thanks for using products of Shenzhen C-Data Technology Co. Ltd. Contact Information: Company Address:Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: 1 floor, Building B, Wentao Industrial Park, Yingrenshi...
