- Page 1 INSTRUCTION MANUAL Thermoplastic Submersible Sump Pump CMXWUSD62348 CMXWUSD62346 CMXWUSD62313 CMXWUSD62558 CMXWUSD62556 IF YOU HAVE QUESTIONS OR COMMENTS, CONTACT US. 1-888-331-4569 WWW.CRAFTSMAN.COM...
-
Page 2: Table Of Contents
ENGLISH Index Content Page # Components Safety Guidelines Description Specifications Installation Operation Maintenance Troubleshooting Performance Parts Notes Warranty Components 1 Float Switch 2 Handle 3 Motor 4 1-1/2 in. (38.1mm) Discharge 5 Base 6 Check Valve* *Included with CMXWUSD62313 or sold separately under part no. CMXWUSDCV69502... -
Page 3: Safety Guidelines
ENGLISH Safety Guidelines Carefully read, understand and follow all safety WARNING: Don’t expose the pump to freezing instructions in this manual. Retain this manual for temperatures. Discharge lines exposed to freezing temperatures future reference should be positioned with a downward slope to prevent freezing. This is the safety alert symbol. -
Page 4: Description
This sump pump is designed to remove ground water from residential sump pits. The motor is oil cooled and hermetically sealed. A float switch is provided for automatic operation and is equipped with a 10 ft., 3-prong grounding type power cord. Specifications CMXWUSD62348 CMXWUSD62558 CMXWUSD62313... -
Page 5: Installation
ENGLISH Installation Install new pump - Cont WARNING: Always disconnect the power source before attempting to install, service or perform maintenance on the 5. Test your installation after you have completed setting pump. Failure to do so may result in fatal electrical shock. up the pump. -
Page 6: Operation
ENGLISH Operation Maintenance WARNING: The pump motor is thermally protected. It is WARNING: Risk of electric shock. Always disconnect not recommended for pumping liquids over 120° F (48.9°C). The the power supply before attempting to install, service or perform thermal overload protector will automatically shut down the maintenance on the pump. -
Page 7: Troubleshooting
ENGLISH Troubleshooting Problem Possible Causes How To Correct Pump is not plugged in; switch Plug pump in or turn on switch/breaker or breaker is turned off Check for blown fuses or tripped circuit breakers or Replace fuse, reset circuit breaker, reset GFCI outlet tripped GFCI outlets If the pump does not start or run... -
Page 8: Performance
Height and/or piping restriction will reduce the pump output performance. It is recommended to use the same size or larger pipe as the pump discharge for optimum performance. Model Number 25ft / 7.62m CMXWUSD62348 CMXWUSD62313 20ft / 6.1m CMXWUSD62346 CMXWUSD62558 CMXWUSD62556 15ft / 4.6m... -
Page 9: Parts
ENGLISH Replacement Parts For parts, contact customer support at 888-331-4569. CMXWUSD62348 CMXWUSD62558 Reference Description CMXWUSD62313 CMXWUSD62346 CMXWUSD62556 Power Cord 98101040 98101040 98101040 Shaft Seal T00900035/36 T00900035/36 T00900035/36 Impeller 98112002 98112002 G81200124 Base ACM200000 ACM200000 ACM200000 Intake Screen ACM200002 ACM200002 ACM200002... -
Page 10: Notes
ENGLISH Notes:... -
Page 11: Warranty
ENGLISH Limited Warranty: General Terms and Conditions - Cont: Manufacturer warrants the products specified in this Warranty will be VOID if any of the following conditions are warranty to be free from defects in material or workmanship found: for three (3) years from date of purchase. During the Product is used for purposes other than those for which time period and subject to the terms and conditions, it was designed and manufactured. - Page 12 45 Maryland Ave East St. Paul, Minnesota 55117 © 2022 CRAFTSMAN. CRAFTSMAN® is a registered trademark of Stanley Black & Decker, Inc., and are used under license. Product may differ from that pictured. Does not affect function. 09/22 Form #: 601102...
