D-Link 7000AP - Air Xpert - Wireless Access Point Quick Installation Manual

Tri-mode dualband wireless access point.
Hide thumbs


Advertisement

This product can be set up using
any current web browser, i.e.,
Internet Explorer 6 or Netscape
Navigator 6.2.3 or later.
Before You Begin
The default IP address for the DWL-7000AP is
255.255.255.0. You will need to assign your computer a Static IP address within the
same range as the DWL-7000AP's IP address for the purpose of configuring the DWL-
7000AP. See the Manual on the CD-ROM if you need assistance in assigning a
Static IP address for your network adapter.
Check Your Package Contents
If any of the above items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and
DWL-7000AP Wireless Access Point
CD-ROM (containing Manual and Warranty)
Ethernet (CAT5 UTP/Straight-Through) Cable
5V 2.5A DC Power Adapter
specifications subject to change without notice. DWL-7000AP. 06192003
DWL-7000AP
Tri-mode Dualband Wireless
192.168.0.50
with a Subnet Mask of
1
D-Link AirXpert
Access Point
Using a power supply
with a different voltage
rating will damage and void
the warranty of this product.
TM

Advertisement

   Related Manuals for D-Link 7000AP - Air Xpert - Wireless Access Point

   Summary of Contents for D-Link 7000AP - Air Xpert - Wireless Access Point

  • Page 1: Before You Begin

    If any of the above items are missing, please contact your reseller. ©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DWL-7000AP. 06192003...

  • Page 2

    Connecting The DWL-7000AP To Your Network First, connect the power adapter to the receptor at the back panel of the DWL-7000AP and then plug the other end of the power adapter to a wall outlet or power strip. The Power LED will turn ON to indicate proper operation.

  • Page 3: Using The Setup Wizard

    When you have completed the steps in this Quick Installation Guide, your connected network should look similar to this: Using The Setup Wizard Open your Web browser and type “http://192.168.0.50” into the URL address box. Then press the Enter or Return key. The logon pop-up screen will appear.

  • Page 4

    Using The Setup Wizard (continued) Once you have logged in, the Home screen will appear. Click Run Wizard You will see the following screens. Click Next...

  • Page 5

    Step 1 - Set up your password. You have the option to establish a password. Click Next Step 2 Wireless Lan 802.11a Setup The default wireless settings are: SSID = default Channel = 36 You can change these settings to match an existing wireless network.

  • Page 6

    Your Setup is Complete! Step 2 Wireless Lan 802.11g Setup The default wireless settings are: SSID = default Channel = 6 You can change these settings to match an existing wireless network. Click Next Step 3 WEP Encryption for 802.11g The DWL-7000AP is capable of 64, 128, and 152bit encryption.

  • Page 7

    Status tabs on the web-management interface; or to the manual located on the CD-ROM. • For managing several DWL-7000AP’s, please utilize the D-Link AirXpert Access Point Manager. For the latest version of the firmware or AP manager please go to http://support.dlink.com...

  • Page 8: Technical Support

    Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our website, or by phone.
