Installation & Operation Manual
Undercounter & Prep. table units
Please read this manual completely before installing or operating this unit!
BAUR28
BAUR36
BAUR48
BAUR60
BAUR72
Blue Air reserves the right to make product modification at any time. Specifications and Designs are subject to change without notice.
IMPORTANT SAFETY INSTRUCTION ( SAVE THESE INSTRUCTIONS )
Visit our website at www.blueairinc.com
Blue Air
Commercial Refrigeration Inc.
BAUF28
BAUF36
BAUF48
BAUF60
BAUF72
BAPT28
BAMT28
BAPT36
BAMT36
BAPT48
BAMT48
BAPT60
BAMT60
BAPT72
BAMT72
Advertisement
Table of Contents
Related Manuals for Blueair BAUR28
Summary of Contents for Blueair BAUR28
- Page 1 Blue Air Commercial Refrigeration Inc. Installation & Operation Manual Undercounter & Prep. table units Please read this manual completely before installing or operating this unit! BAUR28 BAUF28 BAPT28 BAMT28 BAUR36 BAUF36 BAPT36 BAMT36 BAUR48 BAUF48 BAPT48 BAMT48 BAUR60 BAUF60 BAPT60...
-
Page 2: Table Of Contents
Contents ♦ Specifications ………………………………..♦ Installation ……………………………………. ♦ Maintenance & cleaning …………………….. ♦ Operation ……………………………………... ♦ Trouble-Shooting …………………………….. ♦ Installing Castors ..………………………….. Service Contact Blue Air Refrigeration has a Nationwide Service Network to provide timely services to our customer’s needs. Please call or fax us at the following numbers. -
Page 3: Specifications
Specifications Product Undercounter Refrigerator Model BAUR28 BAUR36 BAUR48 BAUR60 BAUR72 Capacity (cu.ft) 16.5 Exterior Dimensions (Including 5” Casters) [in] Net Weight (lbs) Type of refrigeration system Indirect cooling (Fan blowing) Control Thermostat Control Shelves Number of Doors Rated Voltage AC115V /60Hz... - Page 4 Specifications Product Sandwich Prep. Table unit Model BAPT28 BAPT36 BAPT48 BAPT60 BAPT72 Capacity (cu.ft) 16.5 Exterior Dimensions (Including 5” Casters) [in] Net Weight (lbs) Type of refrigeration system Indirect cooling (Fan blowing) Control Thermostat Control Shelves Number of Doors Rated Voltage AC115V /60Hz Type of Power Cord NEMA 5-15...
-
Page 5: Installation
Installation 1. INDOOR USE ONLY 1) This unit is intended for indoor use only. 2. FOR LOCATION 1) Be sure that the location is strong enough to support the total weights of the unit and the content. 2) Keep the unit away from sunlight and other heat generating equipment. 3) The minimum clearance between the back of the unit and the wall should be 7 inches at least. -
Page 6: Operation
Operation 1. The temperature controller (thermostat) is located on the upper left of the back side of the cabinet interior. 2. The controller has been preset "NORMAL" position at the factory. 3. Set the control-knob toward "COOL" for higher temperature and "COLD" for lower temperature. -
Page 7: Troubleshooting
Troubleshooting Problem Possible Cause Action Power connection failure Check Power Cord and plug it in Compressor will not start Power switch is in off position Change it on position Temperature set point is too high Correct temperature set point The door is opened too frequently Loading of too much warm or moist product The unit does not... -
Page 8: Installing Castors
Installing Casters 1. Remove the outer packing. 2. Install the castors in the area. 3. Maker sure that castors with brakes should be installed in front. - Page 9 WARRANTY CERTIFICATE Warranty Valid Only In the USA This warranty is subject to all of the terms and conditions listed below. Warranty card furnished with this unit must be properly executed and returned to BLUE AIR immediately after installation. Failure to return the warranty registration card to provided location will automatically void all warranties.
- Page 10 Any such assignment or transfer will void this warranty and all other warranties implied. Improper Usage - BLUEAIR is not liable in any way for parts or labor coverage for component failure or other damages resulting from improper usage or installation or failure to clean and/or maintain product as mentioned in the warranty packet provided with the unit.
- Page 11 Warranty Registration Card Blue Air Commercial Refrigeration Inc. 15001 S. Broadway St. Gardena, CA 90248 Tel, 310-808-0102, Fax, 310-808-0242 Customer Name Business Name Telephone : ( Telephone : ( Address (Customer) Address (Business or Installation Site) Street Street City State City State Place of Purchase...
- Page 12 BLUE AIR 15001. S. Broadway St., Gardena, CA 90248 TEL, (310) 808-0102 Fax, (310) 808-0242/0262 Toll Free, 1-866-677-8500 Visit us our website at www.blueairinc.com...
