HFCF-SVX01-EN
Aug 2021
Supersedes HFCF-SVX01-ZH-EN
Oct 2020
RELEASED 14/Sep/2021 03:05:35 GMT
Installation, Operation and Maintenance
Chilled Water Fan Coil Unit
Airflow Range 200~1500 CFM
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating,
ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed,
adjusted or altered equipment by an unqualified person could result in death or serious injury.When working on the equipment,
observe all precautions in the literature and on the tags, stickers, and labels that are attached to the equipment.
Aug. 2021
2021
HFCF-SVX01-EN
690201790200
