- Page 1 Manual DVA050 DVA100 DVA170 Visit www.duratech.be for other available languages 11-01-24 Allegro...
-
Page 3: Table Of Contents
Table of contents Technical specifications Page 4 Remarks Page 5-6 Page 7 Box contents Installation instructions Page 10-11 Installation specialties Page 12-13 Page 14-15 Wiring instructions setup 1 Wiring instructions setup 2 Page 16-17 Wiring remarks Page 18-19 Page 20 Synchronizing Color programs Page 21... -
Page 4: Technical Specifications
Technical specifications Lamp Type Description Voltage Power Color temp Luminous flux* (*) Propulsion systems remains a tolerance of +/- 10% on luminous flux measurements @ 25°C ; 12VAC For operation only with a safety isolation IEC Protection Class III transformer Operation on DC voltages is NOT allowed 10 VAC 50/60 Hz Minimum input voltage:... -
Page 5: Remarks
Remarks Water conditions Prevent damage to your pool lamps and wires due to unstable water conditions. Your local government may have enacted guidelines for your pool water conditions to apply by. If not we strongly advise the following parameter specifications to be applied: pH level 6,8 - 7,6 Free Chlorine... -
Page 6: Installation & Maintenance
VISION Allegro pool lamps must be completely submerged into water during operation. Fixing the lamps with adhesives or silicone kit into a niche is not allowed. -
Page 7: Box Contents
Box contents 3m Cable** Connection Kit* VISION Allegro (50, 100 or 170 mm) Retrofit Kit Quick Start Guide (only for 170mm models) Lamp type Connection kit Cable DVA050 1 mm 513-0480 ; 1 washer for fixnut ; blue cable gasket + 1 spare washer... -
Page 8: Installation Instructions
Installation instructions Installing faceplate Toolset ( not included ) Contact your local distributor for a toolset (513-0151) Lamp Face Plate... - Page 9 Installation instructions Installing connector DVA050 DVA100 DVA170 3m Cable Washer Fix Nut Silicone Gasket Connector Installation: Page 10 & 11...
-
Page 10: Connector Installation
Connector installation... -
Page 12: Installation Specialties
Installation specialties DVA050 & PZA-WG For installations with DVA050 & PZA-WG-NG: Please make sure to only use 1 silicone washer for the Fix nut Fix nut PZA-WG-NG... - Page 13 DVA050 Removal tool When DVA050 needs to be removed from the PZA-WG-NG wall conduits, a special tool is needed (513-0491)* 1. Insert the tool over the lamp, straight into the wall conduit 2. Twist the tool counter clockwise the lamp should be snapped into the 3 hooks of the tool 3.
-
Page 14: Wiring Instructions Setup 1
Wiring instructions Setup 1 For new installations Each lamp is connected to the transformer via 1 cable Pool Pool house SELECT CABLE SECTION & MAXIMUM LENGTH 3m cable included in lamp package Always use a toroïdal transformer Separate cable ( not included ) - Page 15 SELECT CABLE SECTION & MAXIMUM LENGTH VA TRANSFORMER LAMP TYPE 1,5mm 2,5mm 4,0mm 6,0mm 10mm (12VAC)* DVA050-RGBW DVA050-WH DVA050-WW DVA100-RGBW DVA100-WH DVA100-WW DVA170-RGBW DVA170-WH DVA170-WW STABLE OPERATION OF THE POOL LIGHTS IS ONLY GUARANTEED WHEN THE INSTALLED CABLE CROSS SECTION MATCHES OR EXCEEDS THE ADVISED VALUES IN THE ABOVE TABLE * The transformer VA rating must be greater or equal to the sum of VA ratings of all connected lamps.
- Page 16 Wiring instructions Setup 2 For existing or other installations All lamps are connected to the transformer via 1 cable Pool Pool house SELECT CABLE SECTION & MAXIMUM LENGTH 3m cable included in lamp package Always use a toroïdal transformer Separate cable ( not included )
- Page 17 SELECT CABLE SECTION & MAXIMUM LENGTH VA TRANSFORMER LAMP TYPE 2,5mm 4,0mm 6,0mm 10mm (12VAC) DVA050-RGBW DVA050-WH DVA050-WW DVA100-RGBW DVA100-WH DVA100-WW DVA170-RGBW DVA170-WH DVA170-WW STABLE OPERATION OF THE POOL LIGHTS IS ONLY GUARANTEED WHEN THE INSTALLED CABLE CROSS SECTION MATCHES OR EXCEEDS THE ADVISED VALUES IN THE ABOVE TABLE...
-
Page 18: Wiring Remarks
230VAC / 400VAC power line. This noise might be injected into the adjacent 12VAC power line and disturb the power line communication towards the VISION Allegro lights. To prevent this, please take care of the following:... - Page 19 Pool Pool house 12VAC to lamps (**) 230VAC Min. 50cm 230VAC / 400VAC to third party equipment (**) Do not mix 12VAC and 230VAC / 400VAC power line cables into the same cable trays...
-
Page 20: Synchronizing
Synchronizing With LinkTouch + LINK Controller (PLP-REM or PLP-REM-350)* + LINK Master (DLM450 or DLM600) First make sure the LinkTouch is paired (see manual LinkTouch) Turn the lamps on and spin the color wheel on the LinkTouch until the lamps react. If the lamps do not react, turn them off and back on untill they react to the color wheel. -
Page 21: Color Programs
Color programs RGBW LAMPS DEEP BLUE SEA Saturated blue DAYLIGHT BLUE Light blue SUNSET Slow animation orange - red LOVE IS IN THE AIR FOREST SPRING Green THINK PINK Pink SUNSHINE Yellow JUNGLE BEACH Slow animation blue & green tints VOODOO Slow animation red &... -
Page 22: Troubleshooting
Troubleshooting PROBLEM SOLUTION The pool light is flickering 1. Switch the lamps ON and select Cold white color program 2. Remove the lamp from the water, unscrew the fix nut, pull back the gasket and the black cable jacket, so you can reach the brass contacts inside the connector block (do not remove the connector block) 3. - Page 23 Declaraction of Conformity Declarations of conformity covering this product are available for download from the House of Duratech website: www.duratech.be LINK VISION Moonlight HEAT Hot Splash FLOW Inverter COVER Tube Driver VISION Spectra HEAT Sun Spring FLOW Cartridge Filter COVER...
-
Page 24: Contact Details
Contact details Propulsion Systems bv Dooren 72 1785 Merchtem, Belgium Tel +32 2 461 02 53 www.duratech.be info@propulsionsystems.be We reserve the rights to change all or part of the contents of this document without prior notice...
