- Page 1 Viking Installation Guide DDHK29 Designer Handle Kit For Use With DFUR, DFUW, DFRI, DFIM, DFWD101 Models...
- Page 2 Please Read and Follow! • • • DFUW - WINE CELLAR DFIM - ICE MACHINE • DFUR - BEVERAGE CENTER DFRI - COMBINATION BEVERAGE CENTER/ICE MAKER • The installer should leave instructions with the customer who should retain for local inspector’s use and future reference.
- Page 3 CUSTOM FRONT INSTALLATION DFWD101 - WARMING DRAWER 26-7/16” Mounting Screws (67.2 cm) (4) - #8 x 3/4” 1-1/4” (3.2 cm) (6) - #8 x 3/4” screws to attach custom front 13/16” (2.1 cm) Custom Front Cavity Assembly Section - 7/16” (1.1 cm) Counter Bore x 1/2”...
