Summary of Contents for Phantom SPIRIT GLIDE DELUXE SD
-
Page 3: Table Of Contents
Main Components..................5 Benefits of Pure Water................6 Cart Model Description................6 Spirit Glide Deluxe Description............... 6 Spirit Glide Deluxe SD Description..........9 Spirit Glide Deluxe HC Description..........11 Spirit Glide Standard Description…………………………....14 Spirit Glide DI Description........…………..………..16 General Operation................. 18 Care &... -
Page 5: Overview
OVERVIEW This manual covers the six configurations offered by PHANTOM WINDOW WORKS in our SPIRIT GLIDE pure water maker carts. 1. SPIRIT GLIDE DELUXE 2. SPIRIT GLIDE DELUXE SD (4 STAGE) 3. SPIRIT GLIDE DELUXE HC 4. SPIRIT GLIDE STANDARD 5. -
Page 6: Benefits Of Pure Water
CONSUMPTION. CART MODEL DESCRIPTIONS SPIRIT GLIDE DELUXE The PHANTOM SPIRIT DELUXE is a three-stage water purification cart. The stages the raw water flows through are: • Carbon – 2.5” x 10” carbon filter removes chemicals and chlorine from the water before it reaches the RO element causing possible damage. - Page 7 PHANTOM TRADEMARK MAIN FRAME The PHANTOM mainframe has four unique features not found in any other cart on the market today. One, the main frame allows 360-degree protection of the RO element housing. Two, the main frame allows for mounting of the hose winder/hanger accessory which allows storage of up to 75 feet of ¼”...
-
Page 8: Axle Assembly
This is not ergonomic and leads to wrist fatigue or even damage. Additionally, having a bicycle grip style handle makes control of the cart difficult over varying terrain. PHANTOM SPIRIT GLIDE carts have a horizontal black plastic poly handle that we mill in-house. This handle ensures user comfort as well as ultimate control traversing terrain, keeping the cart from rolling or tipping. -
Page 9: Spirit Glide Deluxe Sd Description
10 minutes. SPIRIT GLIDE DELUXE SD The PHANTOM SPIRIT DELUXE SD is a four-stage water purification cart. The stages the raw water flows through are: • Sediment – 2.5” x 10” sediment filter removes sand and silt from the raw water before entering RO element. - Page 10 PHANTOM TRADEMARK MAIN FRAME The PHANTOM mainframe has four unique features not found in any other cart on the market today. One, the main frame allows 360-degree protection of the RO element housing. Two, the main frame allows for mounting of the hose winder/hanger accessory which allows storage of up to 75 feet of ¼”...
-
Page 11: Spirit Glide Deluxe Hc Description
This is not ergonomic and leads to wrist fatigue or even damage. Additionally, having a bicycle grip style handle makes control of the cart difficult over varying terrain. PHANTOM SPIRIT GLIDE carts have a horizontal black plastic poly handle that we mill in-house. This handle ensures user comfort as well as ultimate control traversing terrain, keeping the cart from rolling or tipping. - Page 12 PHANTOM TRADEMARK MAIN FRAME The PHANTOM mainframe has four unique features not found in any other cart on the market today. One, the main frame allows 360-degree protection of the RO element housing. Two, the main frame allows for mounting of the hose winder/hanger accessory which allows storage of up to 75 feet of ¼”...
- Page 13 This is not ergonomic and leads to wrist fatigue or even damage. Additionally, having a bicycle grip style handle makes control of the cart difficult over varying terrain. PHANTOM SPIRIT GLIDE carts have a horizontal black plastic poly handle that we mill in-house. This...
-
Page 14: Spirit Glide Standard Description
CUP HOLDER Every SPIRIT GLIDE cart by PHANTOM WINDOW WORKS has an integrated cup holder in the handle assembly. This again helps users have an additional hand free when moving their cart around worksites. - Page 15 PHANTOM mainframe (Deluxe Models). By using aluminum instead of painted frames, we are able to reduce harmful and wasteful fumes from entering our environment. CARTRIDGE HOUSINGS SPIRIT GLIDE STANDARD carts have black poly or gray poly cartridge housings for carbon and DI cartridges. The housing are 10 inches in length, with the carbon cartridge housing being 2.5 inches wide and the DI being 4.5 inches...
-
Page 16: Spirit Glide Di Description
10 minutes. SPIRIT GLIDE DI The PHANTOM SPIRIT GLIDE DI is a single-stage water purification cart. It is a DI only cart. It contains this housing/ cartridge combination. • 40” Stainless-Steel Cartridge Housing •... - Page 17 This is not ergonomic and leads to wrist fatigue or even damage. Additionally, having a bicycle grip style handle makes control of the cart difficult over varying terrain. PHANTOM SPIRIT GLIDE carts have a horizontal black plastic poly handle that we mill in-house. This handle ensures user comfort as well as ultimate control traversing terrain, keeping the cart from rolling or tipping.
-
Page 18: General Operation
GENERAL OPERATION DELUXE CARTS Deluxe carts have a water connection tree on the PHANTOM main frame. This is where you will make all your connections to perform pure water window cleaning. WATER IN This is where you will connect a simple garden hose from the water tap on a building to your SPIRIT CART. - Page 19 membrane, the pressure gauge may have differing readings. It is important for you to note what operating pressure is on your system when an RO cartridge is new. Rising pressures on your RO might mean one of two things. One, your RO is in need of a backflush. Two, your RO might be aging out and need replacement.
-
Page 20: Care & Maintenance Of Cartridges
HOW TO PROTECT YOUR HOSES Take the other end of your WFP hose and connect it to the push style compression fitting on your WFP brush. Turn on the on/off valve attached to the cart and allow the water to flow through the WFP line up and into the jets/spray bar on your brush. - Page 21 sure your backflush valve is closed. Turn on your water full. Allow the water pressure to pop the top black cap off of the housing. The hoses attached will keep the cap from falling off. The cap will rock backwards towards the handle, exposing the inner housing.
-
Page 22: Frequency Of Replacement
FREQUENCY OF REPLACEMENT THE SEDIMENT CARTRIDGE Frequent replacement may be needed depending on the sediment in your local water source. This filter protects the EXPENSIVE RO membrane from filling up with sediment which will shorten the life of the membrane. If you notice water production slowing, immediately replace the sediment filter (sediment filter on SD model only). -
Page 23: Deionizing Cartridge
away the minerals that the membrane separated from the water. Allow the water to flow through the RO in this manner to clean the membrane. Perform this process for every six to eight hours (full day working) you use the cart. THE DEIONIZING CARTRIDGE Unless damaged, you will not need to replace the refillable DI cartridge. -
Page 24: Care And Maintenance Of The Cart
If needed, PHANTOM WINDOW WORKS sells a SPIRIT GLIDE bracket mount and tie-down kit for these carts that can be mounted on or in a vehicle to ensure safe transport of the cart. -
Page 25: Troubleshooting
CLEANING THE HOSES AND FITTINGS Soap and warm water will keep the hoses clean and supple. Monthly wipe down the hoses and plastic fittings with Armor All. CLEANING THE TIRES Again, soap and warm water is great for weekly cleanings. Armor All can be used on a monthly basis on the wheels, rubber grommets and rubber feet. -
Page 26: Plumbing And Your Cart
The SPIRIT GLIDE cart series is unique in its design and the plumbing hose and fittings we chose to use. PHANTOM WINDOW WORKS only uses premium products on our product line. We do not build our products to meet a price point. -
Page 27: Plumbing Flow Diagram
#6 Stainless-Steel Worm Gear Hose Clamp 19.8 Oetiker Pinch Clamps WEIGHTS OF THE CART MODELS MODEL UN LOADED LOADED W/ WATER SPIRIT GLIDE DELUXE SD 52.0 lb 52.8 lb 61.8 lb 41.0 lb 61.2 lb 64.4 lb SPIRIT GLIDE DELUXE HC SPIRIT GLIDE DELUXE 38.4 lb... -
Page 28: Our Warranty
OUR WARRANTY PHANTOM WINDOW WORKS, a wholly owned subsidiary of DISRUPTOR MANUFACTURING will warranty this cart against defects in manufacturing and workmanship for all parts of this cart for the period of one year. This warranty does not cover customary wear items or consumables like membranes, cartridges or medium. -
Page 29: Cart View
CART EXPLODED VIEW... -
Page 30: Cartridge Main Log
CARTRIDGE MAINTENANCE LOG CARTRIDGE LIFE REPLACED... -
Page 31: Ce Declarations
465 Specialty Point Sanford, FL 32771 United States of America Declare under our sole responsibility that the products: Product line: Phantom Window Works™ Spirit Glide Deluxe 300100, 300300, 330100, 324200, 324100 CE Marking To which this declar on relates are in conformity with the requirements of the following...
