- Page 1 Universal User Manual a product of the company Bozzio AG Universal User Manual Universal_User_Manual_3_V06-250319.docx Aarbergstrasse 5 2560 Nidau Switzerland Bozzio AG * joysteer® page 1 of 11...
-
Page 2: Table Of Contents
Shut-down procedure ....................8 Instructor driving mode ....................8 Diagnostic mode ......................8 DRIVING WITH JOYSTEER® ..................9 Procedure for driving in HMI mode ................9 Procedure for brake hold function ................10 Procedure for driving conventionally with JPAS............10 Shutdown the system .................... -
Page 3: General
Universal User Manual General The joysteer® system offers a solution for people with disabilities (users) to drive a vehicle on their own via a suitable input device. joysteer® is a drive-by-wire system (fully electrical) for steer, brake and gas; intended to be driven with a line-up of different HMI’s (human machine interfaces). -
Page 4: Disclaimer
Universal User Manual Disclaimer Bozzio AG refuses their product liability if one or more of the following facts are given: • Driving the system by users who do not possess an appropriate driving licence. Exception: driving accompanied by an authorized driving instructor •... -
Page 5: Status Module
Universal User Manual Status Module The Status Module is the optical and acoustical interface to the user. For safety reasons, there are 2 LED’s and 2 buzzers to be considered, each for one leg of the redundant joysteer® system. Important: The visual and acoustic alarms must be checked at all times, during start-up, driving and shut-down. -
Page 6: Start-Up Procedure
Start driving is only allowed if the system is up and running (both LED’s light green). • The joysteer© system must only be operated when the vehicle engine is running. • The park position P of the gear shifter must remain during the start-up. -
Page 7: Driving Mode
The vehicle may be moved in conventional The vehicle must be repaired on the spot by the car driving mode. adaption company or taken in tow. Limp mode As above, with reduced gas pedal position Buzzer permanent Bozzio AG * joysteer® page 7 of 11... -
Page 8: Shut-Down Procedure
An unexpected takeover might occur. Diagnostic mode Status Indicators Meaning Measures Diagnostic mode Magenta Will only occur in the workshop While parametrisation or Software update process. Driving is not possible. Bozzio AG * joysteer® page 8 of 11... -
Page 9: Driving With Joysteer
2. Ensure that the park brake is engaged bevor you start the system. 3. Turn ON the vehicle ignition. 4. If needed, switch on the joysteer® system with the separate power switch. Otherwise, the joysteer® system will start automatically by ignition on (it depends on how the installation is done). -
Page 10: Procedure For Brake Hold Function
3. Only for HMI mode: Move the gas-brake-lever to centre position (set values for gas and brake equals to zero). 4. Switch off the ignition and the joysteer® power switch, if that is present (depends on how the installation is done). -
Page 11: Maintenance
Service and repairs The joysteer® system is a safety-critical application. Therefore, the user is not allowed to open any modules or to modify the system. For technical support, the car adaptation company which has built the car has to be contacted.
