Telguard T200C001 Installation And Operating Instructions Manual

Cellular alarm transmission system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
TELGUARD
Cellular Alarm Transmission System
™
Using Microburst
Control Channel Technology
MODELS T200C001; T300C001
U L
R
INSTALLATION AND OPERATING INSTRUCTIONS
COMPANY CONFIDENTIAL
®
For use by TELGUARD
customers only.
Distribution to others strictly prohibited.
®
T E L U L A R
C O R P O R A T I O N
Corporate Headquarters
647 North Lakeview Parkway
Vernon Hills, Illinois 60061
847-247-9400 Fax: 847-247-0021
December 21, 2000
®
TELGUARD
is a registered trademark of Telular Corporation. Products are protected
under one or more of the following U.S. patents:
4,658,096
4,737,975
4,775,997
4,868,519
4,922,517
© 2000 Telular Corporation
56020801
© 2000 Telular Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T200C001 and is the answer not in the manual?

Questions and answers

Related Manuals for Telguard T200C001

Summary of Contents for Telguard T200C001

  • Page 1 ® TELGUARD Cellular Alarm Transmission System ™ Using Microburst Control Channel Technology MODELS T200C001; T300C001 INSTALLATION AND OPERATING INSTRUCTIONS COMPANY CONFIDENTIAL ® For use by TELGUARD customers only. Distribution to others strictly prohibited. ® T E L U L A R...

  • Page 2: Foreword

    2. In Fire Alarm Service: When used in conjunction with a Listed central station fire alarm control unit with a two- telco line integral or Listed DACT, the combined control/communicator and Telguard T200C001 meet the requirements for commercial fire alarm usage under UL 864 and NFPA. This enables the T200C001 to be the second "phone line" in commercial fire installations.

  • Page 3: Notices

    1993, the U.S. Federal Communications Commission (FCC) proposed the adoption of this updated Standard. The design of your Telular Telguard DataBurst complies with this updated Standard. Of course, if you want to limit RF exposure even further than the updated ANSI Standard, you may choose to install the unit in a manner that locates its antenna at an even greater distance from the general public than is recommended as a minimum by the standard.

  • Page 4: Electronic Devices

    XPLOSIVE TMOSPHERES Turn OFF your unit when in any area with a potentially explosive atmosphere. It is rare, but your Telguard DataBurst or its accessories could generate sparks. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

  • Page 5: Part 68

     This equipment complies with Part 68 of the FCC Rules. Located on the inside of the hinged door of Telguard models T200C001 and T300C001 is a label that contains, among other information, the FCC Registration Number and Ringer Equivalence Number (REN) for this equipment. If requested, this information must be provided to the Telephone Company.
  • Page 6 This equipment, like any other electrical device is subject to component failure. Although this equipment is designed to be long lasting, the electrical components could fail at any time. Due to these limitations, we recommend that if the automatic self-test feature is not enabled, other arrangements be made with the user to test the system at least once every three months.

  • Page 7: Table Of Contents

    UL L ........................... 6 ISTINGS BY ODEL 2.9.1 Model T200C001............................ 6 2.9.2 Model T300C001............................ 6 REQUEST TELGUARD ACTIVATION FOR CELLULAR SERVICE FROM TELULAR ..... 6 GETTING READY............................6 INSTALLATION SUMMARY......................... 7 C/C A ................. 7 RANSMIT LARMS OVER THE ELCO ONNECTION ...............
  • Page 8 ONNECT ELCO INE AND UPERVISORY UTPUT 5.4.1 Be sure the Telguard is the first device on incoming phone line ............19 5.4.2 Connect RJ31X to Telguard Jack 1 and Check LFC................20 5.4.3 Connect STC Trip Output........................20 5.4.4 Check Telguard Supervisory Trip to C/C ....................21 5: C ..................22...
  • Page 9 A5.1 ......................40 IALER TO NTERFACE LECTRONICS A5.2 ...............................40 OWER  R A5.3 ..........................40 ICROBURST ADIO A5.4 ..............................40 HYSICAL A5.5 ..............................40 ARRANTY A6.0 PARTS LIST..............................41 INDEX..................................42 viii 56020801 © 2000 Telular Corporation...

  • Page 10: General Description And Operation

    In a typical alarm installation, Telguard is installed in the same area as the host alarm system. The incoming telco line is connected from the RJ31X to Telguard and then to the host control/communicator's digital dialer in the normal fashion.

  • Page 11: C/C Compatible Communication Formats

    In order for the C/C to be compatible with the Telguard, the C/C must be programmed to transmit alarm messages to the central station using one of the following non-extended formats: •...

  • Page 12: Radio Communications Failure Condition (Rfc)

    OWER UPERVISION Telguard monitors its backup battery as well as its AC power source and reports low or missing power conditions from either. Telguard’s integrated control and power module, protected by a 3 amp 3AG fuse, incorporates battery charger circuitry that is jumper selectable for high or low battery capacities. The high battery capacity selection is used for 12V 7Ah, or 12V 21Ah batteries.

  • Page 13: Telguard Automatic Self - Test Report

    The query signal is held in the Telguard database at the Communication Center for review and is not forwarded on to the central station.

  • Page 14: Diagnostic And Status Leds

    NFC/LFC trip delay time, and standby battery size. If operating parameters are not uploaded to the Communication Center, a "missing parameters (MP) condition" exists and the Telguard will not operate. When an MP condition exists, the Telguard causes the STC LED to light and the STC (System Trouble) trip output to occur.

  • Page 15: Ul Listings By Model

    3.0 Request Telguard Activation for Cellular Service from Telular There are two ways that you may activate cellular service for a Telguard. Both methods require the activation information to be completed and approved prior to installing the Telguard. The Telguard can only be activated when all the necessary accounting information has been entered into the customer database located at the Telular Communication Center.

  • Page 16: Transmit C/C A Larms Over The Telco Connection

    ADIO ETWORK Next, you will be connecting the C/C's digital dialer output to Telguard and verifying that alarm signals can be reliably sent through Telguard over cellular to the central station digital receiver. The incoming Telco line is not connected to Telguard during this step.

  • Page 17: Connect Telco Line And Supervisory Trip Output

    Once alarms are being successfully transmitted over cellular by the C/C, you will be ready to connect Telguard to the incoming phone line at the RJ31X and check that it properly switches to and from cellular upon telco restoral and telco line fault. Telguard's supervisory trip output (normally open) is connected to a 24-hour zone of the C/C and then tested.

  • Page 18: Step 1: Transmit C/C Alarms Over The Telco Connection

    Be sure the C/C is powered up and programmed so that it will transmit a simple alarm signal over the telco line through the RJ31X to the central station when not connected to the Telguard. In checking this, do not connect the host C/C or incoming telco line to the Telguard.

  • Page 19: Rogram Elguard And Confirm Communications Integrity

    5.2.1 Locate Unit Pick a spot next to the C/C where you think the Telguard will be mounted and place the unit down temporarily in that spot. Do not mount it permanently now, since it may need to be moved to receive a better cellular radio signal or a remote high-gain antenna may be necessary.

  • Page 20: Connect Backup Battery And Ac Power Transformer

    5.2.2 Connect Backup Battery and AC Power Transformer To apply power on models T200C001 or T300C001 attach battery leads to terminals 3 (-) and 4 (+) noting polarity and program Telguard memory location 67 (see section 5.2.5) for proper battery capacity.

  • Page 21: Default Programming

    Fill out the following Telguard Programming Data Sheet. The completed data sheet enables you to properly install and test the Telguard as well as provide a valuable aid to future troubleshooting if it becomes necessary. Detach and retain this data sheet in your customer account file for future reference.

  • Page 22: Setup And Programming

    For example, to re-program the Telguard to transmit over the "A" carrier, the installer would power down the Telguard; put jumper J5 "IN", connect the buttset to T and R test pins, and then power up the unit. After approximately 10 seconds, four tones will be sounded on the buttset indicating entry into programming mode.

  • Page 23: Measure Received Signal Strength (Rssi) For Best Antenna Placement

    If moving the Telguard to a different location is not practical, then you may need a longer cable on the remote antenna in order to receive adequate radio signal strength. Pick a high, visually secure spot, using the guidelines below.

  • Page 24: Antenna Options

    Telguard and allows the Telguard to communicate over the cellular network. A successful "ping" causes the red STC LED to turn off. Additionally, if the Telguard is programmed to monitor LFC, then the STC LED will begin to flash 3 times indicating a telco line fault condition since there is no telco line connected to J1 at this time.
  • Page 25 Note to Installers: The Telguard must be powered-up with antenna connected in order to receive the " activation ping ". Also, the Telular IVR system will allow you to enter a TEST menu to access the Telguard's operational history (e.g., number of occurrences of ACFC, LBC, LFC, and NSC since the last self-test transmission to the communication center).

  • Page 26: Step 3: Transmit C/C A Larms Over The Cellular Radio Network

    Confirm that the Telguard enables the host C/C to transmit alarm signals over the cellular radio network. In checking this, do not connect the incoming telco line to the Telguard or connect the supervisory trip output (STC) to the C/C zone input.

  • Page 27: Verify Alarm Signal Transmissions Over Cellular

    ♦ Call Telular Technical Service, 800-229-2326, and request the Communication Center operator to check the Telguard programming configuration for proper operation on " A " carrier or " B " carrier and proper communications format . The Telguard MUST be programmed to use the SAME FORMAT that the C/C is using (e.g.

  • Page 28: Telco Ine And

    The Telguard monitors voltage on the incoming phone line to decide when to switch transmission paths. This requires that the Telguard must be the first device on the telco line . If not, a line fault condition will be created (we call this a "phantom trip") each time the improperly connected device goes off-hook.

  • Page 29: Connect Rj31X To Telguard Jack 1 And Check Lfc

    5.4.2 Connect RJ31X to Telguard Jack 1 and Check LFC Find the modular Jack-to-Jack (J/J) cable supplied and connect one end to Telguard Jack 1 and other end to the RJ31X. Note that the STC LED goes out and the STC relay returns to normal due to telco line restoral.

  • Page 30: Check Telguard Supervisory Trip To C/C

    If the AC power is restored for 60 seconds or more, then the 6-hour timer restarts. When you are sure that the Telguard is monitoring the telco path and cellular path correctly and the C/C is correctly reporting the STC supervisory trip output, move on to Step 5.

  • Page 31: Step 5: Complete The Telguard Installation

    5.5.1 Check Settings Check the jumper setting of J5 (LED mode, out = normal). 5.5.2 Permanently Mount and Properly Ground the Telguard Chassis Attach earth ground to the green grounding screw located on lower left-hand corner of printed circuit board assembly and permanently mount the Telguard chassis.

  • Page 32: A1.1 Wiring Diagram

    RJ31X PREMISE ANTENNA PHONES STATUS LEDS (See Appendix A1.4) AC POWER SIGNAL SYSTEM TROUBLE STRENGTH TELGUARD OPERATION MODE LEDS RADIO TX OUT = NORMAL TRANSCEIVER IN = RSSI TELCO DIALER D O N OT C ONNE CT T O A SWIT C HED AC REC EP T AC L E.

  • Page 33: A1.2 Jack And Pin Assignments

    Reference Incoming Telco 1 Gray R1 Connects telco line to STC LED Flash 3 times RJ31X Jack. 4 Red R(Ring) Telguard and provides when telco voltage is Telco RJ31X. 5 Green T(Tip) output for premises phone lost. 8 Brown T1 connection at RJ31X.

  • Page 34: A1.3 Terminal Strip Pin Assignments

    - RFC1 - Failure to receive Link Request Ack after 3 attempts. RFC2 - Failure to receive Link Termination Ack after 2 attempts. ♦ Loss of Telguard Dial Tone Voltage (DTF) due STC LED Flashes 6 to: Improper dial tone voltage. ≤ 35 VDC. times.

  • Page 35: A1.4 Led Modes And Functions

    6 Flashes* System Trouble Condition – DTF MODE – LED 2 Yellow Solid ON Telguard operating in Mode 1 Fast Flash C/C off-hook to transmit signals over cellular. Solid ON (1 sec) Telguard in Microburst transmission. Radio TX – LED 1...

  • Page 36: A1.5 Jumpers

    Feature Function Normal Operating Used as LED Mode selector to indicate View Received Normal* Mode, RSSI or operating conditions of Telguard, used to Signal Strength Programming Mode. view Received Signal Strength or enter Programming Mode. Refer to A1.4. Enter Programming Mode.

  • Page 37: A2.0 Operational Quick Reference Table

    Mode LED turns on and STC LED turns off. Disable TX – Communication Center TX capability is disabled until further Activated. Radio TX (Status data) notice. Telguard can still receive radio When signals from Communication Center. transmitting. 56019201 © 2000 Telular Corporation...

  • Page 38: A2.1 Setup Programming Parameters

    Program Location 51 prevents Telguard from operating properly, the condition if programmed, will cause the supervisory trip output (STC) to trip the C/C's 24-hour zone forcing the C/C to communicate the "Telguard S ystem T rouble C ondition" to the central station.

  • Page 39: A2.2 Telguard Communication Formats

    A2.2 Telguard Communication Formats Telguard Standard Communication Formats NAME HANDSHAKE DATA BAUD RATE FORMAT EXTENDED KISS OFF Telguard FREQUENCY FREQUENCY FREQUENCY CODE RADIONICS (Double Round) 2300Hz 1800Hz 40 PPS 2300Hz FRANKLIN (Double Round) 2300Hz 1800Hz 20 PPS 2300Hz SIA P3 (Double Round)

  • Page 40: A2.5 Activation Form

    Telguard Automatic Self-Test Time: AM / PM NOTE: When activating the Telguard DataBurst unit using the Interactive Voice Recognition (IVR) system, you will be required to enter your Dealer number, Installer number, and the unit’s Serial number or Confirmation number.

  • Page 41: A3.1 Ul Grade A Central Station Service

    ERVICE Installation and wiring requirements for UL commercial burglary and residential burglary usage to achieve UL Grade A Central Station Service using Telguard model T300C001. Refer to Appendix A3.3 for “N ” explanations. If installing for UL Bank Safe and Vault Service refer to additional requirements in Appendix A3.3 Note "J".

  • Page 42: A3.2 Ul Grade A Police Station

    TATION ONNECT ERVICE Installation and wiring requirements for UL commercial burglary and residential burglary usage to achieve UL Grade A Police Station Connect Service using Telguard model T300C001. Refer to Appendix A3.3 for “N ” explanations. Radio Only Mode NOTE...

  • Page 43: Requirements On

    (For central station use only). The Telguard antenna must be installed indoors in an area concealed from field of vision and in an area where access is protected by Listed motion detector. The motion detector must be connected to an instant-armed initiating circuit of host burglary alarm C/C ∗...

  • Page 44: A3.3.1 Supervisory Requirements For Listed Burglary Configurations

    A3.3.1 Supervisory Requirements for Listed Burglary Configurations Listed Telguard Trip to Telguard Programming Host C/C Programming Burglary Supervisory Host Configuration Trip Output C/C* Supervised Setup Transmission Local Condition Requirement to Central Annunciation Station** Enabled Enabled with 30 or 60-sec. Telco delay.

  • Page 45: A3.4 Ul864/Nfpa Fire Alarm Central Station Service

    ERVICE Installation and Wiring Requirements for UL commercial and residential fire usage to achieve UL864/NFPA Fire Alarm Central Station Service using Telguard model T200C001. Refer to Appendix A3.5 for “Note” explanations. Telco Primary/Radio Secondary - Host C/C switches communication paths...
  • Page 46 Telco Primary/Radio Secondary - Telguard switches communication paths PRIMARY INCOMING TELCO NOTE RJ31X PREMISE REMOTE ANTENNA PHONES NOTE TELGUARD NOTE TRANSCEIVER 16.5 VAC NOTE 20 VA Transformer TO DIGITAL DIALER TELCO DIALER NOTE TO TELCO RJ31X HOST C/C ZONE TRIP INPUT INITIATION CIRCUITS: See Appendix A3.5.1...

  • Page 47: A3.5 Notes To Installation /Wiring Requirements On

    3. Plug the transformer into the 120 VAC receptacle and secure the transformer. 4. Secure the pull box cover. 5. AC power cable between the pull box housing and Telguard and between the host fire alarm control communicator must be enclosed in rigid conduit.

  • Page 48: A4.0 Ul Installation Requirements Summary Table

    T200C001 T200C001 T200C001 T300C00 T300C00 T300C00 T300C00 T200C001 T300C001 Telguard Model Required. UL Listed Bell and Bell Housing ** AC transformer lines in rigid conduit. AC transformer plugged into unswitched outlet. AC transformer plugged into dedicated branch circuit. AC transformer enclosed in Listed pull box (example: Hoffman A-SG8x8x6).

  • Page 49: A5.0 Detailed Specifications

    EAMPS standards for cellular compatibility and all applicable Aeris Microburst  Standards. The integrated Microburst  radio provides RF control channel data communication facilities for the Telguard DataBurst over the AMPS cellular network via the Aeris Microburst  data communications protocol.

  • Page 50: A6.0 Parts List

    Model T200C001 meets the requirements for Household Burglary, Household Fire, and Commercial Fire installations. T200C001 has a standard metal enclosure, keylock, and magnetic mount antenna with 12ft. cable. T200C001 is UL Listed for the following: 0 UL Household Burglary 0 UL Household Fire...

  • Page 51: Index

    STC Trip Output Strategy ........11 Ground ..............21 Supervisory Trip Output (STC) Relay ...... 4 Installation Summary..........7 Telco Signal Path through Telguard ..... 19 Intranet System............1 Telguard Communication Formats ....... 29 IVR................1 Terminal Strip Connections ........4 Jack and Pin Assignments ........

This manual is also suitable for:
