TELGUARD
Cellular Alarm Transmission System
™
Using Microburst
Control Channel Technology
MODEL T100C001
U L
R
INSTALLATION AND OPERATING INSTRUCTIONS
COMPANY CONFIDENTIAL
®
For use by TELGUARD
customers only.
Distribution to others strictly prohibited.
®
T E L U L A R
C O R P O R A T I O N
Corporate Headquarters
647 North Lakeview Parkway
Vernon Hills, Illinois 60061
847-247-9400 Fax: 847-247-0021
December 21, 2000
®
TELGUARD
is a registered trademark of Telular Corporation. Products are protected
under one or more of the following U.S. patents:
4,658,096
4,737,975
4,775,997
4,868,519
4,922,517
© 2000 Telular Corporation
56019201
© 2000 Telular Corporation
